Leckey Squiggles Stander User Manual page 13

8.4 PELVIC HARNESS
To attach the pelvic harness, simply slide
the left and right sides of the harness
over the lateral supports. Sleeve the
plastic buckles through the slots in the
harness. Then bring the Velcro fastener
straps around the bottom of the
moulding and attach them to the Velcro
panels as shown.
Finally pull the Velcro receiving straps
around the user to secure the user in the
harness.
Squiggles Stander User Manual p13
8.5 HIP SUPPORT
HARNESS
The hip support should be attached
around the pelvic harness as an
additional safety support should the
Velcro on the pelvic harness begin to
wear. It can be attached by clipping the
male buckle into the female buckle at
either end of the pelvic harness.
To adjust the tension lift the front panel,
adjust the straps to the required length
and then replace the panel.
8.6 KNEE SUPPORT PADS
Attach the knee pads by clipping the
male buckle into the female buckle at
either side of the knee support, making
sure the opening of the front cover is
facing downwards as shown.
