Leckey Squiggles Stander User Manual page 21

9.16 ADJUSTING THE
HEIGHT OF THE TRAY IN
PRONE AND SUPINE
The height adjustment knobs for the tray
are located on either side of the central
spine. Rotate knob
direction and rotate knob
anti-clockwise direction as shown,
select the required height and retighten.
A in a clockwise
B
in an
B
A
D
9.17 ADJUSTING THE
DEPTH AND ANGLE OF
THE TRAY
Loosen the adjustment knob
side, slide the tubes along the receiving
brackets to achieve the desired depth
and retighten the knobs. To adjust the
angle of the tray loosen the knobs
either side of the tray, set the tray to the
required angle and retighten securely.
Never use the tray to steer or
push the chair.
Do not place hot objects on
the tray, greater than 40
degrees Celsius.
Please note that the tray is
for the use of the user only.
Do not lean or place heavy
objects on the tray greater
than 8kgs (17.6lbs).
D
Squiggles Stander User Manual p21
D
C
on either
D
on
