Squiggles Stander User Manual p16
9.3 ADJUSTING THE
CHEST AND HIP SUPPORTS
To adjust the chest and hip support
A
rotate knob in a clockwise direction
and rotate knob
direction as shown. Set to the required
position and then retighten. The chest
support can only be adjusted in angle
and depth.
Always use caution to ensure
fingers do not become
trapped when adjusting the
chest and hip supports.
B
B in an anticlockwise
A

9.4 LATERAL SUPPORTS

Loosen the hand knob
width of the lateral supports and retighten
when you have achieved the desired
position. If, the lateral supports are
attached with bolts instead of hand
knobs they can be adjusted with the
multi tool.
9.5 ADJUSTING THE
PELVIC HARNESS
To adjust the pelvic harness pull the
Velcro receiving straps around the user
until the desired position is achieved.
A
to adjust the
A
