9.6 CHEST AND HIP
SUPPORT HARNESS
To change the width of the chest
harness, lift the front cover, adjust the
Velcro straps and set to the desired width
and replace the cover.
Always make sure the plastic
buckles are fully engaged
when using the
chest harness.
Squiggles Stander User Manual p17
9.7 ADJUSTING THE
STERNUM PAD
The sternum pad can be raised to
provide additional support to assist
thoracic extension. This also allows the
chest support to be set lower to enable
greater freedom of arm movement. The
sternum plate is adjusted by loosening
the two bolts at the front of the chest
plate with the multi-tool, set to the
desired height and retighten.
9.8 ADJUSTING THE
HEIGHT, DEPTH AND
ANGLE OF THE KNEE CUPS
Each knee cup can be positioned
independently. To adjust the height,
depth and angle of the knee cups, loosen
knob , select the height, angle and
A
depth required and retighten the knob
securely. To adjust the width of the knee
cup loosen knob
width then retighten.
B
, set to the desired
