Chapter 3: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on
the screen. The main menu allows you to select from several setup functions
and one exit. Use arrow keys to select among the items and press
accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS
Setup Utility.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Main Advanced Chipset Security
BIOS Information
BIOS Vendor American Megatrends
Core Version 5.11
Compliancy UEFI 2.4; PI 1.3
Project Version N614T009 x64
Build Date and Time 08/11/2016 18:12:01
Processor Information
Name SkyLake DT
Brand String Intel(R) Core(TM)
i7-6700 CPU @ 3.40GHz
Frequency 3400 MHz
Processor ID 506E3
Stepping R0/S0/N0
Number of Processors 4Core(s) / 8Thread(s)
Microcode Revision 84
GT Info GT2
1033
IGFX VBIOS Version
Memory RC Version 1.8.0.1
Total Memory 32768 MB
Memory Frequency 2133 MHz
PCH Information
Name SKL PCH-H
Version 2.17.1255. Copyright (C) 2016 American Megatrends, Inc.
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Main Advanced Chipset
Brand String
Frequency
to
Processor ID
Stepping
Number of Processors
Microcode Revisions
GT Info
IGFX VBIOS Version
Memory RC Version
Total Memory
Memory Frequency
PCH Information
Name
PCH SKU
Stepping
LAN PHY Revision
ME FW Version
ME Firmware SKU
System Date
System Time
Version 2.17.1255. Copyright (C) 2016 American Megatrends, Inc.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day,
from Monday to Sunday. Month displays the month, from January to
December. Date displays the date, from 1 to 31. Year displays the year, from
1999 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays
hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays
seconds from 00 to 59.
30
Security Boot Save & Exit
▲
Intel(R) Core(TM)
Set the Time. Use Tab to
i7-6700 CPU @ 3.40GHz switch between Time elements.
3400 MHz
506E3
R0/S0/N0
4Core(s) / 8Thread(s)
84
GT2
1033
1.8.0.1
32768 MB
2133 MHz
→←: Select Screen
SKL PCH-H
↑↓: Select Item
PCH-H Desktop H110 SKU
Enter: Select
31/D1
+/-: Change Opt.
B2
F1: General Help
F2: Previous Values
11.0.0.1194
F3: Optimized Defaults
Corporate SKU
F4: Save & Exit
ESC: Exit
[Tue 11/01/2016]
[15:59:15]
▼
