Chapter 2: Jumpers and Connectors

COM Port Box Headers

Connector type: 1x10 10-pin Wafer, 1.0mm pitch
Connector location: JCOM1 (Port3), JCOM2 (Port1) and JCOM3 (Port4)
10 1
Pin Definition
1 COM_DCD#
3 COM_TXD
5 GND
7 COM_RTS#
9 COM_RI#
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 COM_RXD
4 COM_DTR#
6 COM_DSR#
8 COM_CTS#
10 GND

SATA Connectors

Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: JSATA1, JSATA3, JSATA4 and JSATA2 (Q170 only)
1 7
Pin Definition
1 GND
3 SATA6G_TX_DN
5 SATA6G_RX_DN
7 GND
19
Pin Definition
2 SATA6G_TX_DP
4 GND
6 SATA6G_RX_DP
