Chapter 2: Jumpers and Connectors

PEGx16 Mode Select

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: JP3
1 3
Pin Status
1-2 Short PEG = 1 X 16 LANE
2-3 Short PEG = 2 X 8 LANE
1-2 On: default
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Settings

RS232/422/485 Voltage Select

Connector type: 1x5 5-pin header, 2.0mm pitch
Connector location: JRI1
1 5
Pin Status
1-2 Short
2-3 Short
4-5 Short
Pin Definition
1 VCC5
2 COM_RI#2_con
3 VCC5
4 COM_RI#2_con
5 COM_RI#2
9
Settings
+5V
+12V
RING
