Appendix A: Power Consumption
Voltage
Net Name
Input Source
Chipset Chipset Item
Skylake-S (65W) Quad Core
PCH-H (H110 co-lay Q170)
DDR4 SO-DIMM x2
HDMI/DP Combo Connector*2
PCIe x16 Slot
Mini-PCIe Card
Intel LAN - I219
Intel LAN - I211
USB 3.0 x4
USB 2.0 x2
USB 2.0 x4 (Pin Header)
ALC886
CPU + System FAN
COM Port (RS232*3 RS232 422 485*1)
SIO (ITE8786)
SP338
CH7511B
Total Current
Total Watt
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
0.95V 0.55V 0.55V
VCCIO VCCGT VCORE
CPU CPU (SVID) CPU (SVID)
5.50A 48.00A 79.00A
5.50A 48.00A 79.00A
5.23W 26.40W 43.45W
1.2V 0.6V
V_SM V_SM_VTT
CPU + DRAM
2.8A
6.00A 1.00A
6.00A 1.00A
7.20W 0.60W
59
Subtotal
2.5V 1.8V
Power
V1P8A
VPP
(Standby)
2.00A 0.52A
0.26A
2.00A 0.78A
5.00W 1.40W 170.03W
