Chapter 3: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on
the screen. The main menu allows you to select from several setup functions
and one exit. Use arrow keys to select among the items and press
accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS
Setup Utility.
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Main Advanced Chipset Security
BIOS Information
BIOS Vendor American Megatrends
Core Version 5.12
Compliancy UEFI 2.5; PI 1.4
Build Date and Time 03/06/2017 11:32:15
Access Level Administrator
Project Version N912-005 x64
Processor Information
Name SkyLake DT
Type Intel(R) Core(TM)
i5-6500 CPU @ 3.20GHz
Speed 3200 MHz
ID 0x506E3
Stepping R0/S0/N0
Package Not Implemented Yet
Number of Processors 4Core(s) / 4Thread(s)
Microcode Revision A6
GT Info GT2 (0x1912)
IGFX VBIOS Version 1046
Memory RC Version 2.0.0.6
Total Memory 8192 MB
Memory Frequency 2133 MHz
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Main Advanced Chipset
Stepping
Package
Number of Processors
to
Microcode Revision
GT Info
IGFX VBIOS Version
Memory RC Version
Total Memory
Memory Frequency
PCH Information
Name
PCH SKU
Stepping
Hsio Revision
TXT Capability of Platform/PCH
Production Type
ME FW Version
ME Firmware SKU
System Language
System Date
System Time
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
System Language
Selects the language of the system.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day,
from Monday to Sunday. Month displays the month, from January to
December. Date displays the date, from 1 to 31. Year displays the year, from
1999 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays
hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays
seconds from 00 to 59.
22
Security Boot Save & Exit
▲
R0/S0/N0
Set the Time. Use Tab to
Not Implemented Yet switch between Time elements.
4Core(s) / 4Thread(s)
A6
GT2 (0x1912)
1046
2.0.0.6
8192 MB
2133 MHz
SKL PCH-H
Q170
D1
→←: Select Screen
52
↑↓: Select Item
Supported
Enter: Select
Production
+/-: Change Opt.
11.6.0.1126
F1: General Help
Corporate SKU
F2: Previous Values
F3: Optimized Defaults
[English]
F4: Save & Exit
ESC: Exit
[Tue 02/14/2017]
[01:24:10]
▼
