Chapter 2: Jumpers and Connectors

Jumpers

AT/ATX Mode Select

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: JATX1
1 3
Pin Status
1-2 Short ATX Mode (option)
2-3 Short
2-3 On: default
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
AT Mode

RTC CMOS Clear Select

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: JRTC1
1 3
Pin Status
1-2 Short
2-3 Short
1-2 On: default
8
Settings
Normal
Clear CMOS
