Opening Unit - Steelcase Currency Workwall Manual

®

3 Opening Unit

NOTE: Assemble as close
to assembled units final
TURN
CLOCKWISE
desired location to avoid
moving a heavy unit.
1
LC
B
Cam locks can be seen on the topside of the
bottom shelf when installing the bottom shelf.
NOTE: Before assembling each part, please make
sure cams are parallel to the side of the surface &
pins are nicely screwed with the collar touching the
edge of the part. (See page 3 for proper alignment
of parts)
Use mallet, before tightening cam screws, to bring
parts together and avoid light leaks.
T
MC
Fasten Cam Locks in 6 places
(The cam lock screw needs to be turned
3/4 full turn or 270
TURN
CLOCKWISE
2
T
Fasten Cam Locks in 9 places
(The cam lock screw needs to be turned
3/4 full turn or 270
complete engagement.)
TURN
CLOCKWISE
o
clockwise for
complete engagement.)
For ease of assembly, it is
B
recommended to lay down
the end panel (E) as shown.
MC
E
TURN
CLOCKWISE
o
clockwise for
LC
Page 4 of 12
939500279 Rev E
