Steelcase Currency Workwall Manual page 3

®
(Tips for Proper Alignment of Parts)
CAM LOCK
(See cam lock note)
CAM LOCK NOTE:
If cam lock is installed high on the surface,
tap it down flush with the surface. If that
doesn't work, replace part.
If cam lock is installed low into the surface,
screw cam pin out to extend the length of
the cam pin.
Apply stickers on all visible cam
joint faces to cover the connector
faces, after assembly.
CAM LOCK
Make sure the cam
lock is located parallel
to the side of the
surface as shown.
NOTE: When assembly has been completed,
make sure to remove all of the E, B, I, ect.
stickers from the surfaces of all the parts.
CAM LOCK ADJUSTMENT TOOL
(The cam lock screw needs to
be turned 3/4 full turn or 270
clockwise for complete
Use mallet, before tightening cam screws, to
bring parts together and avoid light leaks.
TURN
CLOCKWISE
Fasten Cam Locks If the cam lock screw is not
visible, you have installed
o
the panel/shelf wrong and
engagement.)
NOTE: The cam pin is offset and needs
to be installed on the shorter offset side.
If the screw heads are not visible, turn
o
the panel/shelf 180 .
Shorter off-set side
PANEL
CAM PIN
CAM LOCK
WRONG
you need to turn the
o
panel/shelf 180 .
Page 3 of 12
939500279 Rev E
