Steelcase Currency Quarter Bookcase Instruction Manual

Download this manual

Components

Letter Description

Full End Panel

Top Panel

Center Shelf

Bottom Shelf Assembly

Short End Panel

Back Panel

If you have a problem, question, or request, call

your local dealer, or Steelcase Line 1 at

888.STEELCASE (888.783.3522)

for immediate action by people who want to help you.

(Outside the U.S.A., Canada, Mexico, Puerto Rico,

and the U.S. Virgin Islands, call: 1.616.247.2500)

Or visit our website: www.steelcase.com

2012 Steelcase Inc.

Grand Rapids, MI 49501

U.S.A.

Printed in U.S.A.

M O

Currency

Quarter Bookcase

Page 1 of 4

939500339 Rev D

Need help?

Do you have a question about the Currency Quarter Bookcase and is the answer not in the manual?

Page 1 Short End Panel Back Panel If you have a problem, question, or request, call your local dealer, or Steelcase Line 1 at 888.STEELCASE (888.783.3522) for immediate action by people who want to help you. (Outside the U.S.A., Canada, Mexico, Puerto Rico, and the U.S.
Page 2 ® (Tips for Proper Alignment of Parts) Use mallet, before tightening cam screws, to bring parts together and avoid light leaks. CAM LOCK ADJUSTMENT TOOL TURN WRONG CLOCKWISE Make sure the cam lock is located parallel to the side of the If the cam lock screw is not Fasten Cam Locks surface as shown.
Page 3 ® Components Fasten Cam Locks in 5 places (The cam lock screw needs to be turned NOTE: Assemble as close to assembled units final 3/4 full turn or 270 clockwise for Letter Description desired location to avoid moving a heavy unit. complete engagement.) Full End Panel Lower the MC (center shelf) and LC (bottom shelf assembly) onto the I...
Page 4 ® Components Letter Description Tip the unit into the upright position. Lower the T (top) Full End Panel onto the short end panel, full end panel & back panel as shown. Make sure pins engage into cams (see page 2 for Center Shelf alignment of parts).
