The TPM 2.0 (Trusted Platform Module 2.0) module is a modularized design applying to the
IMB700 and provides enhanced hardware security for the computer. In this appendix you will
learn how to install the TPM 2.0 module into the IMB700. Please read and follow the
instructions below carefully.
Insert TPM module into the SPI interface of the motherboard, as illustrated below.
1.
AX93515 TPM
module
There are two ways to confirm whether the TPM Module is installed successfully or not:
2.
a. Enter the BIOS setup menu and go to Trusted Computing. The first line will show
"TPM2.0 Device Found".
iAMT Settings
TPM Module Installation
TPM SPI interface
IMB700 LGA4189 ATX Motherboard
Appendix B
TPM module put in place
