This sequence is for installing the CPU cooler above 205 Watts:

Repeat step1 to 3 for installing CPU on CPU cooler.

Step 7

Latch four levers on the cooler.

Step5 Put the fan module on the CPU cooler and tighten two screws (8in-LBF).
