U P :
SER ARAMETERS
The section "User Parameters" is used to modify the parameters of the PROFIBUS slave (Fig. 9).
In this section there are:
The List of all Parameters available for the
PROFIBUS device ("User Parameters") (Fig.
9, point (1));
The Configuration of all parameters in RAW
("Parameters in RAW
point(2));
The "Use Parameter Inserted
enable this option is possible to insert
manually the parameters of Device and also
of the Modules. Using the
Parameters Manually" button is possible
to insert/modify the parametrization of the
device (and/or modules). For more info see
below. (Fig. 9, point(3));
The admited value
parameter. It is possible to select the value
desired and confirm it with the "Apply"
button. If no value appears in this table, the
"Min Value" and "Max Value" are the limit of
the parameter. (Fig. 9, point(4));
The "Apply" button is used to confirm the
new value of the parameter, the "Default"
button is used to load the factory value for
the parameter. In "New
is possible to set the new value. (Fig. 9,
point(5)).
ADFweb.com Srl – IT31010 – Mareno – Treviso
(Hex)") (Fig. 9,
Manually",
"Modify User
for the selected
Value" edit box it
Figure 9: "PROFIBUS Device – User Parameters" window
