AXIS 70U/7000 User's Guide

Basic Installation

Installation Summary

The AXIS 70U/7000 is installed in the following stages:

• Checking the Hardware Inventory.

• Connecting the AXIS 70U/7000 to a scanner.
• Connecting the AXIS 70U/7000 to the network.
• Assigning an IP address to the AXIS 70U/7000.
• Verifying the installation.
Checking the Hardware Inventory
Unpack and check all the items using the following list. Contact your dealer if
anything is missing or damaged. All packing materials are recyclable.
Item
Product
Media
Power Supply
Accessories
Optional Accessories
AXIS 7000
Optional Accessories
AXIS 70U/7000
Document Server
AXIS 70U
0162-xxx-01
AXIS 7000
0094-xxx-03 and
0094-xxx-04
AXIS 7000
0094-xxx-01
0094-xxx-02
Description
AXIS 70U Network Document Server
AXIS 7000 Network Document Server
AXIS 70U/7000 User's Guide
AXIS 70U/7000 Instruction Label
Keyboard Instruction Label
See table below
Mounting bracket with plastic feet
50-pin high-density shielded SCSI-2
connector (micro-D)
50-pin high-density shielded SCSI-2
connector (Centronics)
Mini Keyboard US
Mini Keyboard DE
Mini Keyboard UK
For Use in... Power Supply Type
Europe AXIS PS-H
UK
Australia
USA/Japan
Korea
Europe AXIS PS-E
UK
Australia
USA
Japan
Basic Installation
Part no. 14260
Part no. 14259
Part no. 17588
Part no. 17883
Part no. 17884
Power Supply Part no.
19108
19109
19111
19110
19112
15507
15509
15510
15508
15511
9
