AXIS 70U/7000 User's Guide
The tri-colored Network indicator displays:
Flashing Yellow
Flashing Green
Red

Assigning an IP Address to the AXIS 70U/7000

Follow the instructions below to set the IP address from the Control Panel.
Important!
• This section can be ignored if you are using DHCP, RARP or BOOTP, as the IP address is set auto-
matically (DHCP is the preferred method for Windows networks, as it automatically sets some
other parameters as well).
• A valid and unused IP address must be acquired from your Network Administrator.
• Connecting a PC-AT keyboard directly to the mini-DIN connector on your AXIS 70U/7000 pro-
vides a convenient method for managing the unit, and setting the IP address during system
start up. The administrator can choose to disallow this function from the Administration pages.
Please make sure that the AXIS 70U/7000 power supply is disconnected before connecting the
keyboard.
• The IP address for your product can also be set using the AXIS IP Installer (available at the Axis
Web site at http://www.axis.com), or the ARP, RARP, BOOTP or DHCP methods.
Please refer to the AXIS 70U/7000 User's Manual for further details.
1. Power up the AXIS 70U/7000 and press Menu
appears:
AXIS 70U
version: x.xx
2. After a few seconds this display will be shown:
IP Address:
000.000.000.000
3. Press Select
Edit IP Address:
000.000.000.000
4. Press Menu
5. Use
Indicating network activity on a 10MB Ethernet network.
Indicating network activity on a 100MB Ethernet network.
Indicating that the unit is not correctly connected to the network.
to edit the IP address:
to move through and highlight each digit, one at a time.
to increase or decrease each highlighted digit, as required.
Basic Installation
when this message
11
