EVAL-ADuC7026 User Guide

BILL OF MATERIALS

Table 5.
Component Qty
ADuC7026 1
Evaluation Board,
Revision B2
PCB Standoff 4
U1 1
U2 1
U3 1
U4 1
U5 1
U6 0
U7 0
U8 0
Y1 1
S1 1
S2, S3, S4 3
D1, D2, D3 3
D4 1
C1, C5, C13, C15, 7
C18, C22, C23
C2 to C4, C6, C12, 10
C14, C16, C17, C24
C7, C8 2
C9, C10 2
C11, C19 2
C20, C21 2
R1 1
R2 1
R3 1
R4 1
R5, R6, R8, R9 4
R7 1
R10, R11 2
R12, R18, R20 3
R13, R14, R23 3
R15, R16, R17 3
R19 1
R21, R22, R24 3
L1 1
J1 1
J2 1
J3 1
J4 1
J5 1
Part Description
PCB-1 2-sided, surface-mount PCB
Standoff Stick-on mounting feet
ADuC7026 MicroConverter (80-lead LQFP)
ADR291 Band gap reference
AD8132 Differential op amp
AD8606 Dual op amp, (8-pin SOIC)
ADP3333 Fixed 3.3 V linear voltage regulator
AT29LV1024 64 k × 16 flash
74LVT16373ADGG 16-bit D-latch
CY7C1020CV33-12 32 k × 16 static RAM
32.768 kHz Watch crystal
SW\8DIP 8-way DIP switch
Push-button switch PCB-mounted push-button switch
LED 1.8 mm miniature LED
PRLL4002 Diode
10 µF Surface-mount tantalum capacitor, Taj-B case
0.1 µF Surface-mount ceramic capacitor, 0603 case
22 pF Surface-mount ceramic capacitor, 0603 case
10 nF Surface-mount ceramic capacitor, 0603 case
470 nF Surface-mount ceramic capacitor, 0603 case
12 pF Surface-mount ceramic capacitor, 0603 case
10 kΩ 0.25W, 4 series, (4 mm × 4 mm square)
potentiometer
100 Ω Surface-mount resistor, 0603 case
200 Ω Surface-mount resistor, 0603 case
49.9 Ω Surface-mount resistor, 0805 case
348 Ω Surface-mount resistor, 0603 case
24.9 Ω Surface-mount resistor, 0805 case
60.4 Ω Surface-mount resistor, 0805 case
270 Ω Surface-mount resistor, 0603 case
0 Ω Surface-mount resistor, 0603 case
1 kΩ Surface-mount resistor, 0603 case
1.5 Ω Surface-mount resistor, 0603 case
100 kΩ Surface-mount resistor, 0603 case
Ferrite bead Surface-mount inductor, 1206 case
4-pin header 4-pin, 90º single-row header
42-pin header 42-pin, straight single-row header
42-pin header 24-pin, straight single-row header
20-pin header 20-pin, connector
Power socket PCB mounted socket (2 mm pin diameter)
Rev. B | Page 13 of 16
UG-669
Order No. Mfg.
Analog Devices
148-922 Farnell
ADuC7026CP Analog Devices
ADR291ER Analog Devices
AD8132ARM Analog Devices
AD8606AR Analog Devices
ADP3333ARM3.3 Analog Devices
AT29LV1024 Not populated
74LVT16373ADGG Not populated
CY7C1020CV33-12 Not populated
971-3220 Farnell
GH7242-ND DigiKey
177-807 Farnell
359-9954 Farnell
BAV103TPMSCT-ND DigiKey
197-130 Farnell
317-287 Farnell
722-005 Farnell
301-9561 Farnell
318-8851 Farnell
721-979 Farnell
TS53YJ 10K 20% TR Vishay
(lead free)
933-2375 Farnell
933-2758 Farnell
311-49.9HRCT-ND DigiKey
311-348HRCT-ND DigiKey
311-24.9HRCT-ND DigiKey
311-60.4HRCT-ND DigiKey
933-0917 Farnell
933-1662 Farnell
933-0380 Farnell
9331832 Farnell
933-0402 Farnell
952-6862 Farnell
TSM-104-02-T-SH Samtec
TSM-121-01-T-DV Samtec
TSM-124-01-T-SV Samtec
HTST-110-01-L-DV Samtec
KLD-SMT2-0202-A Kycon
