EVAL-ADG2108EBZ User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 4. Component Listing
Qty Reference Designator
19 C1, C3, C5 to C9, C11, C15,
C16, C18 to C22, C24, C26,
C28, C30
2 C2, C29
3 C4, C13, C14
4 C12, C25, C27, C31
2 C10, C17
1 C23
1 D1
1 D4
1 J1
1 J2
5 K1 to K5
18 R3, R4, R12 to R27
2 R5, R6
1 R7
2 R8, R9
1 R10
1 R11
4 R28 to R31
1 RESET
5 T1 to T5
1 U1
1 U2
1 U3
1 U5
2 SCL, SDA
9 X2_X3, X4_X5, X6_X7,
X8_X9, X10_X11, Y0_Y1,
Y2_Y3, Y4_Y5, Y6_Y7
1 XTAL1
Description
0.1 μF (0603 package), 50 V, X7R, SMD, ceramic capacitor
10 μF, TAJ_B, 16 V, SMD, tantalum capacitor
10 μF (0805 package), X5R, ceramic capacitor
10 μF, TAJ_A, 6.3 V, SMD, tantalum capacitor
22 pF (0603 package), 50 V, X7R, SMD, ceramic capacitor
2.2 μF (0603 package), 6.3 V, X5R, SMD, ceramic capacitor
Diode, SOT23
LED (0805 package)
USB Mini-B connector
4-pin terminal block
SIP-2P, two-pin header and shorting shunt
SMD, resistor (0603 package)
75 Ω, SMD, resistor (0603 package)
0 Ω, SMD, resistor (0603 package)
2.2 kΩ, SMD, resistor (0603 package)
10 kΩ, SMD, resistor (0603 package)
1 kΩ, SMD, resistor (0603 package)
10 kΩ, SMD, resistor (0603 package)
Push button switch (sealed 6 mm × 8 mm)
Test point
8 × 10 analog switch array
24LC64
USB microcontroller
3.3 V regulator
50 Ω, straight, SMB jack
Socket, phono, PCB, gold, 1 pair
24 MHz, CM309S, SMD, crystal
Rev. B | Page 11 of 12
UG-465
Supplier/Number
FEC 476–5837
FEC 498-737
Digikey 490-1709-1-ND
FEC 197-130
FEC 722-005
Digikey 490-1552-1-ND
FEC 984–3728
FEC 579–0852
FEC 978–6490, Digikey WM2499CT-ND
FEC 151-791
FEC 102–2247, FEC 150-411
Not inserted
FEC 933–1549
FEC 933–1662
FEC 933-0810
FEC 933–0399
FEC 933-0380
FEC 933–0399
FEC177-807
Not inserted
Analog Devices ADG2108YCP
Digikey 24LC64-I/SN-ND
Cyprus CY7C68013-56LFC
Analog Devices ADP3303AR-3.3
FEC 111–1349
FEC 128–0669
FEC 950–9658
