Connect the Optional Touchscreen

Incorrect routing of the connection cables can cause
tripping.
Fractures, contusions and bruises can be the result.
➢ Place the connecting cables so that no one can trip over
them.
To connect the optional touchscreen, proceed as follows:
➢ Connect the DisplayPort connector plug of the touchscreen to the
DisplayPort connector socket, located on the rear of the scanner.
➢ Connect the USB connector plug of the touchscreen to the USB
connector socket, located on the back of the scanner.
CAUTION
