> 'MENU' + "VFR/AIRSPACE/LAND/MARINE/OTHER SETTINGS" + 'ENTER'

3.5.10.1 VFR Settings

The VFR Settings category relates to the aviation features found in the Navdata Compact Flash.
Airports:
VoR:
NDB:
Intersections:
Vertical obstructions:
Aero objects Id:
Enroute Communications:
Note
The VFR Reporting points can be used as Route waypoints.

3.5.10.2 Airspace Settings

IThe Airspace Settings category relates to the airspace data found in the Navdata Compact Flash.
Low Airways: ON/OFF. The default setting is Off.
Note
Low Airways are only displayed below 50 Nm.
The Airline Airway, Control Airway and Direct Route Airway are displayed below 5 Nm.
This is the default setting. It is also possible to select them in the 50 Nm, 0 Nm, 10 Nm map scales.
The Official Designated Airway and RNAV Airway are displayed below the 50 Nm map scale.
To change from default settings, select 'MENU' + 'SELECTIVE DISPLAY', and scroll-down to any
of the following:
1. Airline Airway
. Control Airway
3. Direct Route Airway
4. Official Designated Airway
5. RNAV Airway
Refer to Section 3.5.1 for detailed information on how to customize the map display settings.
When routing to a specific leg, the Airline Airway, Control Airway, Direct Route Airway and Official
Designated Airway are displayed in blue, while the RNAV Airway (Area Navigation) are displayed
in purple.
Important Note: When the Low Airways are enabled, the Land Elevation (shading) display will be
disabled below the 50 Nm map scale. The land elevation can be determined by moving the cursor
to any area on the map display, and the elevation for that location will be displayed.
The QUICK INFO window gives you the data that refers to the selected airways. They are:
1. The Low Airways name
. The outbound course: from the starting point of the selected airway leg
3. The length of the leg
4. The minimum altitude of the leg
In the QUICK INFO window, you may get duplicate information about the same airway. This
3
ON/OFF. The default setting is On.
ON/OFF. The default setting is On.
ON/OFF. The default setting is On.
ON/OFF. The default setting is On.
ON/OFF. The default setting is On.
OFF/SMALL/MEDIUM/LARGE. The default setting is Large.
ON/OFF. The default setting is On.
