To deactivate, press 'GOTO' and select "DEACTIVATE".

1.3.7 Database

The Database function allows the user to access information stored in the data cartridges on
Airports, VOR's, NDB's, Intersections and User Waypoints. Searching the Database allows the user
to activate GoTo Flight Plans and locate the item on the map. There are two methods of accessing
the Database information. The first is through the Database function within the Main Menu and the
second is directly from the Moving Map display (see Chapter 3).

1.3.8 Battery Compartment and Batteries

The EKP-IV is designed with a battery compartment for 6 rechargeable AA batteries. It is located
in the rear of the unit underneath the removable knee mount. The unit provides a 'trickle' charge
to the batteries when the unit is plugged into external power and powered ON. Rechargeable AA
batteries are required. Install them only after the batteries are fully charged. With fully-charged
batteries, the normal discharge time will be close to two hours, depending upon the condition of
the batteries, as well as the brightness and contrast of the screen settings. AvMap highly recommends
that NiMH AA batteries be used (available from AvMap/Navigation, or from any electronics shop).
DO NOT USE ALKALINE BATTERIES, as they may damage the unit and void the warranty.
