Installation location
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– Filament lamp
or
– Spotlight; complete
Yellow rotating beacon:
(on the driver's cab)
– Rotating beacon, complete
Inside light:
(in the driver's cab)
– Cab light
– Reading light
SUPERSTRUCTURE LIGHTING:
Marker lights, yellow:
(left and right on the main boom head)
– Side marker light
Red rear marker lights:
(on the turntable)
– Marker light
Yellow rotating beacon:
(on the turntable)
– Rotating beacon, complete
Inside light:
(in the crane cab)
– Cab light
– Reading light
Spotlight, angular-shaped, permanently installed:
(at the front of the crane cab)
– Filament lamp
Spotlight, electrically adjustable:
(at the front of the main boom)
– Filament lamp
Spotlight, swinging:
(at the front of the main boom)
– Halogen bulb
Maintenance manual
GMK3060
GROVE part
number
02316460
03143786
04156048
00550434
00550434
03329569
03329492
04156048
00550434
00550434
01573349
03142726
02309610
3 302 574 en
Spare parts required for maintenance
Designation Power (W)
8GH 002090251
LED
K 24 V
K 24 V
LED
FPL 98 CKS
K 24 V
K 24 V
H3 24 V
8GS009028001
810992 RSY
11.2 Lighting
70
10
10
10
10
70
35
100
11 - 3
