Power - mectron compact piezo led Manual

V ~ .Power
For powering the module at 24V
Connect pins 8 and 9 in order to insert the filter capacity.
Observe the plate values as far as voltage and current are concerned.
V .Power
For powering the module in V , connect the positive to pin 14 and the negative to pin 15.
Connect pins 8 and 9 in order to insert the filter capacity.
Observe the plate values as far as voltage and current are concerned.
compact piezo led connections
~ 50/60 Hz connect pins 13 and 14.
16
1
15
2
14 3
13 4
5
12
11 6
7
10
8
9
16
1
15
2
14
3
13
4
12 5
11
6
10 7
8
9

Power

~
Vin
+
-
EN
17
