FarmTek PolyMax H1-10 Manual

Dutch bucket system
Hide thumbs

Advertisement

Quick Links

Download this manual
Versatile PolyMax® Dutch Buckets are ideal for both small- and large-scale hydroponic growing.
©2020 FarmTek
®
All Rights Reserved. Reproduction
is prohibited without permission.
Revision date: 05.13.20
112529 PolyMax® H1-10
Dutch Bucket System
PolyMax® Dutch Buckets
*Actual system may differ.
STK#
112529
19" W x 26" H x 118" L*
*Dimensions have been rounded and are approximate.
Dimensions are of the frame only; they do not include
buckets, reservoir, or drain plumbing.
DIMENSIONS
1

Advertisement

loading

Related Manuals for FarmTek PolyMax H1-10

Summary of Contents for FarmTek PolyMax H1-10

  • Page 1 *Actual system may differ. PolyMax® Dutch Buckets Versatile PolyMax® Dutch Buckets are ideal for both small- and large-scale hydroponic growing. STK# DIMENSIONS ©2020 FarmTek ® 112529 19" W x 26" H x 118" L* All Rights Reserved. Reproduction is prohibited without permission.
  • Page 2 READ THIS DOCUMENT BEFORE YOU BEGIN TO ASSEMBLE YOUR 112529 DUTCH BUCKET SYSTEM. This guide provides helpful hints and important information needed to safely assemble and properly maintain the 112529 PolyMax H1-10 Dutch Bucket System. Read and understand this guide before you begin.
  • Page 3 Important Information PICTORIAL GUIDE The following graphics and photos will help you identify the different parts of the system. Consult the Quick Start Guide for additional details and diagrams. (All parts are sold separately.) Plastic Pipe & Tube Cutter WF1023 Filter (1) 111698 Ratchet Clamp 111044 110407...
  • Page 4 Important Information PICTORIAL PARTS GUIDE—CONTINUED PVC PRIMER & CEMENT Follow all directions printed on pvc primer and cement containers. Purple color of primer does not fade! Use caution during application FAG102B FALF15B FALB04B WF6990 106742 to reduce spills and over application at joints. PVC Cement and Prime all joints before assembly.
  • Page 5 Assembly Instructions ATTENTION: Use a carpenter's square to square the frame during assembly and ASSEMBLE TABLE FRAME before you tighten all the fasteners. Required Parts: • FALB04B 3/8" nuts (12) and 106742 3/8" x 2-1/2" carriage bolts (6) • FAG102B 1/4" x 3/4" bolts (18) and FALF15B 1/4" lock nuts (18) •...
  • Page 6 Assembly Instructions Required Parts: INSTALL 1-1/2" DRAIN TUBE CLAMPS • WF4140 PVC tube (1) and FAPA14 pipe clamp for 1-1/2" PVC • FAG102B 1/4" x 3/4" bolts (6) and FALF15B Complete these steps: 1/4" lock nuts (6) 1. Locate and mark the center at each end of the frame. 2.
  • Page 7 Assembly Instructions Required Tools: • Drill with a 1" hole saw. Example shows using a MARK AND DRILL BUCKET DRAIN HOLES step bit. Keep holes aligned and uniform. • Marker, chalk line, and tape measure Complete these steps: 1. With the drain tube in place on the frame, snap a chalk line from end-to-end along the top of the drain tube. 2.
  • Page 8 Assembly Instructions ASSEMBLE AND INSTALL SIPHON ELBOWS Complete these steps: 1. Assemble the siphon elbows as shown. Two (2) elbows are used for each Siphon Elbow assembly. 2. Take the elbow assembly and install one inside each Dutch bucket. 3. Check bucket position on the frame and verify that each bucket drain nipple is inserted in the drain hole of the pvc drain tube.
  • Page 9 Assembly Instructions ASSEMBLE FILTER AND RELATED FITTINGS WR1095 Complete these steps: Tape 1. First remove the WF1023 filter cap and replace it with the 112066 shut-off valve. Tape the filter threads before installation. Tighten valve until snug. 2. Take the WR1095 thread tape and wrap the threads of each component four or five times. Apply tape in a direction that prevents unwrapping during assembly.
  • Page 10 Assembly Instructions Drill 2" Drain Tube Hole 2" Drain DRILL HOLES IN RESERVOIR COVER Tube Hole Supply Drill 2" Drain Tube Hole Tube Hole 1. Position the reservoir under the Dutch bucket frame and determine in which corner you want to drill the drain tube hole in the cover.
  • Page 11 Assembly Instructions ASSEMBLE PUMP AND SUPPLY TUBE AC2804 110729 111698 Connect this end to the Complete these steps: Ratchet 110721 pump. Clamp 1. Take the filter assembly from Procedure 5 and attach it to the 110721 water pump. Consult the documentation supplied with the pump to properly select and install the tube fitting and related seal.
  • Page 12 Assembly Instructions ASSEMBLE AND INSTALL DRAIN MANIFOLD Use the photos below to assemble the drain manifold. Read these notes before you continue. WF6990 PVC Cement & • A five (5') section of pvc is included to construct this manifold. WF6627 WF1574 WF1384 113372 PVC Purple Primer...
  • Page 13 Assembly Instructions 110407 Dripper PREPARE AND INSTALL IRRIGATION LINES Stake Complete these steps: 1. Use the plastic pipe and tube cutter to cut twenty (20) 16" irrigation lines—two (2) for each bucket. 2. Gently push one 16" line onto each 110407 dripper stake. Wet the line end for easier assembly.
  • Page 14 Assembly Instructions ATTENTION: Always position the air pump above the reservoir/water level to prevent siphoning of the reservoir. ATTACH THE AIR PUMP AND AERATOR STONES 109260 Air For optimal system performance and to extend the life of the nutrient solution through increased Stone oxygenation, an aerator pump and aerator stones are included.
  • Page 15 OPERATIONAL AND MAINTENANCE INFORMATION General Operating Instructions General Cleaning and Maintenance Instructions After assembling the 112529 Dutch bucket system, take a few minutes to For optimal performance and to increase yields, check and clean the Dutch check the system. Complete these steps. bucket system periodically.
  • Page 16 OPERATIONAL AND MAINTENANCE INFORMATION RESERVOIR CLEANING AND MAINTENANCE Clean the reservoir periodically to maximize plant growth and to minimize system contamination. The steps that follow can be used to change nutrient solution and to pump the reservoir for cleaning and typical maintenance. 4.
  • Page 17 OPERATIONAL AND MAINTENANCE INFORMATION Clean the Filter Screen and Housing ATTENTION: SYSTEM SHOWN MAY Regular cleaning of the filter is recommended to ensure proper flow. Filter should also be DIFFER FROM ACTUAL SYSTEM. FILTER cleaned after cleaning the reservoir to remove sediment. When a reduced flow rate is noticed, ASSEMBLY IS THE SAME.
  • Page 18 ADDITIONAL PHOTOS AND DIAGRAMS ATTENTION: Actual dimensions will vary slightly. Frame has been manufactured using tolerances that allow for easier assembly. 19" TOP VIEW 8 " " 4 " 26 " " " 118" SIDE VIEW END VIEW 112529 Revision date: 05.13.20...
  • Page 19 ADDITIONAL PHOTOS AND DIAGRAMS Item # Part # Description Quantity 112259VFRM END FRAME AND MID FRAME SUPPORT 112529HANG FRAME SIDE RAIL 112529NBRC DIAGONAL BRACES Revision date: 05.13.20 112529...
  • Page 20 ADDITIONAL PHOTOS AND DIAGRAMS These frame photos are included to provide additional assembly information. Side Rail Photo above shows side rail and end support. Side Rail Photo above shows end support with installed diagonal braces and side rails. During assembly, position side rail on Photo shows fully assembled top of all end and mid frame supports.

  • Page 21: Top View

    ADDITIONAL PHOTOS AND DIAGRAMS TOP VIEW ® PolyMax Nutrient Solution Feed Line Dutch Bucket 3/4” Tubing (typical) Overflow Return Line to Reservoir Drip Line SIDE VIEW Nutrient Solution Feed Line 3/4” Tubing (typical) Timer Air Pump Air Line Main Power Reservoir Submersible Pump Tank...
  • Page 22 ADDITIONAL PHOTOS AND DIAGRAMS Actual system, reservoir, and lid may differ from what is shown. 112529 Revision date: 05.13.20...
  • Page 23 ADDITIONAL INFORMATION DRIPPER STAKES—GETTING STARTED The easy-to-use 110407 stakes are perfect for even and consistent nutrient delivery. After filling the buckets with the selected growing medium, determine what nutrient solution is needed for your plants and mix this according to the instructions on the mixture.
  • Page 24 OPTIONAL ACCESSORIES—ADDITIONAL PURCHASE REQUIRED OPTIONAL ACCESSORIES* Depending on the plant and application, using 110010 Tomato RollerHook Assemblies and the ® 110006 or 110007 clips can save time and labor. The RollerHook components are easily ® assembled by slipping the spool between the wire ends of the hanger.
  • Page 25 OPTIONAL ACCESSORIES—ADDITIONAL PURCHASE REQUIRED INSTALLING THE 110010 TOMATO ROLLERHOOK ASSEMBLY* ® As plants mature, it may become necessary to provide adequate support. The 110010 Tomato RollerHook Assembly used with the 110006 or 110007 tomato clips provide the ® perfect support system, saving you time and money. 1.
  • Page 26 OPTIONAL ACCESSORIES—ADDITIONAL PURCHASE REQUIRED Photo shows using the 110010 RollerHook Assembly. ® 112529 Revision date: 05.13.20...
  • Page 27 PAGE RESERVED FOR CUSTOMER NOTES AND RECORDS Revision date: 05.13.20 112529...
