- Page 1 CARTS AND WAGONS 109722 ALL PURPOSE DUMP CART 12855 ©2019 All Rights Reserved. Reproduction is prohibited without permission. STK# Description 109722 All Purpose Dump Cart Revision date: 11.01.19...
-
Page 2: Care And Maintenance
CARTS AND WAGONS CARE AND MAINTENANCE • Periodically check fasteners to make sure they are in place and tight. • Clean the cart using water and mild soap. Rinse with water sprayed from a garden hose. (Tip the tub to allow the water to drain out after washing.) •... - Page 3 CARTS AND WAGONS ATTACH FRONT AXLE AND AXLE BRACE TO FRAME STEP 1: Position frame on a flat surface STEP 2: Insert the flat head fasteners STEP 3: Install washer and locknut and and place steering axle assembly on the up through the mounting holes.
- Page 4 CARTS AND WAGONS ATTACH STEERING YOKE STEP 1: Remove the washer and cotter STEP 2: Squeeze yoke ends together and STEP 3: Align mounting hole with the pin from the front axle mounting stud. slide ends between straight and angled mounting stud and release yoke, allowing Press angled front axle brace (installed in axle braces.
- Page 5 CARTS AND WAGONS ATTACH TIE BAR TO THE ASSEMBLED FRONT AXLE Yoke STEP 1: Take the tie bar (see below) and STEP 2: Insert one of the three remaining STEP 3: Verify that the shoulder is through place it on top of the yoke as shown. Ends shoulder bolts up through the yoke and the yoke and tie bar and add the washer will be under the tie rod ends of the axle.
- Page 6 CARTS AND WAGONS ATTACH TUB LATCH AND REAR AXLE COMPONENTS STEP 1: Position tub on a flat surface. STEP 2: Hold the bolt heads with a STEP 3: Place the rear axle on the tub. Insert pan head bolt from the inside and screwdriver and slightly tighten nuts.
- Page 7 CARTS AND WAGONS ATTACH FRONT AXLE AND FRAME TO TUB STEP 1: Carefully place front axle and STEP 2: Align the mounting hole in the STEP 3: Add the washer and locknut and frame assembly onto tub. Press and release frame with the hole in the tub.
- Page 8 CARTS AND WAGONS INSTALL WHEELS AND TUB HANDLE STEP 1: Remove wheel locknut and washer STEP 2: Ensure valve stem is to the STEP 3: Tighten locknut. Repeat these from axle and slide wheel onto axle. outside and add washer and locknut. steps for the remaining wheels.
- Page 9 CARTS AND WAGONS TEST CART DUMPING OPERATION STEP 1: Press latch to release tub. STEP 2: Carefully lift tub to dump STEP 3: Lower tub and lock in place contents. Do not stand behind tub when using latch. Verify that the latch jaw locks dumping.
