PICTORIAL PARTS GUIDE—CONTINUED
FAG102B FALF15B
FAPA14 AC2804
WF1574
WF1970
Porthole Cover
4
Important Information
FALB04B
106742
113372 Purple Primer
110729 111074
WF3411
Reservoir Reservoir Cover
PVC PRIMER & CEMENT
Follow all directions printed on pvc primer and
cement containers. Purple color of primer
does not fade! Use caution during application
WF6990
to reduce spills and over application at joints.
PVC Cement and
Prime all joints before assembly.
112604
112066 (1) Shut-
off to attach to
WF1023 filter.
WF1384 WF6627
ATTENTION: Reservoir and lid
style shown throughout this guide
may vary. When needed, critical
dimensions are noted for hole
locations.
WR1095
Tape
112603
111049 Perlite
112529 Revision date: 05.13.20
