FarmTek PolyMax H1-10 Manual page 7

3
MARK AND DRILL BUCKET DRAIN HOLES
Complete these steps:
1. With the drain tube in place on the frame, snap a chalk line from end-to-end along the top of the drain tube.
2. Next measure 6" in from one end and mark the position on the chalk line.
6" 12" 12"
3. From the 6" line measure 12" and mark that position.
4. Continue marking hole locations at 12" intervals until you reach the end of the tube. There will be ten (10) hole locations in all–one for each Dutch bucket.
5. Take a 1" hole saw and drill the 10 drain holes in the pvc drain tube. Keep all holes aligned and centered on the chalk line.
6. Remove the tube from the frame and clean all debris from the drain tube and from around the drain holes.
7. Slide the tube through the clamps and into position on the frame and add the buckets. Adjust the tube as needed to allow the end buckets to set on the
side rails of the frame. See photo above.
8. Continue with the next procedure.
Revision date: 05.13.20 112529
Assembly Instructions
Hole Spacing for Dutch Buckets
Required Tools:
• Drill with a 1" hole saw. Example shows using a
step bit. Keep holes aligned and uniform.
• Marker, chalk line, and tape measure
WF4140 PVC Tube: 120"
Chalk Line
6"
STEP 7
7
