- Page 1 CARTS AND WAGONS 109722 ALL PURPOSE DUMP CART 12855 ©2022 All Rights Reserved. Reproduction is prohibited without permission. STK# Description 109722 All Purpose Dump Cart Revision date: 07.11.22...
-
Page 2: Safety Precautions
CARTS AND WAGONS • Inflate the tires to the proper level as indicated REQUIRED TOOLS on the tires. Inflate the tires with air only. Never The following list identifies the main tools needed use a flammable gas to inflate the tires. for assembly. - Page 3 CARTS AND WAGONS PROVIDED PARTS Handle Bolt, Nut, and Rear axle Washer Nuts, Bolts, and Washers Handle Wheels Wheel Washers Rear Brace Wagon Tub Wheel Nuts Hitch Pre-Assembled Frame Coupler Revision date: 07.11.22...
- Page 4 CARTS AND WAGONS ATTACH PRE-ASSEMBLED FRAME TO TUB STEP 1: Turn tub upside down and position on a STEP 2: Fit the pre-assemble frame onto the bottom STEP 3: Slide the axle into the whole in the back of flat surface. of the tub.
- Page 5 CARTS AND WAGONS ATTACH PRE-ASSEMBLED FRAME TO TUB (continued) STEP 6: Insert the round head bolts up through the STEP 4: Slide angled rear axle braces onto the STEP 5: Line the holes in the braces with the holes mounting holes. axle.
- Page 6 CARTS AND WAGONS ATTACH LATCH STEP 2: Insert the round head bolts STEP 3: Add the washers and locknuts. STEP 1: Line the hitch up to the holes on through the mounting holes. the front of the tub. Make sure the hooks are grabbing the bar on the pre-assembled frame.
-
Page 7: Install Wheels
CARTS AND WAGONS INSTALL WHEELS STEP 1: Slide a wheel on the axle. STEP 2: Add a wheel washer and locknut. STEP 3: Tighten locknut until snug. Turn Ensure the valve stem is to the outside. the wheel to make sure the wheel still turns freely. - Page 8 CARTS AND WAGONS INSTALL TUB HANDLE STEP 2: Insert the long hex head bolt STEP 3: Add the washer and locknut. STEP 1: Determine the desired handle through the yoke, coupler, and handle orientation, slide coupler onto end of the mounting holes.
- Page 9 CARTS AND WAGONS TEST CART DUMPING OPERATION STEP 1: Press latch to release tub. Carefully lift tub to dump contents. Do not STEP 2: Lower tub and lock in place using latch. Verify that the latch jaw stand behind tub when dumping. locks around the frame bar to prevent unwanted dumping of the tub contents when moving or while loading.
