17.3.1

Setup Ctrl P1/2 - Reversing the P2 Master Fader

Some operators who use the Preset faders while running a show prefer to move the
two Preset Master faders together, to crossfade between Presets. To allow this on an
Event 4 the Preset 2 Master fader can be reversed so that at the top of its travel output
from Preset 2 is zero (0) and at the bottom of its travel the output is 100%.
P1/2
Norm
Rev
17.3.2 Setup Ctrl DBO – Changing DBO operation
The Dead Blackout button (DBO) scales all intensity channels to zero.
DBO
Momt
Ltch
17.3.3 Setup Ctrl Smast – Using the Hold Master
This field sets the function of the Hold master fader.
SMast
Hold
Asgn
Xfade
25/11/02
Set P1/2 dbo Smast
Ctrl Norm Momt Hold
This field can be set to:
The P1 and P2 faders both move from zero at the bottom to 100% at the
top.
The P2 fader moves from 100% at the bottom to zero at the top.
Set P1/2 dbo Smast
Ctrl Norm Momt Hold
This field can be set to:
All intensity channels are Blacked Out only while the DBO button is held
down.
The DBO button must be pressed once to BlackOut and again to restore
intensity.
Set P1/2 dbo SMAST
Ctrl Norm Momt Hold
This field can be set to:
Pressing the button above the Hold fader takes a snapshot of the console
output and retains that information until the button is pressed again. The
fader can be used to fade the intensity of this snapshot in and out.
The Hold fader scales the intensity of all Assign master faders.
The Hold fader can be used to crossfade between any 2 memories on the
Assign faders as follows:
1. Press and hold the Sample button above the Hold fader.
2. Press the Flash button beneath any of the Assign faders.
3. Release both buttons.
4. Move the Hold fader up to fade in the chosen Memory.
Chs Stack
Normal Single
Chs Stack
Normal Single
Chs Stack
Normal Single
Draft
Software Version 5.0
Page 67
