JANDS – Event 4 Version 5 Users Manual

4 Software Setup

4.1

Setting the Number of Fader Channels

The console defaults to 2 Preset mode with Fader 1 patched to DMX channel 1, Fader
2 patched to DMX channel 2 and so on.
The Setup Desk Wide submenu is used to double the number of Fader channels
available on the console by combining all faders into a single preset. This menu is also
used to create additional (virtual) Faders that can be controlled using the numeric
keypad.
Press the Setup button to open the Setup menu.
Move the cursor to the Desk field and press the + (On) button to open the Set Desk
menu.
Move the cursor to the Wide field and press the + (On) button to open the Set Desk
Wide menu.

4.1.1 Setting the Physical Faders

To use all the Faders as a single preset move the cursor to the Presets field and
change this field to Single to allow all the Preset faders to be used as a single preset.
Move the Cursor to the Confirm field and Press the + (On) button to confirm the
changes.
When the console is in Single Preset Mode the Preset switch (located above the
Fixture fader in the master section) is used to swap the flash buttons between the
upper and lower sets of faders.
Once a console has been set to Single Preset Mode the Preset 2 faders are used to
control the higher numbered channels. For example, on an EVENT 408 the Preset 2
faders would control channels 25 to 48. The Preset 2 Master fader is disabled.

4.1.2 Setting Additional Virtual Faders

Move the Cursor to the Faders field and enter the total number of Fader channels
required (1 – 240).
Move the Cursor to the Confirm field and Press the + (On) button to confirm the
changes.
Fader channels numbered higher than the number of physical faders must be
controlled using the Fader (Next), And, At and Thru buttons combined with the
numeric keypad. Refer to section 8.2 for details.
Virtual Faders default to being scaled by the P1 master. However they can be set to
being scaled by the P2, P1 and P2, or Hold master. Refer to section 8.2 for details.
Page 14
Set Desk Ptch Ctrl Heat Rec
Up +to| +to| +to| +to| +to| +to| +to|
Set Mode Wide Link Display Midi
Desk Rec +to| +to|
Set Presets Faders
Wide Dual
Revision 5.0.0.5
Pref Bkup
+to| +to|
Confirm
24 Off
25/11/02
