RS 485 communication(option)
CS2 series supports Modbus RTU mode protocol to be used as Remote
Terminal Unit (RTU) for monitoring and controlling in a SCADA
(Supervisor Control And Data Acquisition) system. The baud rate can be
up to 38400 bps. It's not only can be read the measured value and DI
(external control inputs) status but also controls the relays output (DO)
by RS485 communication ports.
CS2-PR & SC2-RL APPLICATION MEASURING & RS485 COMMUNICATION
RS 485 Modbus RTU Mode (up to 38400bps)
Analog Output 0~10V/0(4)~20mA
4 Relay outputs:
Functions: Hi(Lo) alarm / Hi(Lo)
COM COM
R L 1 R L 1
R L 2 ECI1 R L 2 ECI1
RL3 RL3
ECI2 ECI2
RL4 RL4
ECI3 ECI3
ENT/FN ◄ ▲ ▼ Kg/cm 2 ENT/FN ◄ ▲ ▼ Kg/cm 2
3 External Control Inputs:
Functions: Relative PV / PV hold / Reset for
Application: Leakage test / Thermal Switch /

ERROR MESSAGE
BEFORE POWER ON, PLEASE CHECK THE SPECIFICATION AND CONNECTION AGAIN.
SELF-DIAGNOSIS AND ERROR CODE:
DISPLAY
ovfl
Display is positive-overflow (Signal is over display range)
-ovfl
Display is negative-overflow (Signal is under display range)
ADC is positive-overflow (Signal is higher than input
ovfl
high
ADC is negative-overflow (Signal is lower than input
-ovfl
-20%)
eep fail
EEPROM occurs error
aiCng pv
Calibrating Input Signal do not process
aic fail
Calibrating Input Signal error
aoCng pv
Calibrating Output Signal do not process
aoc fail
Calibrating Output Signal error
RS485 wiring 1.2KM maximum
Terminate Resistor:
energized hold / Go
function / DO function
Max(Mini) / Reset for relay latch / DI
Circuit Breaker / Push Button / ...
DESCRIPTION
20%)
CS2-PR-2008-05-14
Remote Display:
The meter will show the value that received from RS485 command. In
past, The meter normally receive 4~20mA or 0~10V from AO or digital
output from BCD module of PLC .We support a new solution that PV
shows the value from RS485 command of master so that can be save
cost and wiring from PLC.
When the [ dsply] set to be RS485, it means, the PV screen will show the
number from RS485 command & data. The data(number) will be same as
PV that will compare with set-point, analogue output and ECI functions so
that is to control analogue output, relay energized and so on.
COM COM
R L 1 R L 1
R L 2 R L 2
ECI1 ECI1
RL3
ECI2 RL3 ECI2
RL4 ECI3 RL4
ECI3
2
ENT/FN ◄ ▲ ▼ Kg/cm ENT/FN ◄ ▲ ▼ Kg/cm
System calibration by front key. The process of calibration,
Calibration
please refer to the operating manual
Optional Function
Customize function with quantities is welcome. Please contact with our
sales for detail. The appendix code of optional function will be added
behind the code of auxiliary power as like as xxx-A-HSM.
