The reply to this command will be the same as the reply to the status poll query except the command
code will be '36h'.
REFLECT DISPLAY COMMAND.
This command causes the RC2000 to report 1) the contents of the controllers display (80 characters in
a 2 row by 40 column format), 2) the position of the cursor (row and column), and 3) any active alarms.
The command contains 5 bytes ...
byte 0
byte 1
byte 2
byte 3
byte 4
The response contains 91 bytes ...
byte 0
byte 1
byte 2
byte 3-42
byte 43-82
byte 83
byte 84,85
byte 86
byte 87,88
byte 89
byte 90
CONFIG WRITE COMMAND
This command writes CONFIG mode data to the controller's non-volatile memory. The command
contains 13 bytes. Here is the format of the command ....
byte 0
byte 1
byte 2
Research Concepts, Inc. • 5420 Martindale Road • Shawnee, Kansas • 66218-9680 • USA
sent will remain 'depressed' until the timer expires. The default
timer interval is one second. The user can alter this via the Pol
Motor Jog Duration CONFIG mode item. If the last two digits
of the 'Jog Duration parameter are between 2 and 25 the jog
interval will be the value specified by the last two digits
multiplied by 100 milliseconds. For example, a 'Jog Duration
value of 1015 will result in a timer interval of 1500 milliseconds
or 1.5 seconds.
The resolution of the timer is approximately +/- 150
milliseconds.
STX
A the RC2000's address
37h reflect display command code
ETX
checksum
ACK
A where A is the RC2000's address
37h reflect display command code
row 1 40 ASCII characters displayed on row 1 of the LCD
row 2 40 ASCII characters displayed on row 2 of the LCD
cursor row cursor row position, ASCII '1' or '2'
cursor column ASCII ' 1' through '40', byte 84 contains the most significant
digit
cursor status ASCII '0' or '3' => cursor off, '1' => cursor on and blinking, '2'
=> cursor on but not blinking.
alarm code ASCII ' 1' through '22', byte 87 contains the most significant
digit of the alarm code, byte 88 contains the least significant
digit of the alarm code. The alarm codes are as defined for
bytes 30 and 31 of the Device Status Poll Command.
ETX
checksum
STX
A where A is the RC2000 address
38h the command code
