- Page 1 PARAVAN WHEELCHAIR SERIES Operating instructions PR 25 V1.40...
- Page 2 Valid for the following models: Paravan PR 25 Publisher and Copyright: PARAVAN GmbH Date of issue: 1.7.2020 Document number: PR 25_V1.40 EN...
- Page 3 Dear Customer, We would like to thank you for choosing our PARAVAN power wheelchair in the PR series. In these operating instructions you will receive all the important information and instructions regarding your new power wheelchair. We would like to ask you to carefully read the following to ensure that your power wheelchair will continue to work without problems for many years to come.
-
Page 4: Table Of Contents
Contents General Legal notice ......................15 Your manufacturer ........................15 1.1.1 Copyright ..........................16 1.1.2 Technical status of documentation ..................16 Regarding these operating instructions ...............17 Exclusion of liability ......................... 18 2.1.1 Guarantee ..........................19 2.1.2 Technical modifications ......................20 Target group ..........................22 Explanation of symbols ...................... - Page 5 Road-safe in accordance with The Road Traffic Licensing Act (StVZO) ......45 6.6.1 § 24 Special means of transportation ..................45 Overview of the PARAVAN power wheelchair ............46 Definition of terms for parts and their locations ..............46 Parts and their installation position, chassis ................. 47 Prepare Handover of the power wheelchair ...............49...
- Page 6 Settings on the power wheelchair, electronic ............50 Settings on the power wheelchair, mechanical .............51 10.1 Receiving your new power wheelchair ................... 51 10.2 The armrest pad ........................52 10.2.2 Set the horizontal position of the armrest pad ..............53 10.3 Armrest .............................
- Page 7 13.6.1 Braking systems on the power wheelchair ................68 13.7 Braking the power wheelchair ....................69 13.8 Travelling on hills, up and downhill travel ................70 13.9 The drive programs / movement levels .................. 71 13.10 Manual driving, push mode ..................... 72 13.10.1 Operation of the brake lock release lever (emergency release) ...........
- Page 8 Controls ......................97 15.1 Control panel R-NET CJSM2 ....................97 15.1.1 Overview of the control elements ................... 97 15.1.2 Status display ........................... 98 15.1.3 Start, switch off ........................99 15.1.5 Switch direction indicator on and off ..................100 15.1.4 Switch light on and off ......................100 15.1.6 Switch hazard lights on and off ....................
- Page 9 15.2.11 Set time/date ........................... 119 15.2.12 Show/hide clock, configure 12h/24h display ................. 120 15.2.13 Adjust the display background and brightness ..............121 15.2.14 Adjust display brightness ......................121 15.2.15 Block the controls (with the wheelchair switched on) ............122 15.2.16 Release the controls (with the wheelchair switched off) ............
- Page 10 20.3 Overload protection ......................... 135 20.3.1 Reset the triggered overload protection: ................135 20.4 Connection option for auxiliary units ..................136 20.5 The lighting installation ......................137 20.6 Maintenance-free storage batteries ..................138 20.7 Information regarding storage batteries ................139 20.8 Charging the PR 25 ........................
- Page 11 List of illustrations Fig. 1: QR code ............................ 15 Fig. 2: Direction of travel ........................17 Fig. 3: Safety instruction ........................24 Fig. 4: TÜV logo ........................... 35 Fig. 5: Type plate ..........................38 Fig. 6: Location of type plate ......................39 Fig.
- Page 12 Dahl Adaptionkit for Dahl Docking Station ................86 Fig. 44: Torx TX 27 ..........................86 Fig. 45: Paravan knurled screws ......................87 Fig. 46: Paravan rear and side trim ...................... 87 Fig. 47: Main cable battery ........................88 Fig. 48: Remove batteries ........................88 Fig. 49: Position of the Dahl system ....................
- Page 13 Fig. 59: Light on and off ........................100 Fig. 60: Turn signal right / left ......................100 Fig. 61: Light symbol (colour)....................... 100 Fig. 62: Hazard lights on / off ....................... 101 Fig. 63: Symbols (colour) ........................101 Fig. 64: Driving functions ........................
- Page 14 Fig. 88: Driving functions ........................115 Fig. 89: Driving function blocked ......................115 Fig. 90: Select drive program ........................ 116 Fig. 91: Joystick travelling direction ....................116 Fig. 92: Display of seat functions ......................117 Fig. 93: CJSM seat lowering function display ..................118 Fig.
-
Page 15: Legal Notice
Legal notice Your manufacturer PARAVAN GmbH Registered office / headquarters / production Paravanstraße 5-10, D-72539 Pfronstetten-Aichelau > Tel.: 0 73 88 / 99 95-91 > Fax: 0 73 88 / 99 95-999 > Email: info@paravan.de > Internet: www.paravan.de > Managing Director: Mr. Roland Arnold Many smartphones and tablets have built-in cameras and Fig. 1: QR code... -
Page 16: Copyright
Federal Republic of Germany of 9 September 1965. Such reproduction is generally subject to a fee. Contraventions are subject to the penal provisions of the Copyright Act. > Copyright © PARAVAN GmbH 2020. All rights reserved! 1.1.2 Technical status of documentation All technical data/specifications, illustrations and information in these operating instructions were correct at the time of printing in February 2020. -
Page 17: Regarding These Operating Instructions
Regarding these operating instructions These operating instructions do not constitute a maintenance and repair manual and therefore are not suitable to use for the private carrying out of maintenance and repair work, or to provide instruction on this. You will receive information on the design and the operation of the product throughout its entire life cycle –... -
Page 18: Exclusion Of Liability
The operation of the power wheelchair without faults or malfunctions can only be guaranteed if the knowledge gained from these operating instructions is observed and implemented. PARAVAN GmbH assumes no liability or warranty for damage or operating faults resulting from non-compliance with these operating instructions or from modifications to the power wheelchair. -
Page 19: Guarantee
2.1.1 Guarantee Guarantee services are based entirely on the respective PARAVAN guarantee provisions. Excluded from guarantee claims is damage which has occurred due to: > Wear > Improper operation or use, e.g. overloading > Incorrect/infrequent maintenance > Incorrect/infrequent care See your personal “guarantee card”. -
Page 20: Technical Modifications
All modifications must be authorised or carried out by PARAVAN GmbH. PARAVAN GmbH reserves the right to undertake technical modifications and improvements to the product in the interest of our customers and progressive development. - Page 21 WARNING Danger of injury for persons operating a power wheelchair which does not correspond to the original or delivered condition. Material damage to the power wheelchair by the use of non- authorised parts or incorrectly installed parts. > Do not make any technical modifications to the power wheelchair.
-
Page 22: Target Group
Target group The operator must acquire or gain a level of knowledge relating to the following points before operating the power wheelchair: > Knowledge of the content of the operating instructions in order to safely operate and also be able to move the power wheelchair. >... -
Page 23: Explanation Of Symbols
Explanation of symbols When reading the operating instructions you will encounter the following symbols and warning symbols. The “Caution Danger!” logo highlights hazards. The protective measures specified in the respective text must be followed in all cases. This symbol is always used together with the appropriate signal word that describes the degree of danger: >... -
Page 24: Structure Of Safety Notes
2.3.1 Structure of safety notes You can obtain the following information from the safety notes: > Warning or danger symbol . > Type and source of the danger . > Signal word . > Consequences of hazard occurring . > Protective measures . -
Page 25: Safety Notes
Safety notes Generally applicable safety notes 3.1.1 Operation instructions For your protection and for the protection of people in your vicinity and of the environment, the following safety instructions must be observed and followed at all times. DANGER! Danger of crushing from touching moving parts, e.g. from the rotational movement of the drive wheels or the Lifting movement of the lifting arm and horizontal movement of the seat. - Page 26 WARNING Danger of tipping for persons operating a power wheelchair when travelling at an incline of more than 10°. Danger of tipping for persons operating a power wheelchair when travelling downhill and if the sitting position is in the front position. Danger of tipping for persons operating a power wheelchair when travelling across obstacles.
- Page 27 WARNING Danger of injury for persons operating a power wheelchair which does not correspond to the original or delivered condition. Material damage to the power wheelchair by the use of non- authorised parts or incorrectly installed parts. > Do not make any technical modifications to the power wheelchair.
- Page 28 WARNING Danger of injury for persons while travelling with a power wheelchair on rough ground. Danger of falling and tipping for persons while operating the power wheelchair on ground with diminished load bearing capacity. Material damage to the power wheelchair from mechanical and physical influences while travelling on rough ground.
-
Page 29: Information Regarding Use
3.1.2 Information regarding use CAUTION Material damage to the power wheelchair from overloading the vehicle. Material damage to the power wheelchair from the effect of high temperatures above 41°C. Material damage to the power wheelchair from overcharging of the batteries when travelling downhill. >... -
Page 30: Information Regarding Transport
3.1.3 Information regarding transport CAUTION Material damage to the power wheelchair by it slipping from the ramp or from the lift while loading. Material damage to the power wheelchair by improper securing or transport in the power wheelchair transporter. > Secure the ramp against slipping. -
Page 31: Performance Description
Our products are checked for faults after their manufacture. If a fault with your power wheelchair nevertheless still arises, we request that you contact your dealer or PARAVAN GmbH directly so that the fault can be dealt with. -
Page 32: Correct Use
Correct use The PARAVAN power wheelchair's function and design are intended to transport a person indoors and outdoors. The control panel including joystick or optional operating units in the case of/for special operation is the interface relating to user operation and the liability of the manufacturer for the power wheelchair. -
Page 33: Usability Of The Power Wheelchair
4.2.1 Usability of the power wheelchair - unproblematic > Transport of a person with a maximum body weight of 160kg. > Use as driver's or co-driver's seat, depending on the equipment variant. > Use within the German road traffic regulations (“StVO”), assuming complete and intact lighting. -
Page 34: Clearance Declaration For Non-Dangerous Goods (Storage Battery)
4.2.2 Clearance declaration for non-dangerous goods (storage battery) PARAVAN GmbH uses storage batteries which are classified as “non-dangerous goods”, as long as these storage batteries are not mechanically damaged in any way. The maintenance-free non-woven lattice storage batteries and the maintenance-free lead gel storage batteries are leak-proof, and in accordance with >... -
Page 35: Approvals, Certifications
EU approval as driver's seat The seat belt anchorage is certified and approved according to 76/115/EEC, as is the seat in terms of its anchorage according to 74/408/EEC with the PARAVAN docking system. DANGER! Potential risk of injury or serious injury or death... -
Page 36: German Regulations On Assistive Technology (Hilfsmittelverordnung, Hmv No.)
4.3.2 German regulations on assistive technology (Hilfsmittelverordnung, HMV no.) PARAVAN power wheelchairs are approved in accordance with the assistive technology guidelines: > Kassenarztrecht in Nordwürttemberg – Richtlinien und Normen und Verordnungen und Leistungen (Panel doctors law in Northern Württemberg - guidelines and standards... -
Page 37: Indication
4.3.4 Indication The power wheelchair with lift function is used for people who are unable to walk or have a severe walking disability: > Microsomia (dwarfism) > Paralysis > Joint contractions/joint damage (not on both arms) > other conditions 4.3.5 Contraindication The provision of power wheelchairs is unsuitable for persons with: >... -
Page 38: Product-Specific Data
Product-specific data Trademark and type designation (type plate) This information can be found on the type plate. It is very important to provide this in any correspondence with PARAVAN GmbH so that you receive relevant professional advice. >... -
Page 39: Location Of The Type Designation (Type Plate)
Location of the type designation (type plate) The type designation (type plate) is affixed to the PR 25 in a 1-fold design. The type designation (type plate) has dimensions of approx. 70mm x 40mm. > The type designation (type plate) is situated on the rear right of the battery box ... -
Page 40: Information On Your Power Wheelchair
Information on your power wheelchair Please ensure that this information is recorded upon the handover of the power wheelchair, or if necessary enter the information yourself, so that you always have it to hand. Day of delivery/supply > Supply by (dealer or branch) >... -
Page 41: Accessories
Accessories 5.4.1 Supplied accessories > Charger with charging cable. > Operating instructions. > Socket wrench with T-handle, SW 13. > Allen key, size 5. > Magnetic key, optional according to equipment. Fig. 7: DAHL docking station 5.4.2 Deliverable accessories > DAHL docking station for quick and easy fastening of the PR 25 in a vehicle. -
Page 42: Description/Function Of The Power Wheelchair
Description/function of the power wheelchair The special orthopaedic seat K120 The special orthopaedic seat K120 is an in-house development by PARAVAN GmbH that has been tailored to the precise needs of its customers. It is equipped with: > Integrated 3-point belt >... -
Page 43: Joystick Control
A multitude of special controls such as e.g.: > chin control, > environmental control, > etc. can be implemented on the PARAVAN power wheelchair. If you have requests or suggestions for us regarding this, do not hesitate to contact us. Thank you. Description/function of the power wheelchair... -
Page 44: Tilt Function (Seat Angle, Optional)
Tilt function (seat angle, optional) The PR 25 is optionally equipped with a tilt function. The tilting process can be interrupted and fixed in any direction of movement and at any position. The seat tilt (angle) can be set as follows at the touch of a button: >... -
Page 45: Road-Safe In Accordance With The Road Traffic Licensing Act (Stvzo)
Road-safe in accordance with The Road Traffic Licensing Act (StVZO) The PR 25 is a road-approved vehicle that includes the following features as standard equipment: > LED headlights for optimum illumination . > LED direction indicator . > LED rear lights for the best possible visibility . >... -
Page 46: Overview Of The Paravan Power Wheelchair
Overview of the PARAVAN power wheelchair Definition of terms for parts and their locations The following terms for parts or individual parts are used in the operating instructions. Their location on the power wheelchair is shown in the illustration. >... -
Page 47: Parts And Their Installation Position, Chassis
The installation position on the power wheelchair's chassis is shown in the diagram. > Seat plate > Seat guides > Rear wheel > Battery box > Actuator module Fig. 12: Parts, chassis rear Overview of the PARAVAN power wheelchair... -
Page 48: Fig. 13: Parts, Chassis Front
> Footplates > Anti-tipper, support > Drive wheel > Control units > Rigging eye > Main fuse Fig. 13: Parts, chassis front Overview of the PARAVAN power wheelchair... -
Page 49: Handover Of The Power Wheelchair
Receiving your new power wheelchair Check your power wheelchair for completeness and compare the items received with the delivery with your order documents. If anything is unclear, contact PARAVAN GmbH immediately! Check (visually inspect) that the power wheelchair is in proper condition. Report damage which can be attributed to delivery or transport immediately and in writing to your >... -
Page 50: Settings On The Power Wheelchair, Electronic
Settings on the power wheelchair, electronic The setting and configuration of the PARAVAN control unit is very complex and, for your own safety, can only be undertaken by your service technician. All parameters of the PARAVAN control unit can be subsequently set to your requirements and desires. -
Page 51: Settings On The Power Wheelchair, Mechanical
All mechanical parts or equipment and control elements are set to your body dimensions. If adjustment is still needed however, this can be undertaken at any time. Your PARAVAN power wheelchair is designed in such a way that it can be adjusted to the body dimensions in all requirements. -
Page 52: The Armrest Pad
10.2 The armrest pad The angle of the armrest pad can be tilted. It can also be adjusted horizontally forwards or backwards, allowing it to be adapted for any purpose and to every body size. When standing up or moving, please do not lean on the armrest on one side with your full body weight 10.2.1 Set the angle of the armrest pad. -
Page 53: Set The Horizontal Position Of The Armrest Pad
10.2.2 Set the horizontal position of the armrest pad These instructions apply to both the right and left sides. Proceed as follows to check and set the position of the armrest pad: > Loosen the wing bolt . > Push the armrest pad forwards or backwards to the desired position. -
Page 54: Armrest
10.3 Armrest The armrest is multi-horizontal in all directions (projection) and can be vertically adjusted or adjusted at an angle, and thus can be adapted to every body measurement. Changing the position of the armrest potentially involves using another setting! Proceed as follows to check and set the position of the armrest: >... -
Page 55: Set The Height Of The Armrest
10.4 Set the height of the armrest These instructions apply to both the right and left sides. Turning the hand-operated wheel to the left releases the armrest, thereby enabling its height to be adjusted. When the desired height is reached, turn the hand-operated wheel to the right and pull it tight. -
Page 56: Set The Angle Of The Armrest
10.5 Set the angle of the armrest The armrest is pivoted on the attachment point. This allows the complete armrest to be swung upwards for comfortable sitting and standing or moving from the wheelchair's seat. Fig. 18: Armrest angle Settings on the power wheelchair, mechanical... -
Page 57: Set The Projection Of The Armrest
10.6 Set the projection of the armrest This work instruction applies to the right and left sides; it is possible that the rotational direction of the screw connection is reversed! Proceed as follows to check and set the projection of the armrest: >... -
Page 58: Setting The Mobility Of The Control Panel
10.7 Setting the mobility of the control panel The horizontal swivel mechanism of the control panel can be set in relation to the degree of hardness (response behaviour or the mobility of the joints). The degree of hardness can only be set via your service technician! Fig. -
Page 59: The Special Orthopaedic Seat K120, Operation
The special orthopaedic seat K120, operation 11.1 Adjusting the backrest 11.1.1 Adjusting the backrest angle The backrest or the backrest angle can be adjusted electrically via the PARAVAN control panel. > Select menu in the control unit. > Select the settings. See section “15 Control”... -
Page 60: Adjusting The Headrest
11.2 Adjusting the headrest If you need to adjust the headrest in the head area, you can adjust the height of the headrest individually in 5 incremental steps. The following setting options are available: Tilt adjustment: > Push the headrest to the desired tilt → Push the top of the headrest backwards or forwards. -
Page 61: Attaching And Removing The Chassis Trim
Attaching and removing the chassis trim 12.1 Attaching and removing the rear trim The chassis trim can be removed for maintenance / servicing or cleaning. To attach and remove the rear trim, proceed as follows: > Loosen and unscrew the knurled screws. Set the knurled screws and plastic shims to one side. -
Page 62: Attaching And Removing The Side Trim
12.2 Attaching and removing the side trim The chassis trim can be removed for maintenance / servicing or cleaning. To attach and remove the side trim, proceed as follows: > Loosen and unscrew the knurled screws . > Remove the rear trim. ... -
Page 63: Driving With The Power Wheelchair
Driving with the power wheelchair 13.1 Insurance, liability insurance We recommend that you speak with your insurance advisor before starting to use the power wheelchair so that its use is included in your insurance - in particular in your liability insurance. Please note that a legal requirement may exist to insure the power wheelchair during use in road traffic within the context of the respective legal provisions. -
Page 64: Function Check Before The Trip
13.2 Function check before the trip Before commencing each trip, the following points must be checked for your own safety: It might be necessary to draw on the expertise of a second person for the check. > Function check of the brakes. The brake lock release lever ... -
Page 65: Putting On The Seatbelt
13.3 Putting on the seatbelt Listen for an audible engagement of the lock tongue in the belt buckle when putting on the seatbelt. Fig. 28: Putting on the seatbelt, logo The function of the belt buckle is the same on all belt versions such as: >... -
Page 66: Controlling The Power Wheelchair, Directions Of Travel
13.4 Controlling the power wheelchair, directions of travel The power wheelchair is controlled via the joystick on the control panel. The following basic control options are available if you put the joystick into the position below: Joystick forwards → The power wheelchair travels forwards. >... -
Page 67: Navigating Bends, Turning Corners
13.5 Navigating bends, turning corners The PARAVAN power wheelchair is equipped with front-wheel drive. This means that the rear swings out during steering motions, i.e. turning corners. This is how you navigate a bend: > Push the joystick into the required travelling position (forwards or backwards). -
Page 68: Braking With The Power Wheelchair
13.6.1 Braking systems on the power wheelchair Two independently working braking systems (safety systems) are used in the PARAVAN power wheelchair in order to guarantee the greatest possible level of safety. The functions of the individual safety systems are as follows: Safety during the trip: >... -
Page 69: Braking The Power Wheelchair
13.7 Braking the power wheelchair The braking distance i.e. the distance from initiating the braking process until the power wheelchair comes to a standstill, is heavily dependent on factors such as: > Ground or condition of the road. > Total weight (vehicle and driver) of the power wheelchair. When braking from full speed at approx. -
Page 70: Travelling On Hills, Up And Downhill Travel
13.8 Travelling on hills, up and downhill travel You must observe the following rules for your own safety when travelling up and downhill: > Put the longitudinal seat adjustment mechanism into the furthest back position in order to avoid slipping. >... -
Page 71: The Drive Programs / Movement Levels
13.9 The drive programs / movement levels The PARAVAN power wheelchair has five different movement programmes or levels. You can select the desired movement level or final speed of the power wheelchair on the control panel. The maximum final speed in the respective movement level is reached by moving the joystick as far as it will go. -
Page 72: Manual Driving, Push Mode
13.10 Manual driving, push mode 13.10.1 Operation of the brake lock release lever (emergency release) > If you want to push the power wheelchair, you must set both brake lock release levers on the left and right drive side to “UNLOCK” (downwards). -
Page 73: Information Regarding Roads, Types Of Ground
13.11 Information regarding roads, types of ground WARNING Danger of tipping for persons operating a power wheelchair when travelling at an incline of more than 10°. Danger of tipping for persons operating a power wheelchair when travelling downhill and if the sitting position is in the front position. -
Page 74: 13.11.2 Climbing / Traversing Ability
13.11.2 Climbing / traversing ability > When travelling over obstacles that are higher than approx. 60-70 mm, you could touch the ground and get stuck or tip over with your power wheelchair with the battery box. 13.11.3 Load bearing capacity >... -
Page 75: Loading And Transporting The Power Wheelchair
Loading and transporting the power wheelchair The power wheelchair must always be shut down and correctly secured or fastened for transport in the vehicle. When loading the power wheelchair, loading aids such as > ramps, lifts and hoists with sufficient load-bearing capacity must be used. 14.1 Rules for loading wheelchairs The following rules must be observed for and during loading:... -
Page 76: Securing And Fastening The Power Wheelchair
14.2 Securing and fastening the power wheelchair The power wheelchair must be connected or tied to the transport vehicle with tightening straps, hooks or loops in order to prevent slipping. The power wheelchair must be fastened in accordance with the guideline >... -
Page 77: Putting On The Seatbelt In A Moving Vehicle
14.3 Putting on the seatbelt in a moving vehicle WARNING The 3 or 4-point belts integrated into the wheelchair should not be used as personal restraints in a moving vehicle. Instead, an approved seatbelt system anchored into the vehicle should be used to safeguard the passenger. -
Page 78: Securing The Wheelchair With A 4-Point Belt Restraint System
14.4 Securing the wheelchair with a 4-point belt restraint system Tension belts compliant with ISO 10542-1 are only tested up to 85 kg plus the weight of the person. It is recommended that a 4-point belt restraint system be used that is designed for the total weight of the wheelchair including all options, 2 at the front and 2 at the rear, which comply with ISO 10542-1. -
Page 79: Instructions For Securing Passengers
14.5 Instructions for securing passengers > Use a personal restraint system anchored into the car to protect passengers. > Both lap and upper body restraint belts must be used to safeguard passengers in order to reduce the risk of head injury. >... -
Page 80: Fig. 39: Positioning Of The Safety Belt When Used With The Dahl Docking Station
> The upper body restraining belt must pass over the shoulder and chest, as shown in Fig. 47. > The belt strap of the restraining belt must not be twisted during use. > When putting on the passenger restraint system, care must be taken to ensure that the belt buckle is positioned so that the release button is not touched by wheelchair components in the event of a collision. -
Page 81: Unlocking The Docking Station
14.6 Unlocking the Docking Station > 1. When the vehicle has come to a standstill, remove the seat belt. > 2. To unlock it, move the wheelchair forward slightly to release the pressure on the locking pin. Next, press the red release button on the control panel. The locking pin is triggered/released for approx. 5 seconds, after which the locking pin is automatically locked/activated again. -
Page 82: Installing The Dahl Docking Station
PR 40, PR 25, PR Piccolino, PR Biolution and PR Heavy Duty. The following instructions explain how to install the Dahl Docking Station MK II and VarioDock™ on the wheelchair using the PARAVAN adaptation kit. Please also refer to the Dahl Engineering's instructions for the installation, use and maintenance of the vehicle. - Page 83 WARNING Risk of injury due to incorrect handling of the batteries. Material damage due to improper handling of the batteries. > Handle the batteries with particular care. > Coupling and uncoupling may only be carried out by qualified personnel. > Keep away from fire.
-
Page 84: Contents Of The Dahl Docking Stations
14.7.1 Contents of the Dahl Docking Stations Fig. 41: Contents of Dahl Docking Station MK II Standard Set # 501750 Loading and transporting the power wheelchair... -
Page 85: Fig. 42: Contents Of The Dahl Variodock™ Standard Set # 503600
Fig. 42: Contents of the Dahl VarioDock™ Standard Set # 503600 Loading and transporting the power wheelchair... -
Page 86: Attaching The Dahl Locking Plate To The Wheelchair
14.7.2 Attaching the Dahl locking plate to the wheelchair An additional wheelchair-specific adaptation kit is required for the installation of the Dahl locking plate. It contains special nuts and plastic ④ spacers to be placed inside the battery box. ⑤ ①... -
Page 87: Fig. 45: Paravan Knurled Screws
10 mm spanner. The battery box can then be tilted backwards using the hinges - be careful: the entire weight of the Fig. 45: Paravan knurled screws superstructure rests on the lid! ③ ④ Fig. 46: Paravan rear and side trim Loading and transporting the power wheelchair... -
Page 88: Attaching The Dahl Locking Plate To The Wheelchair
14.7.3 Attaching the Dahl locking plate to the wheelchair Removing the batteries: > Disconnect the main cable plug on the left and right of the batteries. > Remove the left and right batteries. Fig. 47: Main cable battery Fig. 48: Remove batteries Loading and transporting the power wheelchair... -
Page 89: Fig. 49: Position Of The Dahl System
Attaching the DAHL system: > Position the locking plate 503125 on the bottom of the wheelchair. The holes for positioning are already provided in the battery box. > Now, fix the locking plate inside the battery box with the adaptation set 502064 and screw the five countersunk screws from below with the DAHL nuts 500759. - Page 90 After the Dahl system has been attached to the wheelchair chassis, replace the batteries and reattach the cover in the reverse order. The PARAVAN adapter set can also be pushed further forwards or backwards and attached accordingly, depending on the position of the counterpart in the vehicle.
- Page 91 Use the screws supplied to attach the Dahl Docking Station to the wheelchair. DANGER Possible risk of injury or serious injury or death due to the use of incorrect screws. > Only use the screws supplied > Do not use screws other than those supplied by Dahl Engineering (order No.
-
Page 92: Functions Of The Dahl Docking Station
14.7.4 Functions of the Dahl Docking Station ① Dahl Docking Station ② Locking plate and spacer ③ Locking bolt ④ LED display red ⑤ LED display green ⑥ Control panel ⑦ Unlock button ⑧ Manual emergency release lever ⑨ Manual operating lever Fig. -
Page 93: Securing The Wheelchair In The Docking Station
14.7.5 Securing the wheelchair in the Docking Station > Drive the wheelchair slowly and in a uniform direction over the Docking Station. The locking plate under the wheelchair helps to guide the wheelchair into the Docking Station. When the locking plate is fully engaged in the Docking Station, a spring-loaded locking pin automatically secures the locking plate. - Page 94 DANGER Possible risk of injury or serious injury or death! Do not move the vehicle: > While the wheelchair is being moved into position in the Docking Station > If the wheelchair and the wheelchair user are not properly secured. >...
-
Page 95: Unlocking The Dahl Docking Station
14.7.6 Unlocking the Dahl Docking Station > When the vehicle has come to a standstill, remove the seat belt. > The unlocking process begins by moving the wheelchair forwards slightly to reduce the pressure on the locking pin. Next, press the red release button on the control panel. The locking pin is triggered/released for approx. -
Page 96: Manual Release In The Event Of An Electrical Fault
14.8 Manual release in the event of an electrical fault > 1. In the event of an electrical failure, a manual emergency release is located at the front edge of the Docking Station. Move the wheelchair forwards to release the pressure on the locking pin and slide the red release arm to the side and hold it there while the wheelchair moves backwards out of the Docking Station. -
Page 97: Controls
Controls 15.1 Control panel R-NET CJSM2 15.1.1 Overview of the control elements With the control panel (joystick) built into your power wheelchair, ⑫ you can control all of the power wheelchair's driving, steering and ③ braking processes. All additional functions which are equipped with ⑩... -
Page 98: Status Display
15.1.2 Status display The function keys are used to select the specific functions displayed in the assigned fields on the display. Symbols of the status indicator: Charging status of the storage batteries ① > > Direction indicator, left ② “On/off” light ③ >... -
Page 99: Start, Switch Off
15.1.3 Start, switch off Start ① Push the “on/off” switch ① upwards. > The status display briefly flashes and the last selected function in terms of movement level/seat function is shown. > Press the switch ① downwards again to: - Select movement levels 1 to 5 - Then switch to the seat functions Switch off Push the “on/off”... -
Page 100: Switch Direction Indicator On And Off
15.1.5 Switch direction indicator on and off Press key ① or ② for the respective direction indicator, left or right. > The selected direction indicator will flash. > Press once more → direction indicator switches off. Fig. 60: Turn signal right / left 15.1.4 Switch light on and off Press the key ... -
Page 101: Switch Hazard Lights On And Off
15.1.6 Switch hazard lights on and off Press the “hazard lights” key for the “hazard lights on” function. > The hazard lights switch themselves on, while the hazard lights symbol flashes red and both direction of travel symbols flash green. >... -
Page 102: Driving Functions Overview
15.1.7 Driving functions overview Overview of the driving functions shown on the display of the control panel during driving, steering and braking actions of the power ⑤ wheelchair. ② > Selected drive program/movement level ① ⑥ ① > Respective setting (having drilled down) for the selected movement level (1 to 5) fast/slow ②... -
Page 103: Select Drive Program, Drive
15.1.8 Select drive program, drive The power wheelchair must be in driving mode. > The last selected drive program is shown on the display (profiles 1 to 5). Drive profiles 1 to 5 are further divided into 5 levels once you drill down. -
Page 104: Electrical Seat Adjustment
15.1.9 Electrical seat adjustment Use the MODE key to switch from the drive program to the seat functions. Select the desired seat function by moving the joystick “← left/right →”. > The adjustment functions menu will appear on the display. Only the released or available functions can be selected. -
Page 105: Electric Seat-Floor Lowering (Seat-Lift Function)
15.1.10 Electric seat-floor lowering (seat-lift function) The seat lowering function allows the entire seating unit to be lowered to floor level. Use the Mode key to switch from the drive program to the “Seat Down” functions. Select the desired degree of lowering using the joystick “↑Up/Down↓”. -
Page 106: 15.1.11 Set Time/Date
15.1.11 Set time/date Press and hold the “hazard lights” key to access the “Settings” menu. > The special functions menu will appear on the display. Move the joystick → left/right to access the options “year, month, date, day of the week, hours and minutes”. Select the desired option by moving the joystick “←... -
Page 107: 15.1.12 Show/Hide Clock, Configure 12H/24H Display
15.1.12 Show/hide clock, configure 12h/24h display Select the program function: > Press and hold the “hazard lights” key. > The “Settings” menu appears. > Use the joystick to select “Set time”. Move the joystick “← left/right →”. > By moving the joystick “← Left/Right →”, select “12h/24h display” or “Off”. -
Page 108: 15.1.14 Adjust Display Brightness
15.1.14 Adjust display brightness Select the program function: > Press and hold the “hazard lights” key. > Select “Back lighting” from the settings. Move the joystick “← Left/Right →” to select the intensity of the > lighting (0 to 100% in 10% increments) >... -
Page 109: Block The Controls (With The Wheelchair Switched On)
15.1.15 Block the controls (with the wheelchair switched on) > Turn the control panel off and press and hold the ON/OFF button ① until you hear a beeping sound > Move the joystick forwards until you hear a beeping sound ①... -
Page 110: Control Panel R-Net Cjsm-L
15.2 Control panel R-NET CJSM-L 15.2.1 Overview of the control elements With the control panel (joystick) built into your power wheelchair, ⑧ ① ③ ③ you can control all of the power wheelchair's driving, steering and ⑩ ⑪ braking processes. All additional functions which are equipped with displacement motors, such as the lifting arm and the sitting functions, ⑫... -
Page 111: Status Display
15.2.2 Status display The function keys are used to select the specific functions displayed in the assigned fields on the display. Symbols of the status indicator: Charging status of the storage batteries ① > > Direction indicator, left ② “On” light ③ >... -
Page 112: Start And Switch Off
15.2.3 Start and switch off Start ① Push the “on/off” switch ①. > The last selected function in terms of movement level/seat function is shown. Switch off Push the “on/off” switch ①. > The power wheelchair switches itself off (assuming it is already switched on). -
Page 113: Switch Light On And Off
15.2.4 Switch light on and off Press key ① or ② for the respective direction indicator, left or right. > The selected direction indicator will flash. > Press once more → direction indicator switches off. ① ② Fig. 84: Turn signal right / left 15.2.5 Switch direction indicator on and off Press the key ①... -
Page 114: Switch Hazard Lights On And Off
15.2.6 Switch hazard lights on and off Press the “hazard lights” key ① for the “hazard lights on” function. ① > The hazard lights switch themselves on, while the hazard lights symbol flashes red and both direction of travel symbols flash yellow. >... -
Page 115: Driving Functions Overview
15.2.7 Driving functions overview Overview of the driving functions shown on the display of the control panel during driving, steering and braking actions of the power wheelchair. ⑤ ② ① > Selected drive program/movement level ① > Maximum speed in the selected drive program ② ④... -
Page 116: Select Drive Program, Drive
15.2.8 Select drive program, drive The power wheelchair must be in driving mode. ③ > The last selected drive program is shown on the display. ① ② Press the profile key ① to select/switch to one of the 5 movement levels (profiles). -
Page 117: Electrical Seat Adjustment
15.2.9 Electrical seat adjustment Use the “Mode key” to switch from the drive program to the seat functions. Move the joystick “← Left/Right →” to select the seat function. > The respective seat function will appear on the display. Only the functions present from the factory can be selected. ①... -
Page 118: Electric Seat-Floor Lowering (Seat-Lift Function)
15.2.10 Electric seat-floor lowering (seat-lift function) The seat lowering function allows the entire seating unit to be lowered to floor level. Use the Mode key to switch from the drive program to the “Seat Down” functions. Select the desired degree of lowering using the joystick “↑Up/Down↓”. -
Page 119: 15.2.11 Set Time/Date
15.2.11 Set time/date Press and hold the “slower” ① and “faster” ② speed keys to access the “Settings” menu. > The special functions menu will appear on the display. Move the joystick → right to access the options “year, month, date, day of the week, hours and minutes”. -
Page 120: 15.2.12 Show/Hide Clock, Configure 12H/24H Display
15.2.12 Show/hide clock, configure 12h/24h display Select the program function: > Press and hold the keys ①+②. > The “Settings” menu appears. > Use the joystick to select “Display time”. > By moving the joystick “← Left/Right →”, select “12h/24h display” or “Off”. -
Page 121: 15.2.13 Adjust The Display Background And Brightness
15.2.13 Adjust the display background and brightness Select the program function: > Press and hold the “slower” ① and “faster” ② speed keys. > Select “Back lighting” from the settings. By moving the joystick “← Left/Right →”, select the percentage >... -
Page 122: Block The Controls (With The Wheelchair Switched On)
15.2.15 Block the controls (with the wheelchair switched on) > Turn the control panel off and press and hold the ON/OFF button ① ① until you hear a beeping sound > Move the joystick forwards until you hear a beeping sound >... -
Page 123: Moving From The Power Wheelchair
Moving from the power wheelchair The following points must be followed for your own safety in order to independently move from the seat of your power wheelchair: > You should be able to safely carry your own weight. > You should be able to push yourself off from the power wheelchair with both arms simultaneously using the same amount of strength. -
Page 124: Procedure When Moving Sideways Out Of The Seat
16.1 Procedure when moving sideways out of the seat When moving sideways out of the seat, proceed as follows: > Position the power wheelchair sideways > Adjust the seat to the required height > Switch the power wheelchair off >... -
Page 125: Maintenance And Servicing
Maintenance and servicing When using and operating the PARAVAN power wheelchair according to its intended purpose, it is subject to a recommended annual maintenance plan. All driven parts and in particular the lift arm are designed so that the operation of the power wheelchair is guaranteed to be low-maintenance and fault-free. -
Page 126: Cleaning And Care
17.2 Cleaning and care You must not use a high-pressure cleaner to clean the power wheelchair. Avoid contact of the electronic parts with water. To clean the frame and the plastic components (lacquer set), only > mild soapy water without scouring agents may be used. -
Page 127: Disposal And Environmental Protection
Disposal and environmental protection The power wheelchair itself and its individual components are technically durable. In most cases, recyclable and harmless raw materials were used for its design and manufacture. After it has been taken out of service, the power wheelchair is suitable for the correct recycling procedure and economically sustainable disposal. -
Page 128: Packaging Material
18.1 Packaging material The packaging consists of largely recyclable material which is harmless to the environment, such as: > wood, e.g. pallets or outer packaging, > metal, e.g. tightening straps, > bubble wrap. Take advantage of the opportunity to recycle the packaging in an environmentally-friendly way. -
Page 129: Recommissioning
> complete cleaning. The power wheelchair must be completely cleaned and approved for use after a thorough inspection by a service technician authorised by PARAVAN GmbH. See section “18 Maintenance and servicing” Disposal and environmental protection... -
Page 130: Information Regarding Transfer Of The Product
18.3 Information regarding transfer of the product When transferring the PARAVAN power wheelchair you must also pass on all the necessary technical documents for safe handling and operation, such as: > operating instructions, > proofs of maintenance to the new user. -
Page 131: Troubleshooting
Troubleshooting 19.1 Status indicator on the control panel Error message Meaning Centre joystick / Joystick The most common cause of this error is that the joystick is not centred when the zentrieren control system is switched on. “Joystick off-centre” will appear on the display for five seconds. - Page 132 Error message Meaning Brake error / Bremsen This message appears when the control system detects a problem with the magnetic brakes or their connections. Check the magnetic brakes, cables and connections in the control system. Check that the motor brakes have not come uncoupled. Motor error / Motorfehler This message appears when the control system detects that the connection to a motor has been interrupted.
-
Page 133: Electrical System
Electrical system 20.1 Automatic fuses The PARAVAN PR 25 standing wheelchair is equipped with an automatically triggering fuse and an overload protection device. These are described in more detail below: > Main fuse: This protects the complete electrical system in the event of overloading by PR 25 electrical consumers –... -
Page 134: Main Fuse
20.2 Main fuse The main fuse is located at the rear of the power wheelchair. An active (triggered) main fuse is signalised by the swung out green lug. 20.2.1 Reset triggered main fuse Fig. 105: Main fuse, active >... -
Page 135: Overload Protection
20.3 Overload protection While travelling downhill, the generated power is diverted into the storage batteries – the drive motors work like a generator in this case. If you have fully charged your PR 25 before travelling downhill, the security system switches to emergency stop in order to avoid damage to the electrical system (control, electronics, etc.). -
Page 136: Connection Option For Auxiliary Units
20.4 Connection option for auxiliary units The PARAVAN PR 25 offers the option of connecting different auxiliary units with a voltage of 12 volts or 24 volts to the PR 25 on-board power supply. If you require special equipment, e.g. a respirator, for this connection, please contact PARAVAN GmbH. The external connections are individually adjusted for the respective consumer and the cable harness is cut to size or moved in position. -
Page 137: The Lighting Installation
20.5 The lighting installation The PARAVAN PR 25 is equipped with a lighting installation featuring LED technology that is fully approved for road traffic. Due to the LED lamps used, the wearing out or maintenance of this installation is practically impossible/unnecessary. -
Page 138: Maintenance-Free Storage Batteries
20.6 Maintenance-free storage batteries Your PARAVAN power wheelchair is equipped with high quality and powerful storage batteries. These maintenance-free storage batteries are completely sealed. Refilling or topping up the electrolyte (battery acid) is therefore not intended or possible. The charging status or the capacity of the storage batteries can be read on the control panel. -
Page 139: Information Regarding Storage Batteries
20.7 Information regarding storage batteries Sealed storage batteries must never be opened. Opening the storage batteries will result in irreparable damage to them and could lead to a complete power failure. See section “23.1 Handling sealed storage batteries” The storage batteries must be recharged after every use (even if they have only been minimally discharged) with the supplied charger. -
Page 140: Charging The Pr 25
20.8 Charging the PR 25 Only charge the storage batteries with the charger supplied by us. Care tips: > Always ensure that the storage batteries have full charging capacity. > Daily overnight charging is recommended. > The PR 25 should be charged for at least 8 hours uninterrupted. >... -
Page 141: Procedure For Charging The Pr 25
20.8.1 Procedure for charging the PR 25 > Turn off the PR 25. > Put the charger on a heat-insensitive surface, e.g. on the footrests. > Put the charger plug into the charging socket on the control panel. > Connect the charger to the power supply &... -
Page 142: The Charger
20.8.2 The charger The purpose of the charger is to automatically charge the storage batteries. The charger is housed in splash-proof sheet-steel casing. It complies with the guidelines and protection requirements of the: > Low Voltage Directive 2006/95/EC, > Electromagnetic Compatibility Directive 2004/108/EC. Read the operating instructions included separately with the charger. -
Page 143: Technical Equipment
Technical equipment 21.1 Technical data and measurements K120 / K110 orthopaedic seat Seat height with lift function, with seat cushion 120 - 750 mm adapted to light anatomy Tilt 21° forwards, 50° backwards Side frame repositioning Thoracic area 30 mm / side Seat pad 50 mm / side Lumbar support, 4 levels Height adjustment 70 mm... - Page 144 Dimensions Total width of chassis without seat 640 mm (standard seat is within the chassis width) Total length without footplate, forwards movement 1080 mm Total length without footplate, backwards movement 990 mm Total height with a standard seat, including headrest 1200 mm Total height with a standard seat, without headrest 950 mm Electrical equipment...
- Page 145 Driving features Ground clearance 70 mm Maximum obstacle clearance 60 mm Turning circle 780 mm Maximum (upward) climb 12° = 21%** Maximum slope (downward) 10° = 17%** Maximum camber 6° = 11%** Speed Standard 6 km/h, optional max. 10 km/h* * Depending on: weight, ambient temperature, incline, slope, functions used.
- Page 146 Details regarding the pads on the arm supports, seat and rear, description of the frame Arm support pads Pad material: PV foam Thickness: 20mm Compression hardness: 7.2 kPa Density: 56 kg/m³ Cover: BC 12 / Floridas Seat pads Pad material: PR foam / MOI system Thickness: 50 - 110 mm...
- Page 147 Details regarding the pads on the arm supports, seat and rear, description of the frame Back pads Pad material: PR foam / MOI system Thickness: 30 - 50 mm Compression hardness: 77 kg/m3 ± 5%* Degree of hardness: 340 +/-25 N* Density: 260 +/- 25 N Cover:...
-
Page 148: Spare Parts
Spare parts Replacing original parts with non-original parts or parts made in the style of the original (copied) is strictly prohibited/forbidden! Only obtain your replacement parts from your dealer or PARAVAN GmbH. See section “1.1 Your manufacturer” WARNING Danger of injury for persons operating a power wheelchair which does not correspond to the original or delivered condition. -
Page 149: Electromagnetic Compatibility (Emc)
Electromagnetic compatibility (EMC) 22.1 Information regarding electromagnetic compatibility ➨ The installation and maintenance of the device may only be carried out by specialist staff. ➨ Only the charging station supplied by the manufacturer may be used. ➨ The connector must be securely installed. Electronic components and cables must not be damaged. ➨... -
Page 150: Compliance Level
22.2 Compliance level The interference immunity levels in accordance with IEC 60601 are fulfilled. Manufacturer's declaration – electromagnetic interference The PR 25 is designed to be operated under the electromagnetic conditions specified below. The customer or the user of the device should ensure that it is used under these conditions. Emission measurements Compliance Electromagnetic conditions –... - Page 151 Manufacturer's declaration – electromagnetic immunity The PR 25 is designed to be operated under the electromagnetic conditions specified below. The customer or the user of the device should ensure that it is used under these conditions. Interference immunity IEC 60601 – test level Compliance level Electromagnetic conditions –...
- Page 152 Voltage dips, short < 5% UT (>95% dip of Not usable The quality of the supply voltage interruptions and in the UT) for 0.5 periods should correspond to that of a typical case of fluctuations, 40% UT (60% dip of UT) business or hospital environment.
-
Page 153: Annexes And Technical Documentation
Annexes and technical documentation 23.1 Handling of sealed storage batteries When charging sealed storage batteries by water electrolysis at the positive electrode, the oxygen released is guided through a glass mat from the positive to the negative electrode and converted back to water again after a series of chemical reactions. -
Page 154: Customer Service Booklet
23.2 Customer service booklet > 1. Inspection (12 months after commissioning) Date: Signature: Stamp: > 2. Inspection (annual) Date: Signature: Stamp: > 3. Inspection (annual) Date: Signature: Stamp: > 4. Inspection (annual) Date: Signature: Stamp: > 5. Inspection (annual) Date: Signature: Stamp: >... -
Page 155: Ec Declaration Of Conformity
23.3 EC declaration of conformity Fig. 111: EC declaration of conformity Annexes and technical documentation... -
Page 156: Log Of Instructions Provided Upon Delivery
23.4 Log of instructions provided upon delivery Due to the power wheelchair's flexible setting options, the following information should be observed: In the event of tilting (optional): > It must be ensured that the seat is not tilted too far forwards or backwards, as otherwise you could slip out of the seat. - Page 157 Footrests (optional): > When adjusting the height and inclination of the footrest, take care to ensure that the height adjustment does not touch the seat pad. > The setting of the footrest must be higher than the obstacle. The footrest should also not jam on the obstacle since the power wheelchair could topple over.
- Page 158 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
- Page 159 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
- Page 160 Paravan GmbH PARAVAN WHEELCHAIR SERIES Paravanstraße 5-10 72539 Pfronstetten-Aichelau Operating instructions Germany PR 25 Tel.: +49 (0) 73 88 / 99 95-60 Fax: +49 (0) 73 88 / 99 95-999 Email: info@paravan.de ORIGINAL INSTRUCTION MANUAL www.paravan.de V1.40...
