  • Page 1 PARAVAN WHEELCHAIR SERIES User manual PR 30 V3.1...
  • Page 2 Valid for the following model Paravan PR 30 Publisher and Copyright: PARAVAN GmbH Date of issue: 01/09/2020 Document number: PR30_V3.1 EN...
  • Page 3 Dear customer, Thank you very much for having chosen our PR series PARAVAN electric wheelchair. You will find all the important information and tips you need on your new electric wheelchair in this User's Manual. Please carefully read the information on the pages to follow in order to make sure your electric wheel chair will give you many years of problem-free service.
  • Page 4: Table Of Contents

    Table of contents General Legal notice ......................15 Your manufacturer ........................15 1.1.1 Copyright ..........................16 1.1.2 Technical status of this documentation ................. 16 On this User's Manual ..................17 Disclaimer ..........................18 2.1.1 Guarantee ..........................19 2.1.2 Technical alterations ....................... 20 Target groups ...........................
  • Page 5 Accessories included ......................41 5.4.2 Accessories deliverable......................41 Description/Functioning or your electric wheelchair ..........42 The specially PARAVAN comfort seat ..................42 Joystick control ........................43 Special controls ........................43 Lift and tilt (seat inclination) ....................44 Vibration-damped foot rests ....................44 Safe for traffic conditions according to German traffic law ..........
  • Page 6 Optional electric footrest unit ....................54 10.4.2 Setting the tibialis angle ......................55 10.4.3 Setting the foot rest angle ....................... 56 Use of the PARAVAN comfort seat...............57 11.1 Setting the back support ......................57 11.1.1 Setting the back support angle ....................57 11.1.2...
  • Page 7 13.3 Buckling the safety belt ......................66 13.4 Controlling the electric wheelchair's travel direction ............. 67 13.5 Driving a curve.......................... 68 13.6 Braking your electric wheelchair ..................... 69 13.6.1 Braking systems on your electric wheelchair ................ 69 13.7 Braking the electric wheelchair ....................70 13.8 Travelling on hills, uphill and downhill travel ................
  • Page 8 15.6.4 Securing the wheelchair in the docking station ..............93 15.6.5 Release from the docking station ................... 95 15.6.6 Manual release in case of electric failure ................96 Controls ......................97 16.1 Control panel R-NET CJSM2 ....................97 16.1.1 Overview of the control elements ................... 97 16.1.2 Status display ...........................
  • Page 9 16.2.8 Select drive program, drive ...................... 115 16.2.9 Electrical seat adjustment ....................... 116 16.2.10 Set time/date ........................... 117 16.2.11 Show/hide clock, configure 12h/24h display ................. 118 16.2.13 Adjust display brightness ......................119 16.2.12 Adjust the display background and brightness ..............119 16.2.14 Block the controls (with the wheelchair switched on) ............
  • Page 10 21.2 The main safety switch ......................132 21.2.1 Resetting the main safety switch ................... 132 21.3 The secondary safety switch ....................133 21.3.1 Resetting the secondary safety switch .................. 133 21.4 Overload protection ......................... 134 21.4.1 Resetting the overload protection: ..................134 21.5 Facility to connect ancillary devices ..................
  • Page 11 Table of illustrations Fig. 1: QR code ............................ 15 Fig. 2: Direction of travel ........................17 Fig. 3: Safety note ..........................24 Fig. 4: TÜV Logo ..........................35 Fig. 5: Ratings plate ..........................38 Fig. 6: Location, ratings plate ......................39 Fig.
  • Page 12 Content of Dahl Docking Station MK II standard set # 501750 ..........85 Fig. 44: Content of Dahl VarioDock™ standard set # 503600 ............86 Fig. 45: Paravan Kit for Dahl docking station ..................87 Fig. 46: Torx 27 ............................87 Fig. 47: Main Cable battery ........................
  • Page 13 Fig. 57: Control panel R-NET CJSM2 ....................97 Fig. 58: Function keys ........................... 98 Fig. 59: Status display ........................... 98 Fig. 60: “On / off” key ..........................99 Fig. 61: Speed control (tortoise) active ....................99 Fig. 62: Light on and off ........................100 Fig.
  • Page 14 Fig. 86: Turn signal right / left ......................112 Fig. 87: Light symbol (colour)....................... 112 Fig. 88: Hazard lights on / off ....................... 113 Fig. 89: Symbols (colour) ........................113 Fig. 90: Driving functions ........................114 Fig. 91: Driving function blocked ......................114 Fig.
  • Page 15: Legal Notice

    Legal notice Your manufacturer PARAVAN GmbH Registered office / headquarters / production Paravanstraße 5-10, D-72539 Pfronstetten-Aichelau > Tel.: 0 73 88 / 99 95-91 > Fax: 0 73 88 / 99 95-999 > Email: info@paravan.de > Internet: www.paravan.de > Managing Director: Mr. Roland Arnold Many smartphones and tablets have built-in cameras and Fig.
  • Page 16: Copyright

    Germany of 09 September 1965 in its version currently in force. It will always be liable for payment. Any infringements will be subject to the penal clauses of that copyright law. > Copyright © PARAVAN GmbH 2020. All rights reserved! 1.1.2 Technical status of this documentation All details on technical data and/or specifications, illustrations and information in this User's Manual corres- pond to the status as on close of press in September 2020.
  • Page 17: On This User's Manual

    On this User's Manual This User's Manual does not represent product documentation in the sense of a set of maintenance and repair instructions, and is thus not suitable for use in executing maintenance and repair work by its posses- sor, or for instructing on how to execute such work. You are in receipt of information on the nature of the electric wheelchair model and on its use over its entire life cycle from transport (delivery) to decommissio- ning (taking out of service).
  • Page 18: Disclaimer

    Only by observing and putting into practice the knowledge provided by this User's Manual can the electric wheelchair be guaranteed error and fault free operation. PARAVAN GmbH does not take any responsibility for or give any guarantee against damages or operational interruptions that may be caused during operation by the non-observance of the instructions contained in this User's Manual or by any modifications made to the electric wheelchair.
  • Page 19: Guarantee

    2.1.1 Guarantee Guarantee cover is defined exclusively by the relevant provisions set by PARAVAN. Expressly excluded from guarantee entitlements is any damage resulting from: > Wear and tear > Inappropriate operation or usage; e.g. overloading > Incorrect/Irregular maintenance > Incorrect/Irregular care See your personal "Guarantee card"...
  • Page 20: Technical Alterations

    Any modifications made to the safety equipment and technical changes to the electric wheelchair, however small, are absolutely prohibited. All alterations must be executed by PARAVAN GmbH. PARAVAN GmbH reserves the right to make technical alterations and improvements to the product in the interests of four customers and due to advancing technology.
  • Page 21 WA R N I N G Danger of personal injury when operating the electric wheelchair in a state not matching its state upon delivery. Material damage to the electric wheelchair through non-au- thorised or incorrectly installed components. > Do not make any technical modifications to your electric wheelchair.
  • Page 22: Target Groups

    Target groups The operator must attain or acquire a familiarity with the following points before putting the electric wheelchair into operation: > Knowledge of the contents of the User's Manual on the how to use the vehicle, the electric wheelchair, safely and how to move it about.
  • Page 23: Explanation Of Symbols

    Explanation of symbols You will come across the following symbols and warning signs while reading the User's Manual. The "Caution, Danger" logo Calls your attention to danger points. The preventative measures contained in the associated text should always be followed. This symbol always appears with an associated signal word which indicates the degree of danger.
  • Page 24: Structure Of Safety Notices

    2.3.1 Structure of safety notices You can find the following information in the safety notes: > Warning or hazard symbol . > Type and source of hazard . > Signal word . > Consequences of occurrence . > Preventative action . Fig.
  • Page 25: Safety Note

    Safety note General safety notes 3.1.1 Notes on usage You must under all circumstances observe the following safety notes for your own safety, for that of people in your vicinity and to protect the environment. D A N G E R! Danger of crushing by contact with moving parts;...
  • Page 26 WA R N I N G Danger of tipping over for persons when using the electric wheelchair on surfaces with a slope of more than 10°. Danger of tipping over for persons when using the electric wheelchair on downhill slopes with the seat position in its for- wardmost position.
  • Page 27 WA R N I N G Danger of personal injury when operating the electric wheelchair in a state not conforming to its state upon delivery. Material damage to the electric wheelchair through non-au- thorised or incorrectly installed components. > Do not make any technical changes to your electric wheelchair.
  • Page 28 WA R N I N G Danger of injury for persons when travelling with the electric wheelchair over impassible surfaces. Danger of fall and of tipping over for persons when operating the electric wheelchair on surfaces with reduced load-bearing capacity. Material damage to the electric wheelchair through mechani- cal and physical forces due to travelling over impassible sur- faces.
  • Page 29: Notes On Usage

    3.1.2 Notes on usage C A U T I O N Material damage to the electric wheelchair through overloa- ding the vehicle. Material damage to the electric wheelchair though the effect of heat greater than 41°C. Material damage to the electric wheelchair through battery overload on downhill slopes.
  • Page 30: Notes On Transport

    3.1.3 Notes on transport C A U T I O N Material damage to the electric wheelchair through slipping from ramps or lift while being loaded. Material damage to the electric wheelchair through being se- cured and transported improperly in and electric wheelchair transporter.
  • Page 31: Functional Description

    Functional description Manufacturing standard The PARAVAN electric wheelchair is a multifunctional electric wheelchair which, due to its compact design, is ideally suited to both indoor and outdoor usage. The electric wheelchair is built and tested to ensure the highest possible level of safety for its operator and his or her immediate environment.
  • Page 32: Appropriate Usage

    Appropriate usage The PARAVAN electric wheelchair is functionally and structurally intended for the transport of a single person in indoor and outdoor areas. The interface in relation to operation by the user and the liability of the manu- facturer of the electric wheelchair is the control panel, including its joystick and any optional operational units for special operation.
  • Page 33: Usage Of The Electric Wheelchair

    4.2.1 Usage of the electric wheelchair - unproblematic > Boarding by a single person with a maximum body weight of 160kg. > Usage as driver or passenger seat, depending on the associated accessories. > Usage in areas governed by German traffic law (public roads and thoroughfares), on condition that full and fully functioning lighting is installed.
  • Page 34: Clearance Certification As Hazardous Cargo (Accumulator)

    4.2.2 Clearance certification as hazardous cargo (accumulator) PARAVAN GmbH uses accumulators that are rated as "non-hazardous cargo" on condition that the relevant accumulators are not suffering mechanical damage of any type. The maintenance-free VRLA accumulators and the equally maintenance-free lead gel accumulators are clas- sified as leak-proof, non-hazardous cargo for any form of transport according to: >...
  • Page 35: Approvals, Certifications

    The anchoring of the safety belt has been certified and approved in ac- cordance with 76/115/EEC as has the seat in relation to its anchoring in accordance with 74/408/EWG with the Paravan docking system. D A N G E R!
  • Page 36: German Regulations On Assistive Technology (Hilfsmittelverordnung, Hmv No.)

    4.3.2 German regulations on assistive technology (Hilfsmittelverordnung, HMV no.) The PR 40 standing wheelchairs are approved in accordance with assistive technology guidelines: > Kassenarztrecht in Nordwürttemberg – Richtlinien und Normen und Verordnungen und Leistungen (Panel doctors law in Northern Württemberg - guidelines and standards and regulations and services), page B 2 - 1 ff As auxiliary equipment permitted under the German regulations on assistive technology, number: >...
  • Page 37: Indication

    4.3.4 Indication The inability to walk or severely limited ability to walk within the context of the basic need to move in your own home. The provision of wheelchairs with a standing feature is advisable if regular (several times per day) standing training must be carried out as a therapeutic action, and other standing aids, e.g.
  • Page 38: Details Relating To The Product

    Details relating to the product Trademark and type labelling (ratings plate) You can read this information from the device's ratings plate. They are very important in all correspondence with PARAVAM GmbH in guarante- eing that you receive the technically correct advice. >...
  • Page 39: Position Of The Type Label (Ratings Plate)

    Position of the type label (ratings plate) One copy of the type label (ratings plate) has been affixed to your elec- tric wheelchair. The type label (ratings plate) is about 70mm by 40mm in size. > The type label (ratings plate) is positioned on the lower right of your wheelchair, next to the battery holder .
  • Page 40: Details On Your Electric Wheelchair

    Details on your electric wheelchair Please make sure that these details are listed when the wheelchair is handed over to you or, if necessary, enter the information yourself so that you have it to hand at all times. Date of delivery/handover >...
  • Page 41: Accessories

    > DAHL Vario Dock for quick and easy fastening of the PR 30 in a vehicle. Fig. 8: DAHL Vario Dock (height adjustable)
  • Page 42: Description/Functioning Or Your Electric Wheelchair

    Description/Functioning or your electric wheelchair The specially PARAVAN comfort seat > Removable headrest, adjustable height and angle  > The armrest can be swivelled backwards by means of a knurled  screw under the armrest, adjustable angle  > The angle of the backrest can be manually adjusted by means of a rotary knob, ...
  • Page 43: Joystick Control

    Driving speed, control of the two drive motors > Secondary functions, depending on the control panel and equipment being used. Special controls A variety of special controls can be used on the PARAVAN electric wheelchair, including the following: > Chin control >...
  • Page 44: Lift And Tilt (Seat Inclination)

    Lift and tilt (seat inclination) The electric wheelchair is equipped with a sturdy single-lever lift, which fully extended can reach a height of 80cm. This ensures that you have the largest possible radius of action in your everyday household and work environment.
  • Page 45: Safe For Traffic Conditions According To German Traffic Law

    Safe for traffic conditions according to German traffic law Optionally, the PARAVAN electric wheelchair can be enhanced to be- come a vehicle approved for use in road traffic using: > headlights for the best possible illumination . > directional indicators .
  • Page 46: Overview Of The Paravan Electric Wheelchair

    Overview of the PARAVAN electric wheelchair Definition of vocabulary for parts and their positions The following terms for components and parts will be used in this user's manual. Their position on the wheelchair is shown in the illustration. > Control panel with joystick ...
  • Page 47: Definition Of Vocabulary For Parts, Place Of Installation, Chassis

    > Rigging eyelet, rear  > Floating axle  > Drive motor for lift arm  > Actuator module  > Battery holder  > Accumulator (battery)  Fig. 13: Components, rear of chassis Overview of the PARAVAN electric wheelchair...
  • Page 48: Fig. 14: Components, Front Of Chassis

    Fitting for docking station  > Brake release lever, emergency release  > Drive motor  > Lift motor with lifting rod and gearing  > Bracket for ancillary components  Fig. 14: Components, front of chassis Overview of the PARAVAN electric wheelchair...
  • Page 49: Handing Over The Electric Wheelchair

    Check that your your electric wheelchair is complete and compare the state in which it was delivered with what is indicated on your order. Where there is any doubt, contact PARAVAN GmbH immediately! Check (visually) that your electric wheelchair is in proper order. Report any damage that may be due to trans- port or delivery immediately in writing to your >...
  • Page 50: Settings On Your Electric Wheelchair; Electronic

    Settings on your electric wheelchair; electronic The settings and configuration needed for PARAVAN controls are very complex and for your own safety can only be done by your service technician. All parameters used in PARAVAN controls can be adjusted later to your needs and wishes. These parameters include: >...
  • Page 51: Settings On Your Electric Wheelchair; Mechanical

    All mechanical components and equipment and operating elements are set to match your body mass. However, if any adjustment should be necessary, then it can be made at any time. Your PARAVAN electric wheelchair is build so that it can be adjusted to the needs of any body mass.
  • Page 52: The Armrest A8

    10.2 The armrest A8 This instruction applies both to the left and right hand side. > can be raised up > max angel adjustable with the adjustment wheel   Fig. 15: Armrest A8 Settings on your electric wheelchair; electronic...
  • Page 53: Setting The Movability Of The Control Panel

    10.3 Setting the movability of the control panel The horizontal swivel mechanism of the control panel can be set to ad- just its level of stiffness (i.e. in terms of the responsiveness and mova- bility of the joint). This level of stiffness can only be set by your service technici- Fig.
  • Page 54: Series Manual Footrest Unit

    The angle of the footrests can only be manually ad- justed by means of a setting screw. The rest for the lower leg / the lower leg length can be electrically adjusted via the PARAVAN control in the length setting.
  • Page 55: Setting The Tibialis Angle

    Setting the tibialis angle The projection of the lower leg and of the tibialis angle (between the up- per and lower leg) can be made using the angle setting of the PARAVAN control, depending on how your model is equipped.
  • Page 56: Setting The Foot Rest Angle

    > Screw the adjustment screw  in or out as required. > Check your setting (lower the foot rest). > Tighten the lock nut  to about 8 Nm. Fig. 19: Foot rest angle Use of the PARAVAN comfort seat...
  • Page 57: Use Of The Paravan Comfort Seat

    Use of the PARAVAN comfort seat 11.1 Setting the back support 11.1.1 Setting the back support angle The back support and the back support angle can be changed maually. Turn the handwheel  on the side of the seat to adjust theback support angle.
  • Page 58: Setting The Head Support

    In order to remove the head support (e.g. at the hairdresser) you must pull it up over the final stage and pull it free. Do the same in reverse to replace it. Use of the PARAVAN comfort seat...
  • Page 59: Setting Your Sitting Position

    11.1.3 Setting your sitting position The seat can be moved forward or backwards using the PARAVAN con- trol if you have chosen this optional special accessory. > Select the menu in the control. > Make your setting. See Section "3 Notes on safety"...
  • Page 60: Setting Your Lying Position

    11.2 Setting your lying position The seat can be moved into a lying position using the PARAVAN control. The lying position function is not provided within the control. It must be set individually by the user. Take the following steps in the following sequence when setting the ly- ing position: >...
  • Page 61: Setting The Standing Up Position

    11.3 Setting the standing up position The seat can be moved into a stand-up position using the PARAVAN control. The stand-up position function is not provided in the control. It must be set individually by the user. Take the following steps in the following sequence when setting the stand-up position: >...
  • Page 62: Removing And Reattaching The Chassis Cladding

    Removing and reattaching the chassis cladding 12.1 Removing and reattaching the rear cladding The chassis cladding can be removed for maintenance, repair or cleaning. Take the following steps in the following sequence when removing and reassembling the rear cladding: > Loosen and remove knurled screws .
  • Page 63: Removing And Reattaching The Side Cladding

    12.2 Removing and reattaching the side cladding The chassis cladding can be removed for maintenance, repair or cleaning. Take the following steps in the following sequence when removing and reattaching the side cladding: > Loosen and remove knurled screws . >...
  • Page 64: Driving Your Electric Wheelchair

    Driving your electric wheelchair 13.1 Insurance, civil liability insurance We recommend speaking with your insurance advisor before starting use, so that the use of the electric wheelchair is included in your insurance policies – in particular in your civil liability insurance. Please observe that for use on the public roads you may be legally required by the relevant legislati- on to have an insurance policy for use of your electric wheelchair.
  • Page 65: Functional Checking Before Driving

    13.2 Functional checking before driving For your own safety, you must check the following points before begin- ning any trip. You may need to involve a second person for such a check. > Check that the brakes are working. The brake release lever  must be positioned on "LOCK"; i.e.
  • Page 66: Buckling The Safety Belt

    13.3 Buckling the safety belt Listen for an audible clicking into place of the buckle latch  in the belt fastener  when buckling the safety belt. Fig. 30: Fastening the seat belt The function of the belt fastener is similar for all belt variants, including: >...
  • Page 67: Controlling The Electric Wheelchair's Travel Direction

    13.4 Controlling the electric wheelchair's travel direction The electric wheelchair is steered using the joystick on the drive panel. The following basic steering options are available to you when you put the joystick in the following positions: > Joystick pushed forward → the electric wheelchair travels forward. Joystick to left or right →...
  • Page 68: Driving A Curve

    13.5 Driving a curve The PARAVAN electric wheelchair is equipped with front-wheel drive. This means that when steering (driving on curves) the rear of the vehicle swings outwards. How to drive around a curve: > Press the joystick in the desired direction of movement (forwards or backwards).
  • Page 69: Braking Your Electric Wheelchair

    Braking systems on your electric wheelchair In order to guarantee the highest possible level of safety, the PARAVAN electric wheelchair uses two braking (safety) systems that work independently of each other. The functions of each of these safety systems are as follows: >...
  • Page 70: Braking The Electric Wheelchair

    13.7 Braking the electric wheelchair The braking mechanism; i.e. the process from initiating the braking process until the electric wheelchair co- mes to a stop, depends very heavily on a number of factors, such as: > Surface and nature of the surface being travelled on. >...
  • Page 71: Travelling On Hills, Uphill And Downhill Travel

    13.8 Travelling on hills, uphill and downhill travel For your own safety you must observe and follow the following advice during uphill and downhill travel: > Set the seat position to its hindmost position in order to prevent slipping. > Always drive with your safety belt on.
  • Page 72: The Driving Programmes / Drive Levels

    13.9 The driving programmes / drive levels The PARAVAN electric wheelchair has four different driving programmes, or drive levels. You can select the drive level you want or final driving speed of your electric wheelchair on the control panel. You can reach the maximum final speed of the relevant drive level by pushing the joystick forward as far as it goes.
  • Page 73: Driving Manually, Manual Operation

    13.10 Driving manually, manual operation 13.10.1 Use of the brake release lever (emergency release) > If you want to push the electric wheelchair, you must move both brake release levers  on the left and right-hand side to "UNLOCK" (their downward position). Do not switch to "UNLOCK"...
  • Page 74: Terrain Requirements, Surfaces

    13.11 Terrain requirements, surfaces WA R N I N G Danger of tipping over for persons when using the electric wheelchair on surfaces with a slope of more than 10°. Danger of tipping over for persons when using the electric wheelchair on downhill slopes with the seat position in the most forward position.
  • Page 75: 13.11.2 Climbing And Overtaking Capacity

    13.11.2 Climbing and overtaking capacity > If you drive over obstacles higher than 60 to 70mm you and your electric wheelchair may become caught on the obstacle due to the battery casing and may be immobilised or overturn. 13.11.3 Load-bearing capacity >...
  • Page 76: Parking And Storing Your Electric Wheelchair

    Parking and storing your electric wheelchair In order to prevent damage to your electric wheelchair, you must observe the following rules when you park it, e.g. overnight, or for any longer period of time: > Connect it up with the recharger. >...
  • Page 77: Loading And Transporting Your Electric Wheelchair

    Loading and transporting your electric wheelchair Your electric wheelchair should always be switched off and properly secured or lashed down during transport. Use loading devices such as: > ramps, lifts and hoists with sufficient load-bearing capacity. 15.1 Rules when loading wheelchairs The following rules must be followed when loading: >...
  • Page 78: Securing Your Electric Wheelchair, Lashing

    Front: two rigging eyelets  > Rear: one rigging eyelet  No other securing is required if your vehicle is equipped with a PARAVAN docking station.  See Section "5.4.2 Available accessories" Fig. 35: Securing point at rear Loading and transporting your electric wheelchair...
  • Page 79: Fasten The Seatbelt In A Moving Vehicle

    15.3 Fasten the seatbelt in a moving vehicle D A N G E R Potential risk of injury or serious injury or death. The Wheelchair integrated 3 or 4 point belts should not be re- lied on for occupant restraint in a moving vehicle. An approved, vehicle anchored safety belt system, should be used to secure occupant instead.
  • Page 80: Securing The Wheelchair With A 4 Point Strap Restraint System

    15.4 Securing the wheelchair with a 4 point strap restraint system Standard ISO 10542-1 tie down straps are only tested to 85 kg + user. It is recommended to use with 4 point strap restraint system rated for the total weight of the wheelchair in- cluding any option, 2 at front and 2 at the back that conforms to ISO 10542-1.
  • Page 81: Occupant Restraint Instruction

    15.5 Occupant restraint instruction > Use a vehicle anchored occupant restraint system to secure the occupant. > Both pelvic and upper torso restraint belts must used to restrain the occupant to reduce the possibility of head and should not be held away from the body by wheelchair components such as armrest or wheels. >...
  • Page 82: Fig. 41: Positioning The Occupant Restraint For Use With Dahl Docking System Only

    > The upper torso restraint belt must fit over the shoulder and across the chest as illustrated Fig. 50. Restraint belts must be adjusted as tightly as possible consistent with use comfort. > Restraint belt webbing must not be twisted when in use. >...
  • Page 83: Dahl Docking Systems Assembly

    PR Biolution and PR Heavy Duty from Paravan. The following instructions explain how to assemble the Dahl Docking Station MK II and VarioDock™ on the wheelchair, using the PARAVAN adaption kit. Please also refer to Dahl Engineerings instructions for ve- hicle installation, use and maintenance.
  • Page 84 WA R N I N G Risk of injury through incorrect handling of the batteries. Damage to property through incorrect handling of the batter- ies. > Handle with special care. > May only be connected and disconnected by qualified per- sonnel.
  • Page 85: Content Of Dahl Docking Stations

    15.6.1 Content of Dahl docking stations Fig. 43: Content of Dahl Docking Station MK II standard set # 501750 Loading and transporting your electric wheelchair...
  • Page 86: Fig. 44: Content Of Dahl Variodock™ Standard Set # 503600

    Fig. 44: Content of Dahl VarioDock™ standard set # 503600 Loading and transporting your electric wheelchair...
  • Page 87: Fitting Of The Dahl Lock Plate On Wheelchair

    ⑦ Countersunk screw TORX ISO 14581 - M8 x 35 -14.9 ⑧ Hexagon nut ISO 4032 - M8 > To install the Dahl Locking plate use Paravan Adaptation Kit, article 33187. > To assemble the adapter set of the Dahl docking station, you need two Allen keys, size 5 and size 10, a Torx 27 and a wrench SW 13.
  • Page 88: Fig. 47: Main Cable Battery

    Disconnect the main cable plug from the batteries left and right ④. Fig. 49: Knurled screws Paravan ② ③ ④ ④ Fig. 50: Rear and side panels Paravan Fig. 47: Main Cable battery Fig. 48: Disconnect battery Loading and transporting your electric wheelchair...
  • Page 89: Fig. 51: Position The Dahl System

    Fasten the Dahl system on both sides with four M8 x 12 pan-head screws each. > Screw them in medium-tight with a screw lock Fig. 52: Remove batteries Paravan Fig. 51: Position the Dahl system Fig. 53: Fasten the Dahl system Loading and transporting your electric wheelchair...
  • Page 90 After the Dahl system has been attached to the wheelchair chassis, reinsert the batteries and reattach the panelling in reverse order. The PARAVAN adapter kit can also be pushed further forwards or backwards and fastened accordingly, depending on the position of the counterpart in the vehicle.
  • Page 91 To attach the Dahl Docking Station to the PR 30, use the screws provided. D A N G E R Potential risk of injury or serious injury or death due to use of incorrect screws. > Use the screws provided.
  • Page 92: Description Of The Dahl Docking System Functions

    15.6.3 Description of the Dahl Docking system functions ① Dahl Docking station ② Lock plate and spacer ③ Lock pin ④ Red LED ⑤ Green LED ⑥ Control panel ⑦ Release button ⑧ Manual emergency release lever ⑨ Manual operating lever Fig.
  • Page 93: Securing The Wheelchair In The Docking Station

    15.6.4 Securing the wheelchair in the docking station > Maneuver the wheelchair slowly and in a uniform direction over the docking station. The lock plate under the wheelchair helps to guide the wheelchair into place in the docking station. When the lock plate is fully engaged in the docking station, a spring-action locking pin automatically secures the lock plate.
  • Page 94 D A N G E R Potential risk of injury or serious injury or death! Do not move the vehicle: > Whilst the wheelchair is being maneuvered into position in the docking station > If the wheelchair and user are not correctly secured. >...
  • Page 95: Release From The Docking Station

    15.6.5 Release from the docking station > When the vehicle has been brought to a halt, remove the safety belt. > To unlock commence by driving the wheelchair forward to release pressure on the lock pin. > Press the red release button in the control panel. The locking pin will be triggered/ released for approx. 5 or 8 seconds, after which the locking pin is automatically locked/activated again.
  • Page 96: Manual Release In Case Of Electric Failure

    15.6.6 Manual release in case of electric failure A manual emergency release is located at the front edge of the docking station. > Move wheelchair forward to remove the pressure on the lock pin and push the red release arm to one side and hold it there while the wheelchair moves away.
  • Page 97: Controls

    Controls 16.1 Control panel R-NET CJSM2 16.1.1 Overview of the control elements With the control panel (joystick) built into your power wheelchair, ⑫ you can control all of the power wheelchair's driving, steering and ③ braking processes. All additional functions which are equipped with ⑩...
  • Page 98: Status Display

    16.1.2 Status display The function keys are used to select the specific functions displayed in the assigned fields on the display. Symbols of the status indicator: Charging status of the storage batteries ① > > Direction indicator, left ② “On/off” light ③ >...
  • Page 99: Start, Switch Off

    16.1.3 Start, switch off Start ① Push the “on/off” switch ① upwards. > The status display briefly flashes and the last selected function in terms of movement level/seat function is shown. > Press the switch ① downwards again to: - Select movement levels 1 to 5 - Then switch to the seat functions Switch off Push the “on/off”...
  • Page 100: Switch Direction Indicator On And Off

    16.1.5 Switch direction indicator on and off Press key ① or ② for the respective direction indicator, left or right.  > The selected direction indicator will flash. > Press once more → direction indicator switches off.  Fig. 63: Turn signal right / left 16.1.4 Switch light on and off Press the key ...
  • Page 101: Switch Hazard Lights On And Off

    16.1.6 Switch hazard lights on and off Press the “hazard lights” key  for the “hazard lights on” function. > The hazard lights switch themselves on, while the hazard lights  symbol flashes red and both direction of travel symbols flash green. >...
  • Page 102: Driving Functions Overview

    16.1.7 Driving functions overview Overview of the driving functions shown on the display of the control panel during driving, steering and braking actions of the power ⑤ wheelchair. ② > Selected drive program/movement level ① ⑥ ① > Respective setting (having drilled down) for the selected movement level (1 to 5) fast/slow ②...
  • Page 103: Select Drive Program, Drive

    16.1.8 Select drive program, drive The power wheelchair must be in driving mode. > The last selected drive program is shown on the display (profiles 1 to 5). Drive profiles 1 to 5 are further divided into 5 levels once you drill down.
  • Page 104: Electrical Seat Adjustment

    16.1.9 Electrical seat adjustment Use the MODE key to switch from the drive program to the seat functions. Select the desired seat function by moving the joystick “← left/right →”. > The adjustment functions menu will appear on the display. Only the released or available functions can be selected.
  • Page 105: Set Time/Date

    16.1.10 Set time/date Press and hold the “hazard lights” key to access the “Settings” menu. > The special functions menu will appear on the display. Move the joystick → left/right to access the options “year, month, date, day of the week, hours and minutes”. Select the desired option by mo- ving the joystick “←...
  • Page 106: Show/Hide Clock, Configure 12H/24H Display

    16.1.11 Set time/date Press and hold the “hazard lights” key to access the “Settings” menu. > The special functions menu will appear on the display. Move the joystick → left/right to access the options “year, month, date, day of the week, hours and minutes”. Select the desired option by moving the joystick “←...
  • Page 107: Adjust Display Brightness

    16.1.12 Adjust display brightness Select the program function: > Press and hold the “hazard lights” key. > Select “Back lighting” from the settings. > Select the intensity of the lighting (0 to 100% in 10% stages) by mo- ving the joystick “← left/right→”. To save →...
  • Page 108: Block The Controls (With The Wheelchair Switched On)

    16.1.14 Block the controls (with the wheelchair switched on) > Turn the control panel off and press and hold the ON/OFF button ① until you hear a beeping sound > Move the joystick forwards until you hear a beeping sound ①...
  • Page 109: Control Panel R-Net Cjsm-L

    16.2 Control panel R-NET CJSM-L 16.2.1 Overview of the control elements With the control panel (joystick) built into your power wheelchair, ⑧ ① ③ ③ you can control all of the power wheelchair's driving, steering and ⑩ ⑪ braking processes. All additional functions which are equipped with displacement motors, such as the lifting arm and the sitting functions, ⑫...
  • Page 110: Status Display

    16.2.2 Status display The function keys are used to select the specific functions displayed in the assigned fields on the display. Symbols of the status indicator: Charging status of the storage batteries ① > > Direction indicator, left ② “On” light ③ >...
  • Page 111: Start And Switch Off

    16.2.3 Start and switch off Start ① Push the “on/off” switch ①. > The last selected function in terms of movement level/seat function is shown. Switch off Push the “on/off” switch ①. > The power wheelchair switches itself off (assuming it is already switched on).
  • Page 112: Switch Direction Indicator On And Off

    16.2.4 Switch light on and off Press key ① or ② for the respective direction indicator, left or right. > The selected direction indicator will flash. > Press once more → direction indicator switches off. ① ② Fig. 86: Turn signal right / left 16.2.5 Switch direction indicator on and off Press the key ①...
  • Page 113: Switch Hazard Lights On And Off

    16.2.6 Switch hazard lights on and off Press the “hazard lights” key ① for the “hazard lights on” function. ① > The hazard lights switch themselves on, while the hazard lights symbol flashes red and both direction of travel symbols flash yellow. >...
  • Page 114: Driving Functions Overview

    16.2.7 Driving functions overview Overview of the driving functions shown on the display of the control panel during driving, steering and braking actions of the power wheelchair. ⑤ ② ① > Selected drive program/movement level ① > Maximum speed in the selected drive program ② ④...
  • Page 115: Select Drive Program, Drive

    16.2.8 Select drive program, drive The power wheelchair must be in driving mode. ③ > The last selected drive program is shown on the display. ① ② Press the profile key ① to select/switch to one of the 5 movement levels (profiles).
  • Page 116: Electrical Seat Adjustment

    16.2.9 Electrical seat adjustment Use the “Mode key” to switch from the drive program to the seat functions. Move the joystick “← Left/Right →” to select the seat function. > The respective seat function will appear on the display. Only the functions present from the factory can be selected. ①...
  • Page 117: 16.2.10 Set Time/Date

    16.2.10 Set time/date Press and hold the “slower” ① and “faster” ② speed keys to access the “Settings” menu. > The special functions menu will appear on the display. Move the joystick → right to access the options “year, month, date, day of the week, hours and minutes”.
  • Page 118: 16.2.11 Show/Hide Clock, Configure 12H/24H Display

    16.2.11 Show/hide clock, configure 12h/24h display Select the program function: > Press and hold the keys ①+②. > The “Settings” menu appears. > Use the joystick to select “Display time”. > By moving the joystick “← Left/Right →”, select “12h/24h display” or “Off”.
  • Page 119: 16.2.13 Adjust Display Brightness

    16.2.12 Adjust the display background and brightness Select the program function: > Press and hold the “slower” ① and “faster” ② speed keys. > Select “Back lighting” from the settings. By moving the joystick “← Left/Right →”, select the percentage >...
  • Page 120: Block The Controls (With The Wheelchair Switched On)

    16.2.14 Block the controls (with the wheelchair switched on) > Turn the control panel off and press and hold the ON/OFF button ① ① until you hear a beeping sound > Move the joystick forwards until you hear a beeping sound >...
  • Page 121: Getting Out Of Your Electric Wheelchair

    Getting out of your electric wheelchair When getting out of your wheelchair independently, you should keep in mind the following points for your own safety: > You should be able to deal with your own body weight safely. > You should be able to push against the electric wheelchair with both arms simultaneously and with each exerting equal strength.
  • Page 122: Procedure When Getting Out From The Side

    17.1 Procedure when getting out from the side During any move from the side, follow this sequence of actions: > Position the electric wheelchair side on > Set the required seat height > Switch the electric wheelchair off > Fold the foot rests  up >...
  • Page 123: Care And Maintenance

    Care and maintenance Appropriate use and operation of the PARAVAN electric wheelchair involves subjecting it to the recommen- ded annual maintenance plan. All powered parts, and particularly the lift arm, are structurally designed so that to ensure that electric wheelchair can be operated without failures and requiring little maintenance.
  • Page 124: Cleaning And Care

    18.2 Cleaning and care High-pressure cleaners should not be used to clean the electric wheelchair. Be careful that no elect- ronics come in contact with water. Only the following should be used for cleaning the frame and plastic components (or painted layer) >...
  • Page 125: Disposal And Environmental Protection

    Disposal and environmental protection The electric wheelchair itself and its individual components are designed to enjoy a long service life. During manufacture and construction,care was taken to use recyclable and harmless raw materials as much as pos- sible. At the end of its service life, the electric wheelchair is suitable for careful recycling and environmentally friendly disposal.
  • Page 126: Packaging Materials

    19.1 Packaging materials The packaging is largely made of recyclable and environmentally harm- less materials, such as: > Wood; e.g. pallets and outer packaging > Metal; e.g. tensioning straps > Bubble wrap Take advantage of the opportunity to recycle the packaging in an environmentally friendly manner.
  • Page 127: Re-Commissioning

    > Clean thoroughly. The electric wheelchair must be completely cleaned and subjected to a thorough inspection by a service technician authorised by PARAVAN GmbH before being put back into use. See Section "18 Care and maintenance" Disposal and environmental protection...
  • Page 128: Notes On Transfer

    19.3 Notes on transfer Where the PARAVAN electric wheelchair is transferred to new user, all technical documentation required for safe use and operation, such as; > The User's Manual and > Service logs must be passed on to the new user.
  • Page 129: Correcting Failures

    Correcting failures 20.1 Flashing codes indicating the status of the control panel Error Message: Meaning: Centre Joystick The most common cause of this error is that the joystick is not centred when the control system is switched on. “Joystick off-centre” will appear on the display for five seconds.
  • Page 130 Error Message Meaning Brake Error Error with the brakes This message appears when the control system detects a prob- lem with the magnetic brakes or their connections. Check the magnetic brakes, cables and connections in the control system. Check that the motor brakes have not come uncoupled.
  • Page 131: Electrical System

    Electrical system 21.1 Automatic safety switches The PARAVAN electric wheelchair is equipped with two automatically triggered safety switches and an elec- trical overload protection mechanism. Taken individually, they may be described as follows: > Main safety switch: The main switch protects the electric wheelchair's entire electrical system from any overload of electrical devices by activating immediately to cut off electricity from your electric wheelchair.
  • Page 132: The Main Safety Switch

    21.2 The main safety switch The main safety switch is positioned at the rear of the electric wheelchair on the left. A pivoted green flag indicates that the main safety switch has been activated (triggered). Fig. 105: Main safety switch, activ 21.2.1 Resetting the main safety switch >...
  • Page 133: The Secondary Safety Switch

    21.3 The secondary safety switch The secondary safety switch can be found on the left under the electric wheelchair's cladding. A raised button  indicates that the secondary safety switch has activated. Fig. 107: Sec. safety switch, activ. 21.3.1 Resetting the secondary safety switch >...
  • Page 134: Overload Protection

    21.4 Overload protection The electricity generated when travelling downhill (when the drive motors act as dynamos) is directed into the accumulators. If you have fully recharged your electric wheelchair before starting the downhill stretch the safety system switches to emergency stop in order to prevent damage to the electrical system (control, electronics, etc.).
  • Page 135: Facility To Connect Ancillary Devices

    12 or 24 volts to the electric wheelchair's own on-board network. If you have a need for this facility – for example for a breathing apparatus, please contact PARAVAN GmbH. The external connections will be made to suit the needs of the affected user and the cable loop will be cut or relayed as necessary.
  • Page 136: The Lighting System

    21.6 The lighting system Depending on the variant you have chosen, your PARAVAN electric wheelchair may be equipped with a complete set of road-approved ligh- ting using LED technology. The use of LED lamps means that lamp re- placement or maintenance tasks are practically no longer necessary. If ...
  • Page 137: The Maintenance-Free Accumulators

    21.7 The maintenance-free accumulators Your PARAVAN electric wheelchair is fitted with high-quality, high-performance accumulators. These mainte- nance-free accumulators are entirely enclosed. The system is not designed to need or allow any refilling or topping up the electrolyte (battery acid). The state of charge or capacity of the accumulators can be seen from the control panel.
  • Page 138: Notes On Accumulators

    21.8 Notes on accumulators The enclosed accumulators should never be opened. Opening the accumulators will cause irrepara- ble damage to these components, possibly resulting in a complete loss of energy supply. See Section "23.1 Dealing with closed accumulators" The accumulators should always be recharged using the supplied recharging device after every spell of use (even if use of charge was minimal during the spell).
  • Page 139: Changing Your Accumulators

    21.9 Changing your accumulators If it should become necessary to replace the accumulators in your electric wheelchair, let your service technician or dealer do the work in order to guarantee the safe function or your electric wheelchair. > Move the lift arm upwards. >...
  • Page 140: Charging Your Electric Wheelchair

    21.10 Charging your electric wheelchair Charge the accumulators only with the charging device supplied. The recharging device is available in 2 models: > "Indoor" for use in indoor areas > "Outdoor" for use outdoors Care tips: > Make sure that the accumulators are always charged to full capacity. >...
  • Page 141: 21.10.1 Procedure For Charging Your Electric Wheelchair

    21.10.1 Procedure for charging your electric wheelchair > Switch electric wheelchair off. > Place the charging device on a heat-resistant surface e.g. the foot supports. > Insert the charging device plug  into the charging socket on the control panel. >...
  • Page 142: 21.10.2 The Charging Device

    21.10.2 The charging device The charging device is suitable for automatic charging of the accumu- lators. The charging device is protected by a water-resistant sheet-steel housing. This complies with the directives and safety regulations of: > 2006/95/EC Low Voltage Directive >...
  • Page 143: Technical Equipment

    Technical equipment 22.1 Technical data and dimensions Orthopaedic seat K630 seating unit Lifting function as measured without seat 360mm - 800mm Tilting Forward 21° Backward 50° Back angle Backward 67° Adjustment of foot position 120mm Seat length adjustment, optional 180mm Foot angle adjustment, optional 0°...
  • Page 144 Dimensions Total width of chassis without seat 640mm (Standard seat fully within the chassis width) Total length without foot rests, forward movement. 990mm Total length without foot rests, reverse movement. 900mm Total height, standard seat, including head support 1240mm Total height, standard seat, without head support 1050mm Electrics Accumulators...
  • Page 145 Driving properties Floor clearance 70mm Maximum height of obstacles 60mm Turning radius 780mm Maximum slope (uphill) 12° = 21%** Maximum slope (downhill) 10° = 17%** Maximum lateral slope 6° = 11%** Speed Standard 6 km/h, optional max. 10km/h* * The maximum range was measured under test conditions. Weight, terrain and weather conditions may influence this figure in everyday operation.
  • Page 146: Replacement Parts

    Replacement parts The replacement of original parts by thirdpary components or by reproduction (copied) original parts is strictly forbidden! Obtain your spare parts exclusively from your dealer or from PARAVAN GmbH. See Section "1.1 Your manufacturer" WA R N I N G Danger of personal injury when operating the electric wheelchair in a state not conforming to its state upon delivery.
  • Page 147: Systems And Technical Documentation

    Systems and technical documentation 23.1 How to deal with closed accumulators Where accumulators are completely enclosed, the oxygen liberated at the positive electrode by water decom- position is channelled via a glass fibre mat from the positive to the negative electrode and finally converted back into water at the end of a series of chemical reactions.
  • Page 148: Customer Service Book

    23.2 Customer service book > 1. Inspection (12 months after commissioning) Date: Signature: Stamp: > 2. Inspection (annual) Date: Signature: Stamp: > 3. Inspection (annual) Date: Signature: Stamp: > 4. Inspection (annual) Date: Signature: Stamp: > 5. Inspection (annual) Date: Signature: Stamp: >...
  • Page 149: Eu Declaration Of Conformity

    23.3 EU Declaration of Conformity Fig. 115: EU Declaration of Conformity Systems and technical documentation...
  • Page 150: Protocol Of The Handover Briefing

    23.4 Protocol of the handover briefing Due to the flexible options available for setting up your electric wheelchair, you must observe the following points: Where there is tilt: > It should be ensured that the seat is not leaning out too far to the front or back, as this may mean you might slip out of the seat.
  • Page 151 Foot rests: > When adjusting the height and angle of the foot rests, be careful that the height does not make contact with the seat padding. > The foot rest setting must be higher than any obstacle. In addition, the foot rest must not become caught up by the obstacle, as this may cause the electric wheelchair to topple over.
  • Page 152 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 153 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 154 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 155 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 156 Paravan GmbH PARAVAN WHEELCHAIR SERIES Paravanstraße 5-10 72539 Pfronstetten-Aichelau User manual Germany PR 30 Telephon:+49 (0) 73 88 / 99 95-60 Fax: +49 (0) 73 88 / 99 95-999 Email: info@paravan.de ORIGINAL INSTRUCTION MANUAL www.paravan.com V3.1...

Table of Contents
