Hirschmann EAGLE20 User Manual

Installation industrial security router
Hide thumbs Also See for EAGLE20:
Table of Contents

Advertisement

Quick Links

User Manual
Installation
Industrial Security Router
EAGLE20/30
Installation EAGLE20/30
Technical support
Release 12 03/2021
https://hirschmann-support.belden.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAGLE20 and is the answer not in the manual?

Questions and answers

Related Manuals for Hirschmann EAGLE20

Summary of Contents for Hirschmann EAGLE20

  • Page 1 User Manual Installation Industrial Security Router EAGLE20/30 Installation EAGLE20/30 Technical support Release 12 03/2021 https://hirschmann-support.belden.com...
  • Page 2 In addition, we refer to the conditions of use specified in the license contract. You can get the latest version of this manual on the Internet at the Hirschmann product site (www.hirschmann.com). Hirschmann Automation and Control GmbH Stuttgarter Str.

  • Page 3: Table Of Contents

    1.7.2 Digital input (optional) 1.7.3 Port status 1.7.4 Additional status information (optional) Management interfaces 1.8.1 V.24 interface (external management) 1.8.2 SD card interface 1.8.3 USB interface Input/output interfaces 1.9.1 Signal contact 1.9.2 Digital input (optional) Installation EAGLE20/30 Release 12 03/2021...
  • Page 4 2.7.3 WAN port (optional) Filling out the inscription label Making basic settings First login (Password change) Monitoring the ambient air temperature Maintenance and service Disassembly Removing the device Removing an SFP transceiver (optional) Technical data Further support Installation EAGLE20/30 Release 12 03/2021...

  • Page 5: Important Information

    WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION CAUTION indicates a possible danger which, if not avoided, may result in minor injuries. Installation EAGLE20/30 Release 12 03/2021...
  • Page 6 NOTICE NOTE provides information about procedures that do not involve the risk of injury. Installation EAGLE20/30 Release 12 03/2021...

  • Page 7: Safety Instructions

    Certified usage   Use the product only for the application cases described in the Hirschmann product information, including this manual.  Operate the product only according to the technical specifications. See “Technical data” on page 47.  Connect to the product only components suitable for the requirements of the specific application case.
  • Page 8  At ambient air temperatures > +140 °F (+60 °C): The surfaces of the device housing may become hot. Avoid touching the device while it is operating. Qualification requirements for personnel   Only allow qualified personnel to work on the device. Installation EAGLE20/30 Release 12 03/2021...
  • Page 9 Only for device variants featuring supply voltage with the characteristic value CC: The voltage connected complies with the requirements for a safety extra-low voltage (SELV) as per IEC 60950-1 or ES1 as per IEC/EN 62368-1. Table 1: General requirements for connecting electrical wires Installation EAGLE20/30 Release 12 03/2021...
  • Page 10 The power supply cables are suitable for ambient air temperatures of at least +167 °F (+75 °C). The wires of the power supply cables are made of copper. Table 3: Requirements for connecting the supply voltage Installation EAGLE20/30 Release 12 03/2021...
  • Page 11 Table 3: Requirements for connecting the supply voltage a. IT supply system according to the technical standard UL 60950-1 Supply voltage  The supply voltage is connected to the device casing through protective elements exclusively. Installation EAGLE20/30 Release 12 03/2021...
  • Page 12 à moins que l'emplacement soit connu pour ne contenir aucune concentration de gaz inflammable. Avertissement - Risque d'explosion - La substitution de tout composant peut rendre ce matériel incompatible pour une utilisation en classe I, division 2. Installation EAGLE20/30 Release 12 03/2021...
  • Page 13 Ta: -40 C to +70 C for “T” or “E” temperature types (Refer to the temperature code of the type designation on the device) Control Drawing for EAGLE20/30 devices according to Class I Division 2 Hazardous Locations Rev.: 2 Doc. No.: 000172287DNR...
  • Page 14 WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON- HAZARDOUS. Control Drawing for EAGLE20/30 devices according to Class 1 Division 2 Hazardous Locations Rev.: 2 Doc. No.: 000172287DNR...
  • Page 15 In accordance with the above-named EU directive(s), the EU conformity declaration will be at the disposal of the relevant authorities at the following address: Hirschmann Automation and Control GmbH Stuttgarter Str. 45-51 72654 Neckartenzlingen Germany...
  • Page 16 Recycling note  After usage, this device must be disposed of properly as electronic waste, in accordance with the current disposal regulations of your county, state, and country. Installation EAGLE20/30 Release 12 03/2021...

  • Page 17: About This Manual

    About this manual The “Installation” user manual contains a device description, safety instructions, a description of the display, and the other information that you need to install the device. Installation EAGLE20/30 Release 12 03/2021...

  • Page 18: Key

    The symbols used in this manual have the following meanings:  Listing Work step  Subheading  Installation EAGLE20/30 Release 12 03/2021...

  • Page 19: Description

    Network management software (for example Industrial HiVision) The Network Management Software Industrial HiVision provides you with options for smooth configuration and monitoring. You find further information on the Internet at the Hirschmann product pages: http://www.hirschmann.com/en/QR/INET-Industrial-HiVision  V.24 interface (locally on the device) The device provides you with a large range of functions, which the manuals for the operating software inform you about.

  • Page 20: Device Name And Product Code

    Item Product Character Description characteristic istic value 1 ... 7 Device EAGLE20 Router without gigabit ports EAGLE30 Router with gigabit ports (hyphen) – 9 ... 10 Number: 4 × Fast Ethernet ports 11 ... 12 Number: 0 ×...
  • Page 21 24 ... 25 Certifications Note: You will find detailed information on the certificates and declarations applying to your device in a separate overview. See table 5 on page 22. Table 4: Device name and product code Installation EAGLE20/30 Release 12 03/2021...
  • Page 22 Application case Certificates and Characteristic value declarations Standard applications UL 508 IEC/EN 62368-1 EN 61131-2 Oil and gas applications ANSI/UL 121201 – Class I, Div. 2 Substation applications IEC 61850-3 IEEE 1613 Navy applications DNV GL Railway applications EN 50121-4 Table 5: Assignment: application cases, certificates and declarations, characteristic values a.

  • Page 23: Device Views

    LED display elements for additional status information LED display elements The support of the function is dependent on the software release. Software support for the function is unimplemented at the time of publishing this manual. Installation EAGLE20/30 Release 12 03/2021...

  • Page 24: Rear View

    1.4.3 Supply voltage with the characteristic value CC For the redundant power supply of the device, two 2-pin terminal blocks are available. For further information see “Supply voltage with the characteristic value CC” on page Installation EAGLE20/30 Release 12 03/2021...

  • Page 25: Ethernet Ports

    IEEE 802.3 100BASE-FX/1000BASE-SX/1000BASE-LX standard. This port supports:  Full duplex mode 1.5.3 100/1000 Mbit/s twisted pair port (optional) Note: The following information applies only to device variants with HiSecOS, software versions 01.2.00 and higher. Installation EAGLE20/30 Release 12 03/2021...

  • Page 26: Wan Port (Optional)

    Aggregation of 2 links within the same port  SHDSL (Single Pair High Bit Rate Digital Subscriber Line) Function Pair 1 Ring Pair 0 Ring 3,6,7,8 — Table 7: Pin assignment of SHDSL port, RJ-45 socket Installation EAGLE20/30 Release 12 03/2021...

  • Page 27: Display Elements

    ACA storage medium inoperative Check the file system format See “SD card interface” on page 30. Deactivate the write protection on the ACA31 by pushing the lock towards the contacts. Installation EAGLE20/30 Release 12 03/2021...

  • Page 28: Digital Input (Optional)

    The device is establishing a link period data yellow flashing Device is transmitting and/or receiving data 1.7.4 Additional status information (optional) Note: Only for supply voltage with the following characteristic values:   VPN RD S1 S2 Installation EAGLE20/30 Release 12 03/2021...

  • Page 29: Management Interfaces

    A serial interface is provided on the RJ11 socket (V.24 interface) for the local connection of an external management station (VT100 terminal or PC with corresponding terminal emulation). This enables you to set up a connection to the Command Line Interface CLI and to the System Monitor. Installation EAGLE20/30 Release 12 03/2021...

  • Page 30: Sd Card Interface

    The USB interface has the following properties:  Supports the USB master mode  Supports USB 2.0 (data rate max. 480 MBit/s)  Connector type A  Supplies current of max. 500 mA Installation EAGLE20/30 Release 12 03/2021...

  • Page 31: Input/Output Interfaces

     The support of the function is dependent on the software release. Software support for the function is unimplemented at the time of publishing this manual. Figure 3: Input: 2-pin terminal block with screw locking Installation EAGLE20/30 Release 12 03/2021...

  • Page 32: Installation

    Note: For information about the position on the device see “Rear view” on page  Push the SD card into the slot with the beveled corner facing upwards.  Tighten the thumb screw hand-tight to fix the SD card. Installation EAGLE20/30 Release 12 03/2021...

  • Page 33: Installing And Grounding The Device

    DIN EN 60715, proceed as follows:  Slide the upper snap-in guide of the device into the DIN rail.  Press the media module downwards onto the clip-in bar.  Snap in the device. Installation EAGLE20/30 Release 12 03/2021...

  • Page 34: Grounding The Device

    The device variants featuring supply voltage with the characteristic value CC and not featuring SHDSL ports have a connection for functional grounding  Ground the device via the ground screw. Installing an SFP transceiver (optional) Prerequisites: Exclusively use Hirschmann SFP transceivers. Installation EAGLE20/30 Release 12 03/2021...

  • Page 35: Connecting The Terminal Blocks

    Do not touch the connection terminals. Failure to follow this instruction can result in death, serious injury, or equipment damage. Note: The supply voltage is connected to the device casing through protective elements exclusively. Installation EAGLE20/30 Release 12 03/2021...

  • Page 36: Supply Voltage With The Characteristic Value K9

    You have the option of supplying the supply voltage redundantly, without load distribution. Both supply voltage inputs are uncoupled. With a redundant supply, the supply voltage 1 (upper voltage input on the device) has priority. Installation EAGLE20/30 Release 12 03/2021...

  • Page 37: Supply Voltage With The Characteristic Value Cc

    Management. 2.5.3 Supply voltage with the characteristic value CC You have the option of supplying the supply voltage redundantly, without load distribution. Both supply voltage inputs are uncoupled. Installation EAGLE20/30 Release 12 03/2021...

  • Page 38: Signal Contact

    The connected voltage is limited by a current limitation device or a fuse. Observe the electrical threshold values for the signal contact. See “General technical data” on page 47.  Connect the signal contact lines with the terminal block connections. Installation EAGLE20/30 Release 12 03/2021...

  • Page 39: Operating The Device

    SF/UTP cables according to ISO/IEC 11801. Exclusively use shielded data cables to meet EMC requirements according to EN 50121- 4 and marine applications.  Connect the data cables according to your requirements. See “Ethernet ports” on page 25. Installation EAGLE20/30 Release 12 03/2021...

  • Page 40: 100/1000 Mbit/S F/O Port (Optional)

     Provide copper cabling to ensure sufficient distance between the power supply cables and data cables. Ideally, install the cables in separate cable channels.  Use shielded cables. Filling out the inscription label The information field for the IP address helps you identify your device. Installation EAGLE20/30 Release 12 03/2021...

  • Page 41: Making Basic Settings

     Input via the V.24 interface  Input via the HiView or Industrial HiVision application. You find further information about the applications HiView or Industrial HiVision on the Internet at the Hirschmann product pages: HiView http://www.hirschmann.com/en/QR/INET-HiView Industrial HiVision http://www.hirschmann.com/en/QR/INET-Industrial-HiVision ...
  • Page 42 Note: If you lost your password, then use the System Monitor to reset the password. For further information see: https://hirschmann-support.belden.com/en/kb/required-password-change- new-procedure-for-first-time-login Installation EAGLE20/30 Release 12 03/2021...

  • Page 43: Monitoring The Ambient Air Temperature

    The temperature displayed in the CLI and the GUI is the internal temperature of the device. It is up to 68 °F (20 °C) higher than the ambient temperature. This depends on the configuration of your device. Installation EAGLE20/30 Release 12 03/2021...

  • Page 44: Maintenance And Service

    Maintenance and service  When designing this device, Hirschmann largely avoided using high-wear parts. The parts subject to wear and tear are dimensioned to last longer than the lifetime of the product when it is operated normally. Operate this device according to the specifications.

  • Page 45: Disassembly

     Disconnect the terminal blocks.  Disconnect the grounding.  To remove the device from the DIN rail, press the device downwards and pull it out from under the DIN rail. Figure 9: Removal from the DIN rail Installation EAGLE20/30 Release 12 03/2021...

  • Page 46: Removing An Sfp Transceiver (Optional)

     Open the locking mechanism of the SFP transceiver (1).  Pull the SFP transceiver out of the slot via the open locking mechanism (2).  Close the SFP transceiver with the protection cap (3). Installation EAGLE20/30 Release 12 03/2021...

  • Page 47: Technical Data

    Power loss buffer >10 ms at 98 V AC Overload current protection on Non-replaceable fuse the device Back-up fuse Nominal rating: min. 2.5 A max. 20 A Characteristic: slow blow Peak inrush current <3.5 A Installation EAGLE20/30 Release 12 03/2021...
  • Page 48 Only use SFP transceivers with the “EEC” extension. c. +185 °F (+85 °C) for 16 hours (tested according to IEC 60068-2-2) d. Temperature of the ambient air at a distance of 2 in (5 cm) from the device Installation EAGLE20/30 Release 12 03/2021...
  • Page 49 2000 (6562) (Annex B) 3072 6144 14.5 Europe 32-TCPAM 2900 (9514) (Annex B) 2048 4096 14.5 Europe 16-TCPAM 3300 (10827) (Annex B) 1024 2048 13.5 Europe 16-TCPAM 4500 (14764) (Annex B) Table 9: Profiles with settings Installation EAGLE20/30 Release 12 03/2021...
  • Page 50 114,7 6,55 4.52 inch 0.26 2.76 89,9 3.54 Figure 11: Dimensions of the device variants without WAN ports with operating characteristic value S. For the characteristic value, see “Device name and product code” on page Installation EAGLE20/30 Release 12 03/2021...
  • Page 51 120,85 4.76 6,55 114,7 0.26 4.52 2.76 121,95 Figure 13: Dimensions of the device variants with WAN ports with operating characteristic value S. For the characteristic value, see “Device name and product code” on page Installation EAGLE20/30 Release 12 03/2021...
  • Page 52 4.57 0.26 4.52 inch 2.76 121,95 Figure 14: Dimensions of the device variants with WAN ports with operating characteristic value E and T. For the characteristic value, see “Device name and product code” on page Installation EAGLE20/30 Release 12 03/2021...
  • Page 53 EMC and immunity  Note: You will find detailed information on the certificates and declarations applying to your device in a separate overview. See table 5 on page 22. EMC interference Standard Navy applications Railway Substation emission applications applications applications Radiated emission EN 55032 Class A...
  • Page 54 EMC interference Standard Navy applications Railway Substation immunity applications applications applications EN 61000-4-3 80 MHz ... 800 MHz 10 V/m — 10 V/m 10 V/m EN 61000-4-3 800 MHz ... 1000 MHz 10 V/m — 20 V/m 10 V/m EN 61000-4-3 1400 MHz ...
  • Page 55 EMC interference Standard Navy applications Railway Substation immunity applications applications applications Damped oscillation - AC/DC supply connection EN 61000-4-18 line/ground — — — 2.5 kV IEEE C37.90.1 EN 61000-4-12 line/line — — — 1 kV IEEE C37.90.1 Damped oscillation – data line EN 61000-4-18 line/ground —...
  • Page 56 -LH/LC... LH 1550 nm 9/125 µm 5 dB ... 14.29 mi . 0.25 dB/km 19 ps/(nm×km) 22 dB .. 49.71 mi (23 km ... 80 km) Table 10: F/O port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver) Installation EAGLE20/30 Release 12 03/2021...
  • Page 57 . 80 km) Table 11: F/O port (bidirectional Gigabit Ethernet SFP transceiver) a. Including 3 dB system reserve when compliance with the fiber data is observed. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul Installation EAGLE20/30 Release 12 03/2021...
  • Page 58 MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul 10/100/1000 Mbit/s twisted pair port Length of a twisted pair segment max. 328 ft (100 m) (for Cat5e cable) Table 13: Network range: 10/100/1000 Mbit/s twisted pair port Installation EAGLE20/30 Release 12 03/2021...
  • Page 59 (exclusively for device variants featuring supply voltage with characteristic value KK) 2 × 2-pin terminal block for the supply voltage (only for device variants featuring supply voltage with characteristic value CC) 1 × Safety and general information sheet Installation EAGLE20/30 Release 12 03/2021...
  • Page 60 943 015-001 M-SFP-LX/LC EEC 943 897-001 M-SFP-LX+/LC 942 023-001 M-SFP-LX+/ LC EEC 942 024-001 M-SFP-LH/LC 943 042-001 M-SFP-LH/LC EEC 943 898-001 M-SFP-LH+/LC 943 049-001 M-SFP-LH+/LC EEC 942 119-001 Table 14: Accessory: Gigabit Ethernet SFP transceiver Installation EAGLE20/30 Release 12 03/2021...
  • Page 61 942 196-001 SFP-GIG-LX/LC EEC 942 196-002 Table 14: Accessory: Gigabit Ethernet SFP transceiver a. You will find further information on certifications on the Internet on the Hirschmann product pages (www.hirschmann.com). Bidirectional Gigabit Ethernet SFP transceiver Order number M-SFP-BIDI Type A LX/LC EEC...
  • Page 62 If your device has a shipping approval according to DNV GL, you find the approval mark printed on the device label. You will find out whether your device has other shipping approvals on the Hirschmann website at www.hirschmann.com in the product information.

  • Page 63: A Further Support

    Further support Technical questions For technical questions, please contact any Hirschmann dealer in your area or Hirschmann directly. You find the addresses of our partners on the Internet at http:// www.hirschmann.com. A list of local telephone numbers and email addresses for technical support...
