Sony STR-DN1010 Service Manual page 89

Ref. No. Part No. Description
R3220 1-218-933-11 METAL CHIP
R3221 1-218-933-11 METAL CHIP
R3222 1-218-941-81 METAL CHIP
R3223 1-218-935-11 METAL CHIP
R3224 1-218-935-11 METAL CHIP
R3225 1-218-965-11 METAL CHIP
R3226 1-218-973-11 METAL CHIP
R3227 1-218-933-11 METAL CHIP
R3228 1-218-965-11 METAL CHIP
R3229 1-218-935-11 METAL CHIP
R3230 1-218-935-11 METAL CHIP
R3231 1-218-961-11 METAL CHIP
R3232 1-208-957-11 METAL CHIP
R3233 1-218-961-11 METAL CHIP
R3234 1-218-961-11 METAL CHIP
R3235 1-218-935-11 METAL CHIP
R3236 1-218-935-11 METAL CHIP
R3238 1-218-965-11 METAL CHIP
R3241 1-208-695-11 METAL CHIP
R3242 1-208-695-11 METAL CHIP
R3243 1-208-695-11 METAL CHIP
R3244 1-208-695-11 METAL CHIP
R3245 1-218-965-11 METAL CHIP
R3247 1-218-961-11 METAL CHIP
R3248 1-218-990-81 SHORT CHIP
R3249 1-218-933-11 METAL CHIP
R3250 1-218-990-81 SHORT CHIP
R3251 1-218-933-11 METAL CHIP
R3252 1-218-965-11 METAL CHIP
R3253 1-218-965-11 METAL CHIP
R3254 1-218-937-11 METAL CHIP
R3255 1-218-937-11 METAL CHIP
R3256 1-218-990-81 SHORT CHIP
R3257 1-218-937-11 METAL CHIP
R3258 1-218-938-11 METAL CHIP
R3259 1-218-938-11 METAL CHIP
R3260 1-218-938-11 METAL CHIP
R3261 1-218-938-11 METAL CHIP
R3262 1-218-938-11 METAL CHIP
R3264 1-218-963-11 METAL CHIP
R3266 1-218-990-81 SHORT CHIP
R3267 1-218-990-81 SHORT CHIP
R3268 1-218-990-81 SHORT CHIP
R3269 1-218-990-81 SHORT CHIP
R3270 1-218-958-11 METAL CHIP
R3271 1-218-958-11 METAL CHIP
R3272 1-218-958-11 METAL CHIP
R3273 1-218-958-11 METAL CHIP
R3274 1-218-965-11 METAL CHIP
R3275 1-218-958-11 METAL CHIP
R3276 1-218-958-11 METAL CHIP
R3277 1-218-965-11 METAL CHIP
R3278 1-208-957-11 METAL CHIP
R3281 1-218-941-81 METAL CHIP
R3282 1-218-965-11 METAL CHIP
R3284 1-218-965-11 METAL CHIP
R3285 1-218-929-11 METAL CHIP
R3286 1-218-929-11 METAL CHIP
R3287 1-218-929-11 METAL CHIP
R3288 1-218-949-11 METAL CHIP
Remark
22 5% 1/16W
22 5% 1/16W
100 5% 1/16W
33 5% 1/16W
33 5% 1/16W
10K 5% 1/16W
47K 5% 1/16W
22 5% 1/16W
10K 5% 1/16W
33 5% 1/16W
33 5% 1/16W
4.7K 5% 1/16W
820K 0.5% 1/16W
4.7K 5% 1/16W
4.7K 5% 1/16W
33 5% 1/16W
33 5% 1/16W
10K 5% 1/16W
3.3K 0.5% 1/16W
3.3K 0.5% 1/16W
3.3K 0.5% 1/16W
3.3K 0.5% 1/16W
10K 5% 1/16W
4.7K 5% 1/16W
0
22 5% 1/16W
0
22 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
47 5% 1/16W
47 5% 1/16W
0
47 5% 1/16W
56 5% 1/16W
56 5% 1/16W
56 5% 1/16W
56 5% 1/16W
56 5% 1/16W
6.8K 5% 1/16W
0
0
0
0
2.7K 5% 1/16W
2.7K 5% 1/16W
2.7K 5% 1/16W
2.7K 5% 1/16W
10K 5% 1/16W
2.7K 5% 1/16W
2.7K 5% 1/16W
10K 5% 1/16W
820K 0.5% 1/16W
100 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10 5% 1/16W
10 5% 1/16W
10 5% 1/16W
470 5% 1/16W
Ref. No. Part No. Description
R3289 1-218-949-11 METAL CHIP
R3290 1-218-949-11 METAL CHIP
R3291 1-218-949-11 METAL CHIP
R3292 1-218-941-81 METAL CHIP
R3296 1-218-933-11 METAL CHIP
R3297 1-218-953-11 METAL CHIP
R3300 1-218-973-11 METAL CHIP
R3302 1-218-937-11 METAL CHIP
R3331 1-218-965-11 METAL CHIP
R3404 1-218-990-81 SHORT CHIP
R3405 1-218-929-11 METAL CHIP
R3406 1-218-929-11 METAL CHIP
R3407 1-218-929-11 METAL CHIP
R3408 1-218-935-11 METAL CHIP
R3409 1-218-935-11 METAL CHIP
R3410 1-218-935-11 METAL CHIP
R3411 1-218-935-11 METAL CHIP
R3514 1-218-973-11 METAL CHIP
R3521 1-218-941-81 METAL CHIP
R3522 1-218-941-81 METAL CHIP
R3530 1-218-933-11 METAL CHIP
R3531 1-218-933-11 METAL CHIP
R3536 1-218-933-11 METAL CHIP
R3540 1-218-933-11 METAL CHIP
R3544 1-218-929-11 METAL CHIP
R3545 1-218-941-81 METAL CHIP
R3546 1-218-989-11 METAL CHIP
R3548 1-216-805-11 METAL CHIP
R3549 1-216-805-11 METAL CHIP
R3550 1-216-805-11 METAL CHIP
R3551 1-216-805-11 METAL CHIP
R3552 1-216-805-11 METAL CHIP
R3554 1-216-805-11 METAL CHIP
R3556 1-216-805-11 METAL CHIP
R3557 1-216-813-11 METAL CHIP
R3563 1-218-941-81 METAL CHIP
R3564 1-216-864-11 SHORT CHIP
R3565 1-218-929-11 METAL CHIP
R3566 1-218-929-11 METAL CHIP
R3567 1-218-929-11 METAL CHIP
R3568 1-218-937-11 METAL CHIP
R3569 1-218-950-81 METAL CHIP
R3570 1-218-937-11 METAL CHIP
R3571 1-218-937-11 METAL CHIP
R3572 1-218-937-11 METAL CHIP
R3573 1-218-937-11 METAL CHIP
R3574 1-218-937-11 METAL CHIP
R3575 1-218-937-11 METAL CHIP
R3576 1-218-929-11 METAL CHIP
R3577 1-218-929-11 METAL CHIP
R3578 1-218-961-11 METAL CHIP
R3579 1-218-973-11 METAL CHIP
R3580 1-208-883-81 METAL CHIP
R3581 1-218-941-81 METAL CHIP
R3582 1-220-876-81 METAL CHIP
R3583 1-218-929-11 METAL CHIP
R3584 1-218-929-11 METAL CHIP
R3585 1-218-973-11 METAL CHIP
R3593 1-218-965-11 METAL CHIP
R3594 1-218-973-11 METAL CHIP
STR-DN1010
DIGITAL VIDEO
Remark
470 5% 1/16W
470 5% 1/16W
470 5% 1/16W
100 5% 1/16W
22 5% 1/16W
1K 5% 1/16W
47K 5% 1/16W
47 5% 1/16W
10K 5% 1/16W
0
10 5% 1/16W
10 5% 1/16W
10 5% 1/16W
33 5% 1/16W
33 5% 1/16W
33 5% 1/16W
33 5% 1/16W
47K 5% 1/16W
100 5% 1/16W
100 5% 1/16W
22 5% 1/16W
22 5% 1/16W
22 5% 1/16W
22 5% 1/16W
10 5% 1/16W
100 5% 1/16W
1M 5% 1/16W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
220 5% 1/10W
100 5% 1/16W
0
10 5% 1/16W
10 5% 1/16W
10 5% 1/16W
47 5% 1/16W
560 5% 1/16W
47 5% 1/16W
47 5% 1/16W
47 5% 1/16W
47 5% 1/16W
47 5% 1/16W
47 5% 1/16W
10 5% 1/16W
10 5% 1/16W
4.7K 5% 1/16W
47K 5% 1/16W
680 0.5% 1/16W
100 5% 1/16W
18 0.5% 1/16W
10 5% 1/16W
10 5% 1/16W
47K 5% 1/16W
10K 5% 1/16W
47K 5% 1/16W
89 89
