STR-DN1010
VIDEO
Ref. No.
Part No.
Description
< CONNECTOR >
CN6202
1-770-408-11
CONNECTOR, BOARD TO BOARD 14P
< DIODE >
D6101
6-501-817-01
DIODE MA2J1110GLS0
D6102
6-501-817-01
DIODE MA2J1110GLS0
D6503
6-502-218-01
DI RB060M-30TR
D6504
6-502-961-01
DI DA2J10100L
D6505
6-502-961-01
DI DA2J10100L
< FERRITE BEAD >
FB6001
1-469-152-11
FERRITE, EMI (SMD) (2012)
FB6002
1-469-152-11
FERRITE, EMI (SMD) (2012)
< IC >
IC6001
6-706-767-01
IC NJM2586AM
IC6101
8-759-822-05
IC LA7213
IC6102
8-759-822-05
IC LA7213
IC6205
6-713-031-01
IC KIA7805API-U/PF
IC6206
6-711-998-01
IC KIA7905PI
IC6302
6-704-199-01
IC NJM2595M-TE2
< JACK >
J6001
1-816-592-11
JACK, PIN 9P (COMPONENT VIDEO ASSIGNABLE
J6002
1-821-278-12
JACK 3P (COMPONENT VIDEO ASSIGNABLE
J6004
1-815-043-11
JACK, PIN 2P
J6005
1-794-978-11
JACK, PIN 3P (SAT/CATV VIDEO IN, BD VIDEO IN,
< JUMPER RESISTOR >
JR6000
1-216-864-11
SHORT CHIP
< TRANSISTOR >
Q6105
6-551-469-01
TRANSISTOR
Q6106
6-551-272-01
TRANSISTOR
< RESISTOR >
R6001
1-211-990-11
METAL CHIP
R6002
1-211-990-11
METAL CHIP
R6003
1-211-990-11
METAL CHIP
R6004
1-211-990-11
METAL CHIP
R6005
1-211-990-11
METAL CHIP
R6006
1-211-990-11
METAL CHIP
R6007
1-211-990-11
METAL CHIP
R6008
1-211-990-11
METAL CHIP
R6009
1-211-990-11
METAL CHIP
R6013
1-211-990-11
METAL CHIP
R6014
1-211-990-11
METAL CHIP
R6015
1-211-990-11
METAL CHIP
R6016
1-211-990-11
METAL CHIP
R6017
1-211-990-11
METAL CHIP
R6018
1-211-990-11
METAL CHIP
R6101
1-216-815-11
METAL CHIP
R6102
1-216-815-11
METAL CHIP
R6103
1-216-847-11
METAL CHIP
R6104
1-216-847-11
METAL CHIP
R6105
1-216-829-11
METAL CHIP
100
Remark
(INPUT ONLY) IN 1/IN 2/MONITOR OUT)
(INPUT ONLY) IN 3)
(VIDEO 1 VIDEO IN, MONITOR VIDEO OUT)
VIDEO 1 VIDEO OUT)
0
RT3N33M-T111-1
RT3CLLM
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
330
5%
1/10W
330
5%
1/10W
150K
5%
1/10W
150K
5%
1/10W
4.7K
5%
1/10W
Ref. No.
Part No.
Description
R6106
1-216-829-11
METAL CHIP
R6107
1-216-813-11
METAL CHIP
R6111
1-216-825-11
METAL CHIP
R6112
1-216-821-11
METAL CHIP
R6113
1-216-825-11
METAL CHIP
R6114
1-216-821-11
METAL CHIP
R6124
1-216-815-11
METAL CHIP
R6125
1-216-815-11
METAL CHIP
R6301
1-211-990-11
METAL CHIP
R6302
1-211-990-11
METAL CHIP
R6304
1-211-990-11
METAL CHIP
R6306
1-211-990-11
METAL CHIP
R6307
1-211-990-11
METAL CHIP
R6311
1-216-864-11
SHORT CHIP
*************************************************************
MISCELLANEOUS
**************
55
1-828-384-11
WIRE (FLAT TYPE) (23 CORE)
56
1-828-312-51
WIRE (FLAT TYPE) (9 CORE)
0 103
1-777-071-83
CORD, POWER (UK, ECE)
0 103
1-834-270-11
CORD, POWER (US, CND)
0 103
1-833-566-21
POWER SUPPLY CORD (AUS)
155
1-828-954-11
WIRE (FLAT TYPE) (9 CORE) (US, CND)
155
1-828-964-11
WIRE (FLAT TYPE) (11 CORE) (UK, AUS, ECE)
156
1-828-660-11
WIRE (FLAT TYPE) (27 CORE)
0 F900
1-532-465-33
FUSE, T3.15AL 250V (UK, AUS, ECE)
0 F900
1-533-311-12
FUSE, GLASS (DIA.5) 8A 125V (US, CND)
IC604
6-702-390-01
TRANSISTOR
IC605
6-702-391-01
TRANSISTOR
IC606
6-702-390-01
TRANSISTOR
IC607
6-702-391-01
TRANSISTOR
IC608
6-702-390-01
TRANSISTOR
IC609
6-702-391-01
TRANSISTOR
IC610
6-702-390-01
TRANSISTOR
IC611
6-702-391-01
TRANSISTOR
IC612
6-702-390-01
TRANSISTOR
IC613
6-702-391-01
TRANSISTOR
IC614
6-702-390-01
TRANSISTOR
IC615
6-702-391-01
TRANSISTOR
IC616
6-702-390-01
TRANSISTOR
IC617
6-702-391-01
TRANSISTOR
0 T901
1-445-652-21
POWER TRANSFORMER (MAIN) (UK, AUS, ECE)
0 T901
1-445-797-11
POWER TRANSFORMER (MAIN) (US)
0 T901
1-445-824-11
POWER TRANSFORMER (MAIN) (CND)
TN1
1-693-737-21
TUNER (FM/AM) (UK, AUS, ECE)
TN1
1-693-779-11
TUNER (FM/AM) (US, CND)
*************************************************************
ACCESSORIES
************
1-126-947-11
CAP, ELECT 47M
1-487-852-11
REMOTE COMMANDER RM-AAP052
1-487-857-11
REMOTE COMMANDER RM-AAP051 (US, CND)
1-501-374-12
ANTENNA, LOOP (AM loop antenna (aerial))
1-542-774-21
MEASUREMENT MIC (MONO)
1-770-019-71
ADAPTOR, CONVERSION PLUG 3P (UK)
1-793-184-51
CONNECTOR (F TYPE ADAPTOR)
3-254-070-11
SCREW
4-174-068-12
INSTRUCTION MANUAL (ENGLISH)
Note: If wire (fl at type) is replaced, install it after bending
it in the same form as that before replacement.
Remark
4.7K
5%
1/10W
220
5%
1/10W
2.2K
5%
1/10W
1K
5%
1/10W
2.2K
5%
1/10W
1K
5%
1/10W
330
5%
1/10W
330
5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
75
0.5%
1/10W
0
MN2488-OPY-MK
MP1620-OPY-MK
MN2488-OPY-MK
MP1620-OPY-MK
MN2488-OPY-MK
MP1620-OPY-MK
MN2488-OPY-MK
MP1620-OPY-MK
MN2488-OPY-MK
MP1620-OPY-MK
MN2488-OPY-MK
MP1620-OPY-MK
MN2488-OPY-MK
MP1620-OPY-MK
(UK, AUS, ECE)
(Optimizer microphone (ECM-AC2))
