Ref. No.
Part No.
Description
D2016
8-719-049-09
DIODE 1SS367-T3SONY
D2017
8-719-049-09
DIODE 1SS367-T3SONY
D2018
8-719-049-09
DIODE 1SS367-T3SONY
D2019
6-501-817-01
DIODE MA2J1110GLS0
D2022
8-719-989-03
DIODE DAN222
D2023
8-719-989-03
DIODE DAN222
D2024
6-501-817-01
DIODE MA2J1110GLS0
D2025
8-719-989-03
DIODE DAN222
D2383
6-501-817-01
DIODE MA2J1110GLS0
< FERRITE BEAD >
FB2000
1-400-862-11
BEAD, FERRITE
FB2001
1-400-862-11
BEAD, FERRITE
FB2003
1-216-864-11
SHORT CHIP
FB2004
1-469-139-21
FERRITE, EMI (SMD) (2012)
FB2005
1-469-139-21
FERRITE, EMI (SMD) (2012)
FB2006
1-400-862-11
BEAD, FERRITE
FB2007
1-469-139-21
FERRITE, EMI (SMD) (2012)
FB2008
1-400-862-11
BEAD, FERRITE
FB2009
1-400-862-11
BEAD, FERRITE
FB2010
1-400-862-11
BEAD, FERRITE
FB2011
1-400-862-11
BEAD, FERRITE
FB2012
1-400-862-11
BEAD, FERRITE
FB2013
1-216-797-11
METAL CHIP
FB2014
1-400-862-11
BEAD, FERRITE
FB2015
1-400-862-11
BEAD, FERRITE
* FB2016
1-400-973-21
INDUCTOR (EMI FERRITE)
FB2017
1-400-862-11
BEAD, FERRITE
FB2018
1-400-862-11
BEAD, FERRITE
FB2019
1-400-862-11
BEAD, FERRITE
* FB2020
1-400-973-21
INDUCTOR (EMI FERRITE)
FB2021
1-400-862-11
BEAD, FERRITE
FB2022
1-400-862-11
BEAD, FERRITE
FB2023
1-469-152-11
FERRITE, EMI (SMD) (2012)
FB2024
1-469-152-11
FERRITE, EMI (SMD) (2012)
FB2025
1-469-152-11
FERRITE, EMI (SMD) (2012)
FB2027
1-469-139-21
FERRITE, EMI (SMD) (2012)
FB2028
1-469-139-21
FERRITE, EMI (SMD) (2012)
FB2029
1-469-139-21
FERRITE, EMI (SMD) (2012)
FB2031
1-469-139-21
FERRITE, EMI (SMD) (2012)
< IC >
IC2000
6-708-742-01
IC MM1663DTRE
IC2001
6-713-032-01
IC KIA7809API-U/PF
IC2002
6-600-466-01
IC TORX147L (SONY) (DIGITAL (ASSIGNABLE)
IC2003
6-600-466-01
IC TORX147L (SONY) (DIGITAL (ASSIGNABLE)
IC2004
6-600-466-01
IC TORX147L (SONY) (TV OPTICAL IN)
IC2005
6-712-613-01
IC SI-3010KM-TLS
IC2006
6-713-642-01
IC LC89058W-E
IC2007
8-759-524-48
IC TC74VHC393FT (EL)
IC2008
8-759-524-10
IC TC74VHC157FT (EL)
IC2009
8-759-447-77
IC TC7WH74FU (TE12R)
IC2010
6-705-337-01
IC TK11150CSCL-G
IC2011
8-759-523-81
IC TC74VHC08FT (EL)
IC2012
6-710-554-01
IC PCM1808PWR
IC2013
8-759-082-61
IC TC4W53FU
IC2015
8-759-096-87
IC TC7WU04FU (TE12R)
IC2016
6-712-614-01
IC SI-3050KM-TLS
Remark
0
10
5%
1/10W
OPTICAL SAT/CATV IN)
OPTICAL BD IN)
Ref. No.
Part No.
Description
IC2017
6-712-616-01
IC SI-3033KM-TLS
IC2018
A-1755-487-A
IC MB91F467RAPMC-GE1 (for SERVICE)
IC2019
8-759-058-62
IC TC7S08FU (TE85R)
IC2020
6-702-913-01
IC S-80929CNMC-G8ZT2G
IC2021
8-759-277-63
IC TC7W14FU (TE12R)
IC2022
(Not supplied)
IC CAT24C64WI-GT3
IC2023
6-707-870-01
IC TC74VHC157FT (EKJ)
IC2024
6-711-874-01
IC WM8768GEDS/R
IC2025
8-759-710-97
IC NJM4565M-D
IC2026
8-759-710-97
IC NJM4565M-D
IC2027
8-759-710-97
IC NJM4565M-D
IC2028
8-759-710-97
IC NJM4565M-D
IC2029
6-706-487-01
IC TC7SH08FU (T5RSOYJF) (US, CND)
IC2030
6-706-478-01
IC TC7SET08FU (T5RSOJF) (US, CND)
IC2031
6-706-478-01
IC TC7SET08FU (T5RSOJF) (US, CND)
IC2032
6-707-870-01
IC TC74VHC157FT (EKJ)
IC2033
6-709-861-01
IC TC7SH126FU (T5RSOYF)
IC2034
6-702-913-01
IC S-80929CNMC-G8ZT2G
IC2035
6-706-487-01
IC TC7SH08FU (T5RSOYJF)
< JACK >
J2000
1-784-431-11
JACK, PIN 1P
(DIGITAL (ASSIGNABLE) COAXIAL DVD IN)
< JUMPER RESISTOR >
JR2000
1-211-950-11
SHORT CHIP
JR2001
1-211-950-11
SHORT CHIP
JR2002
1-211-950-11
SHORT CHIP
JR2003
1-211-950-11
SHORT CHIP
JR2004
1-211-950-11
SHORT CHIP
JR2005
1-211-950-11
SHORT CHIP
JR2006
1-211-950-11
SHORT CHIP
JR2007
1-211-950-11
SHORT CHIP
JR2008
1-211-950-11
SHORT CHIP
JR2009
1-211-950-11
SHORT CHIP
JR2010
1-216-296-11
SHORT CHIP
< COIL >
L2000
1-469-555-21
INDUCTOR
< TRANSISTOR >
Q2000
6-551-690-01
TRANSISTOR
Q2002
6-551-696-01
TRANSISTOR
Q2003
6-551-272-01
TRANSISTOR
Q2005
8-729-027-43
TRANSISTOR
< RESISTOR >
R2002
1-216-825-11
METAL CHIP
R2002
1-216-864-11
SHORT CHIP
R2003
1-216-841-11
METAL CHIP
R2004
1-216-833-11
METAL CHIP
R2005
1-216-833-11
METAL CHIP
R2006
1-216-817-11
METAL CHIP
R2007
1-216-833-11
METAL CHIP
R2008
1-216-809-11
METAL CHIP
R2009
1-216-821-11
METAL CHIP
R2010
1-216-833-11
METAL CHIP
R2011
1-216-833-11
METAL CHIP
Note: IC2022 cannot exchange with single. When this part is
damaged, exchange the entire mounted board.
STR-DN1010
DIGITAL
Remark
0
0
0
0
0
0
0
0
0
0
0
10UH
RT3N11M-TP-1
ISA1235AC1TP-1EF
RT3CLLM
DTC114EKA-T146
2.2K
5%
1/10W
(UK, AUS, ECE)
0 (US, CND)
47K
5%
1/10W
(UK, AUS, ECE)
10K
5%
1/10W
10K
5%
1/10W
470
5%
1/10W
10K
5%
1/10W
100
5%
1/10W
1K
5%
1/10W
10K
5%
1/10W
10K
5%
1/10W
83
83
