4.6 Rotating Arm
Chapter 4: Removal, Replacement, and Adjustment Procedures
WARNING:
Ensure the rotating arm is supported before removing the retaining ring.
Failure to do so could result in personal injury or equipment damage.
5. Before removing the retaining ring (E), support the rotating arm (F) to
prevent it from falling through the vertical tube (G).
6. Using the retaining ring removal/installation tool, remove the retaining ring
(E) and the flat washer (H).
7. Remove the rotating arm (F) from the vertical tube (G).

Replacement

1. Install the rotating arm (F) into the vertical tube (G).
2. Install the flat washer (H).
3. Using the retaining ring removal/installation tool, install the retaining ring
(E).
SHOCK HAZARD:
Do not pinch the wires during installation. Pinched wires can cause an
electrical shock hazard, resulting in personal injury or equipment
damage.
4. Connect the electrical connectors (D), and push them into the vertical tube
(G) to prevent pinching them.
5. Using a phillips head screwdriver, install the screw (A) and the plastic
cover (B) to the top of the upright pole (C).
6. Install the lamp head/yoke assembly. See "Lamp Head/Yoke Assembly" on
page 4-13.
