4.3

Lamp

Tools required:

Removal

SHOCK HAZARD:
Unplug the unit from its power source. Failure to do so could result in
personal injury and equipment damage.
1. Unplug the unit from its power source.
WARNING:
The Prima™ Procedural Light operates at a high temperature. Allow the
unit to cool for at least 30 minutes before performing any preventive
maintenance or repair procedures. Failure to do so could result in
personal injury.
2. Allow the unit to cool for at least 30 minutes.
3. Remove the rear housing cover (A) from the lamp head (B) by pulling the
cover (A) away from the lamp head (B) (see figure 4-3 on page 4-8).
4. Pull the knob (C) on the lamp holder subassembly (D), and remove the
lamp holder subassembly (D) from the lamp head (B).
CAUTION:
Do not touch the lamp, the lens, or the inner surface of the reflector
directly. Body oils may significantly lower the life expectancy of these
parts and cause equipment damage.
5. Using a clean, dry cloth, remove the lamp (E) from the socket (F).
NOTE:
It may help to wiggle the lamp (E) slightly during removal.
Prima™ Procedural Light Service Manual (man247ra)
DRAFT 6/4/99
Chapter 4: Removal, Replacement, and Adjustment Procedures
Clean, dry cloth

4.3 Lamp

4
Page 4 - 7
