Hill-Rom Prima Procedural Light Service Manual page 73

Item Number Part Number
1 64927 (7925)
2 64954 (7925)
3 64955 (7925)
4 64956 (7925)
5 64985 (7925)
6 64957 (7925)
7 64958 (7925)
8 64959 (7925)
9 64960 (7925)
10
11 64962 (7925)
12 64963 (7925)
13 64964 (7925)
14 64965 (7925)
15 64966 (7925)
16 64967 (7925)
17 64968 (7925)
18 64969 (7925)
19 64970 (7925)
20 64971 (7925)
21 64972 (7925)
22 64973 (7925)
23 64974 (7925)
24 64975 (7925)
25 64976 (7925)
26 64977 (7925)
27 64978 (7925)
28 64979 (7925)
29 64980 (7925)
30 64981 (7925)
31 69141 (7925)
Prima™ Procedural Light Service Manual (man247ra)
DRAFT 6/4/99
Table 5-2. Lamp Head/Yoke Assembly
Quantity
1 Lamp head/yoke assembly
1 Yoke subassembly
1 Housing subassembly
1 Pivot, lower yoke, small
1 Washer
1 Washer, cap retention, small
1 Washer, belleville, spring
1 Washer
1 Nut, hex
2 Insulation, #8 fiberglass sleeve
2 Connector, crimp, 1/4" closed loop
1 Main support plate subassembly
5 Lockwasher
3 Nut, 1/4"—32 hex
3 Banana jack
1 Handle mount
2 Lockwasher
2 Screw
2 Spacer
3 Clip subassembly
1 Reflector, dichroic glass
1 Clamping ring
1 Lens subassembly
3 Screw, pan head
3 Lockwasher, external tooth
1 Rear cover subassembly
1 Bezel
1 Cap, yoke, small
1 Lamp holder subassembly
1 Lamp, quartz halogen
