Getting Started

WARNING:
Only facility-authorized maintenance personnel should troubleshoot the
Prima™ Procedural Light. Troubleshooting by unauthorized personnel
could result in personal injury or equipment damage.
Begin each procedure in this chapter with step 1. Follow the sequence outlined
(each step assumes the previous step has been completed). In each step, the
normal operation of the product can be confirmed by answering Yes or No to
the statement. Your response will lead to another step in the procedure, a repair
analysis procedure (RAP), or a component replacement. If more than one
component is listed, replace them in the given order.
Start with Initial Actions to begin gathering information about the problem.
Perform the Function Checks to isolate or identify a problem and to verify the
repair after completing each corrective action (replacing or adjusting a part,
seating a connector, etc.).
Perform the Final Actions after the Function Checks to verify the repair.
If troubleshooting procedures do not isolate the problem, call Hill-Rom
Technical Support at (800) 445-3720 for assistance.

Initial Actions

Use Initial Actions to gather information from operators concerning problems
with the Prima™ Procedural Light. Note symptoms or other information
concerning the problem that the operator describes. This information helps
identify the probable cause.
1. Someone who can explain the problem is available.
Yes
↓
2. Ask that person to demonstrate or explain the problem. The problem can be
duplicated.
Yes
↓
Prima™ Procedural Light Service Manual (man247ra)
DRAFT 6/4/99
No
→ Go to "Function Checks" on page 2-4.
No
→ Go to "Function Checks" on page 2-4.

Getting Started

Chapter 2: Troubleshooting Procedures
2
Page 2 - 3
