3.1 MECHANICAL AND ELECTRICAL SPECIFICATIONS

Weight
Min. Flow Area
Max Flow
Max Operating Pressure
Materials Used
Nominal Operating voltage:
Motor current:
Elevation motor:
Horizontal rotation motor:
Nozzle motor:
At rest current:
Recommended fuse or circuit breaker size:
Operating temperature range:
Environmental Rating: All components designed to meet minimum rating of NEMA 4 (IP65).
Wireless Operator Station
Charging Cradle
Nominal Operating Voltage
Operating Current
Recommended Fuse or Circuit Breaker
Transmitter Batteries
Transmitter Power
Operating Frequency
Agency Approvals
©Copyright Task Force Tips, Inc. 2004-2005
MECHANICAL SPECIFICATIONS
Manual 25 lbm
Electric 37 lbm
4" inlets 12.6 in2
3" inlets 7.07 in2
2000 GPM
200 PSI
ANSI A356.0-T6 Aluminum, Stainless, Nylon
ELECTRICAL SPECIFICATIONS
12 or 24 VDC
(field changable)
Nominal*
6 amps
6 amps
1 amp
*with rated water pressure applied
.25 amps
15 amps @ 12 volts, 7.5 amps @ 24 volts
-30F to +120F (-34C to +49C)
12 or 24 VDC
0.15 amps
2 amps
Use ONLY four (4) AA NiCad Batteries
5mW
2.4 GHz
FCC Part 15 - United States
ISC - Canada
CE - European Union
5
11.4 kg
16.8 kg
81.1 cm2
45.6 cm2
7,600 LPM
14 BAR
Limit
15 amps
10 amps
5 amps
