5.7 COMMUNICATION INTERFACE BOX

This Communication Interface Box converts discrete input signals into serial communications for controlling the monitor. The discrete
input signals can be from a joystick, toggle switches, relay contacts or Canbus output module. The interface box accepts +12/24 VDC
signals, but can be field changed to accept ground signals. The installer will need to mount the interface box and connect the cable to a
primary operator station or directly to the monitor.

5.7.1 ENCLOSURE MOUNTING

Select proper enclosure location. Enclosure is designed to be surface mounted and the size is 5" x 3 1/8" (127 x 80mm). Height of
enclosure is 2 3/8" (60mm). Refer to Figure 5.6.1 for mounting hole dimensions.

5.7.2 ELECTRICAL WIRING

See section 5.1.2C for connecting power & communication cable. .
See figure 5.7.2 for connecting INPUTS cable.
See section 5.10 if connecting directly to monitor
5.7.3 INPUTS SIGNAL CONFIGURATION
The Communication Interface Box is shipped from the factory configured to accept +12/24 volt DC input signals, but can be field
changed to accept ground input signals.
To change the configuration:
1. Remove lid from enclosure.
2. Remove jumper to select GROUND inputs or install jumper to select VOLTAGE inputs.
3. Replace lid. Verify rubber seal is clean and undamaged. Verify that no wires are caught between lid and box.
MODE JUMPER
GROUND
INPUTS

5.8 MONITOR POSITION DISPLAY

The monitor position display is supplied with a 10' (3 m) long 4-conductor cable. The installer will need to surface mount the enclosure in
a dry area and connect the cable to power and the communication link of the monitor. Display is designed for use with 180° total
horizontal axis travel.
5.8.1 ENCLOSURE MOUNTING
Select proper location for display.
The display is not weather proof
and needs to be inside a protected
area such as in the cab.
Fig 5.8.1
Monitor Position Display
Hole Dimensions
