6.4.3 MONSOON MONITOR FRICTION LOSS

0
20
16 MONSOON MONITOR FRICTION LOSS
12
8
4
0
0

6.5 STREAM STRAIGHTENERS

6.5.1 STREAM STRAIGHTENERS WITH STACKED TIP NOZZLES

Turbulence though the Monsoon
Monitor is very low but stream quality
and reach can be improved with the
u s e o f t h e i n t e g r a l s t r e a m
straightener on the TFT stacked tip
nozzle. See figure 6.5.1 for the
stacked tip's integral stream
straightener friction loss.
0
20
16
TFT STACKED TIP INTEGRAL STREAM
STRAIGHTENER FRICTION LOSS
12
8
4
0
0

6.5.2 STREAM STRAIGHTENERS WITH FOG NOZZLES

When using a fog nozzle it is
recommended that no stream
straightener be used since the fog
nozzle's flow path generally serves
as a stream straightener. Use of a
stream straightener with a fog nozzle
will increase the stresses on the
monitor's gear train and may lead to
premature wear.
©Copyright Task Force Tips, Inc. 2004-2005
1000 2000 3000
4 PSI AT 1000 GPM
500
Fig 6.4.3F - Monsoon Monitor Friction Loss
1000 2000 3000
3 PSI AT 1000 GPM
500
Fig 6.5.1 - TFT Stack Tip Integral Stream Straightener Friction Loss
(LPM)
4000 5000
15 PSI AT 2000 GPM
1000 1500
Flow (GPM)
(LPM)
4000 5000
13 PSI AT 2000 GPM
1000 1500
Flow (GPM)
32
6000 7000
1.2
1.0
0.8
0.6
0.4
0.2
0.0
2000
OK
6000 7000
1.2
1.0
0.8
0.6
0.4
0.2
0.0
2000
NOT OK
