# DESCRIPTION
1 CABLE-POWER & COM 2C#14
2 1/4-20 X 1/2 BUTTON HEAD CAP SCREW
3 .375 OD LOOP CLAMP STAINLESS
4 LOWER WIRE SKIRT
5 UPPER WIRE SKIR
6 BALL 5/16" STAINLESS
10 1/4-28 X 1/2 SOCKET HEAD CAP SCREW
11 CONTROL BOX BRACKET
11* CONTROL BOX BRACKET FOR LADDER & PLATFORM
12 HEYCO BLACK DOME PLUG #2643
13 MAIN MONITOR CONTROL BOX
14 .250 OD LOOP CLAMP STAINLESS
15 10-24 X 3/8 BUTTON HEAD CAP SCREW
16 CLOSURE CAP ASSEMBLY
17 CABLE - 2 POLE FEMALE PLUG
20 GEAR MOTOR SUBASSEMBLY
(#20 Contains Items #21 Thru #32, Except #27))
21 CUP SEAL 1.0625 X .5625 X 1/4
22 6-32 X 5/16 LONG SHCS WITH HEAD SEAL
23 MOTOR SOCKET
24 O-RING-038 2-5/8 ID 1/16 C/S
25 GEAR MOTOR WITH ENCODER
26 ENCLOSURE
27 1/4-28X3/4 SOCKET HEAD CAP SCREW
30 O-RING-018 3/4 ID 1/16 C/S
31 CONDUIT FITTING
32 HOSE - 3/8" ID PUSH-LOK
33 NAME LABEL: MONSOON RC
39
QTY PART #
30 FEET Y5200
3 VT25-20BH500
3 Y4655
1 Y4660
1 Y4650
1 VB.312
8 VT25-28SH500
1 Y4618
1 Y4619
2 VM4123
1 Y5800
2 Y4656
1 VT10-24BH375
1 Y5340
1 Y5280
1 Y4950
1 Y4620
4 VT06S32SH312
1 Y4615
1 VO-038
1 Y4610
1 Y4616
4 VT25-28SH750
1 VO-018
1 Y5213
1 FOOT Y5250
1 Y4180
