ETC Source 4WRD II Installation And User Manual page 9

Specifications
For full product specifications, see the Source 4WRD II LED datasheet at
etcconnect.com.
Electrical
209–252 VAC 47–53 Hz power input
•
175 W draw at full
•
Recommended 2 fixtures per dimmed circuit (ED15 module)
•
Maximum of 6 fixtures per non-dimmed circuit (ER15AFR module)
•
If using in DMX mode: Connect fixture to relay, constant power, or
•
dimmer with regulation off and parked at full
Inrush: 12 A (first half-cycle)
•
Idle: DMX Mode
Idle: AC Mode
Full Intensity
Environment
Ambient operating temperature: 5°C–50°C (41°F–122°F)
•
Minimum storage temperature: 5°C (41°F)
•
Maximum recommended ambient operating temperature: Ta=50°C
•
(122°F)
Maximum anticipated external surface temperature: Tmax=63°C
•
(145°F) at Ta=50°C (122°F)
External Temperature (steady state achieved) at 25°C (77°F)
•
ambient: 38°C (100°F)
Weight
Source 4WRD II LED retrofit kit only: 1.69 kg (3.73 lb)
•
Source 4WRD II LED installed on 26° fixture with yoke: 5.48 kg
•
(12.1 lb)
Optical
Compatible with all ETC Source Four lens tubes.
Source 4WRD II Installation and User Manual
Typical Power Consumption
Mode Power
3.7 W
0 W
175 W
Current
.05 A
0 A
.75 A
5
