Remove Incandescent Lamp Housing

1. Unplug the Source Four incandescent fixture and place it on a flat,

stable surface.

2. Loosen the brass thumb screw located above the beam adjustment

knob. The lamp housing is now loose.

3. Slide the lamp housing away from the fixture body and locate the

screw that secures the earth bond wire to the fixture body. Loosen

and remove the screw and accompanying washer to free the earth

bond wire.

4. Remove the lamp housing from the fixture body.

Note:

ETC to recycle the burner assembly, contact ETC Technical Services

for more information. See

page 2.

Source 4WRD II Installation and User Manual

The burner assembly is no longer needed. If you would like

Help from ETC Technical Services on
